Fans

Description
Fans
N17E
N17P
Fans support brackets
N17E
N17P
Vent support brackets
Before removing the fans, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the any smart cards and memory cards.
5. Remove the base enclosure (see
6. Remove the battery (see
7. Remove the hard drive (see
8. Remove the SSD (see
Remove the vent support brackets:
1. Release the four Phillips 3 mm flat large head screws (1) that secure the brackets to the computer.
Base enclosure on page
Battery on page 46).
Hard drive (HDD) on page
Solid-state drive (SSD) on page
35).
38).
40).
Component replacement procedures
Spare part number
L24359-001
L29081-001
L24362-001
L24363-001
L24361-001
49
