INNCOM E7 THERMOSTAT USER GUIDE
2 FAN SPEED HEAT PUMP, REVERSING VALVE POSITION DETERMINES HEATING OR
COOLING
System State
Room
(Off / Auto)
Temperature
Off
75 degrees
AUTO
72 degrees
AUTO
73 degrees
AUTO
75 degrees
AUTO
77 degrees
AUTO
70 degrees

4-PIPE, 3-SPEED FAN FCU WITH HOT AND COLD WATER AVAILABLE

System State
Room
(Off / Auto)
Temperature
Off
75 degrees
AUTO
72 degrees
AUTO
73 degrees
AUTO
75 degrees
AUTO
77 degrees
AUTO
67 degrees
AUTO
67 degrees
2-PIPE, 2-SPEED FAN FCU WITH COLD WATER IN PIPE, HEAT STRIP, AND CONTINUOUS
FAN SPECIFIED
System State
Room
(Off / Auto)
Temperature
Off
75 degrees
AUTO
72 degrees
AUTO
73 degrees
AUTO
75 degrees
AUTO
77 degrees
AUTO
67 degrees
AUTO
67 degrees
36-00013—02
Set Temperature
Fan
72 degrees
OFF
72 degrees
OFF
72 degrees
LOW
72 degrees
MED
72 degrees
HIGH
72 degrees
OFF
Set Temperature
Fan
72 degrees
OFF
72 degrees
OFF
72 degrees
LO
72 degrees
MED
72 degrees
HIGH
72 degrees
LOW
72 degrees
HI
Set Temperature
Fan
72 degrees
LOW
72 degrees
LOW
72 degrees
LOW
72 degrees
HIGH
72 degrees
HIGH
72 degrees
LOW
72 degrees
HI
14
Reversing Valve
Compressor
Cool Position
OFF
Cool Position
OFF
Cool Position
OFF
Cool Position
ON
Cool Position
ON
Heat Position
ON
Cold Water
Valve
Hot Water Valve
CLOSED
CLOSED
CLOSED
CLOSED
OPEN
CLOSED
OPEN
CLOSED
OPEN
CLOSED
CLOSED
OPEN
CLOSED
OPEN
Cold Water
Valve
Hot Water Valve
CLOSED
OFF
CLOSED
OFF
OPEN
OFF
OPEN
OFF
OPEN
OFF
CLOSED
OFF
CLOSED
ON
