THS 812
Digitální
satelitní
přijímač
pro vysoká
rozlišení
obrazu
Návod k obsluze
Používateľská príručka
User manual
Evolution. Emotion. Passion
www.thomsonstb.net

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the THS 812 and is the answer not in the manual?

Questions and answers

Related Manuals for THOMSON THS 812

Summary of Contents for THOMSON THS 812

  • Page 1 THS 812 Digitální satelitní přijímač pro vysoká rozlišení obrazu Evolution. Emotion. Passion Návod k obsluze www.thomsonstb.net Používateľská príručka User manual...

  • Page 4: Table Of Contents

    Thomsondeclaresthatthisitemcomplieswiththebasicrequirementsandotherrelevantregulationsofdirectives2004/108/ECand73/23/EC,Rohs2002/95/EC. THOMSON is a trademark of TECHNICOLOR S.A. used under license to STRONG Europe. Subject to alterations. In consequence of continuous research and development technical specifications, design and appearance of products may change. ASTRA is a registered trade mark of SES ASTRA, Eutelsat and HOT BIRD are registered trademarks of Eutelsat Communications, HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

  • Page 5: Introduction

    lICEnsEs ANY USE OF THIS PRODUCT IN ANY MANNER OTHER THAN PERSONAL USE THAT COMPLIES WITH THE MPEG-2 STANDARD FOR ENCODING VIDEO INFORMATION FOR PACKAGED MEDIA IS EXPRESSLY PROHIBITED WITHOUT A LICENSE UNDER APPLICABLE PATENTS IN THE MPEG-2 PATENT PORTFOLIO, WHICH LICENSE IS AVAILABLE FROM mPEgla,llC, 6312 S.

  • Page 6: Storage

    It is advised not to store important information on USB storage devices used with the receiver. Always make backups of data on your USB storage device before using it with this receiver. THOMSON will not take responsibility for any loss of information or circumstances caused by loss of information.

  • Page 7: Yourreceiver

    Please ensure that either the USB device is already formatted to FAT32. 2.0YoURRECEIvER 2.1DefaultPIn-code Default PIN-code of receiver is “0000”. This one can be modified later on. 2.2mastermRPIn-code This PIN is used for maturity rating and playback of protected records and is supplied by the operator.

  • Page 8: Installing The Batteries

    10. ok Menu Off: Displays the current channel list. Menu On: Opens the highlighted setting 11. mEnU Opens the main menu and from main menu you will get one step back 12. EXIT/soRTIE Exits from the menu, sub-menu or cancels actions 13.

  • Page 9: Connecting Multiple Fixed Antennas Via Diseqc 1.0 Switch

    1. Connect the LNB or Mono block for ASTRA 19.2 /ASTRA 23.5 of your satellite antenna to the SAT IN connector of your receiver using a good quality coaxial cable and suitable ‘F-connector’ plugs. 2. Connect one end of a good quality HDMI cable (V1.3 or higher) to the HDMI connector of your receiver and the other end to the HDMI input of your TV set.

  • Page 10: Language, Country And Video Setup

    4.1language,Countryandvideosetup After turning on the power for the first time, the OSD language, Country and Video Setting menus will be shown. First choose your language with then press to select your preferred country. As the last step on this screen use to select Video Setting. Select which connection you will use to your TV screen: SCART or HDMI cable.

  • Page 11: Scan Selection

    When all settings have been made, press blUE Next to continue. To check or change the settings for the satellite on port 1 press ok to enter the submenu. If port 1 is already correctly adjusted and you have proper signal quality and strength banners you can adjust the port 2 if you have a satellite connected there.

  • Page 12: Quickguidetousingyourreceiver

    5.0QUICkgUIDEToUsIngYoURRECEIvER We at THOMSON understand that you can’t wait to enjoy your new HD receiver. The following quick guide will make you familiar with the basic operation of this device. We do, however, advice you to read the full manual to get the best performance from your THOMSON HD receiver.

  • Page 13: Info Banner

    6.1.3UsingtheP+/P-keys P+ or will switch to a higher channel. P- or will switch a lower channel. 6.2Infobanner At any time during viewing mode you can press the button to get info about the current channel and programme*. For the current programme information use to change between the NOW and NEXT event info.

  • Page 14: Instant Recording

    Timeshift, press 3.  T imeshift only works correctly when a fast USB storage device such as a USB2.0/3.0 noTE: HDD is connected to the receiver. Distorted picture and/or audio during Timeshift indicate a too slow USB device speed. Especially when Timeshift is activated at channels with high data rate (High quality SD/HD) a high speed USB device is needed, THOMSON cannot guarantee this function for all USB devices. 6.106.10Playbackofrecording If you have made recordings you can access the HDD Manager directly from viewing mode by pressing . For a detailed description of the menu please refer to chapter 7.4.5hDD...

  • Page 15: Installation

    7.1Installation This menu allows you to change satellite settings and to search for channels. Further you can adjust important settings for your receiver. It consists of the following sub-menus: Antenna Setup, Channel Search, System Settings, Parental Lock and Factory Reset. Choose a sub menu with and press ok to advance.
  • Page 16 Set Limit: Press ok to open this sub menu for setting up the maximum position of you dish. This is needed if your dish will touch a wall and can be damaged. goToXset-up In this menu you can set your geographical location if you use a motor and it supports GOTO X. Press ok to open the list of available satellites and chose the desired one with the buttons.
  • Page 17  W hen you want to add technical data for a new transponder we recommend verifying it noTE: by consulting websites like: www.lyngsat.com or www.kingofsat.net or you can refer to professional journals. 7.1.3systemsettings Use the System Settings menu to configure settings for language, audio, video, look and feel and press ok to list the possibilities or use of your receiver. Choose a setting with change the value of the highlighted setting. Please also read the displayed instructions for each screen carefully.
  • Page 18 Conversion: Letterbox, Pan&Scan or Combined, to choose the preferred picture format. Video Output: RGB or CVBS, depending on what your TV set supports, but for Scart we recommend RGB. Resolution: Only selectable for HDMI HDCP: ON or OFF, please see the note above. After all settings are adjusted following to your preference, choose Save with and press ok.

  • Page 19: Update & Info

    setting you will have to enter your PIN code when switching through channels which support EPG or submit EPG based parental rate. Not rated content: Use buttons to select Blocked or Unblocked. In order to block or not block the channels with PIN code before decoding, where the EPG based parental rate not broadcasted.

  • Page 20: Conditional Access

    7.2.5oTasoftwareUpdate The OTA (Over the Air) function allows you to search for software updates available on ASTRA 23.5 satellite. Please ask your local THOMSON dealer or visit our website www.thomsonstb.net for information. After pressing ok on OTA Software Update to execute your receiver will start looking for new software.

  • Page 21: Channel Manager

    a defined rate for a movie or special event you can use this setting to protect children from watching improper content for their age. These PIN codes are also used to start playback of a recording with protection. The availability and access of this menu depends on if the broadcaster supports/opens this function.
  • Page 22 favourite group and press RED to delete this channel. Then press to change to the left side again if you want to add other channels to favourite groups.  R emoving a channel from a favourite group doesn’t remove this channel from the channel noTE: list. movechannels Press the YElloW button to move a channel position in the channel list for the selected favourite group.
  • Page 23 You can delete all these at once and it allows you to make new recordings again.  T his will delete all data, information and recordings from the external HDD and is irreversible! WaRnIng: THOMSON cannot guarantee this function for all USB devices and cannot be responsible for loss of recordings or data.  I f you time to time make a copy from this external HDD to another HDD by using a computer TIP: it will protect some recordings should they have gotten lost or damaged on the currently used HDD.

  • Page 24: Timer

    SMS method. After you have entered a new name for the selected recording, press ok to store. sort Press mEnU and select Sort and the way you like to display the record list. Select between Sort by Date if you want to sort by date of events. Select Sort by Alphabet to sort on A ~ Z order.

  • Page 25: Troubleshooting

    If the receiver does not work properly after checking it, please contact your local service line or THOMSON dealer. Alternatively you can send a support mail via our website: www.thomsonstb.net. NEVER open or disassemble your receiver.

  • Page 26: Specifications

    symptom Cause Remedy The remote The batteries of the remote Check whether the batteries are inserted control does not control are not inserted, correctly or exhausted, if so replace the work wrongly inserted or batteries in the remote control. exhausted. The USB Wrong formatted.
  • Page 27 Output voltage 12 V DC, 2.0A Power consumption: max. 20 W, typ. 8.00 W Power consumption in stand-by: max. 1.00 W Operating temperature: +0 to +40 °C Storage temperature: -10 to +70 °C Operating humidity range: 25 ~ 75% RH, non-condensing Size (W x D x H) in mm: 261 x 168 x 51 Weight: 0.911 kg sPECIfICaTIons...
