INNCOM E7 THERMOSTAT USER GUIDE

e7 24 VAC POWER AND HVAC SIGNAL (INNCOM PIN 62-1464 R) - H1

Part Number
Color
1
Green
2
Red
3
Black
4
Blue
5
Brown
6
Yellow
7
White
8
Grey
9
Violet
10
Orange

e7 100-277VAC POWER AND HVAC SIGNAL HARNESS (INNCOM P/N 62-1455) - H1

Part Number
Color
1
Green
2
Black
3
White
4
Yellow
5
Orange
6
Red
7
Brown
8
Grey
9
Violet
10
Blue
36-00013—02
Typical Function
Ground
24 Vac
Common
High Fan
Medium Fan or Second Stage Heat
Cold Water Valve (FCU) or Compressor Signal (Heat Pump)
Hot Water Valve (FCU) or Reversing Valve (Heat Pump)
Valve Power
Fan Power
Low Fan
Typical Function
Ground
Line
Neutral
High Fan
Medium Fan or Second Stage Heat
Cold Water Valve (FCU) or Compressor Signal (Heat Pump)
Hot Water Valve (FCU) or Reversing Valve (Heat Pump)
Valve Power
Fan Power
Low Fan
8
