SSL δ-Monitoring Plugin
The δ-Monitoring Plugin remotely controls your Sigma monitoring switches / levels. It is designed to be used alongside
the δ-Mix Bus plugin, and δ-Single/δ-16 plugin; all channel, mix bus and monitor settings will be stored within each DAW
project for faster recall.
GUI
1
2
1 Monitor Source buttons – switch the monitor output source between Mix A, Mix B, and the external input. Click on
switches to select a source.
2 Monitor level – adjusts monitor level. Click and drag mouse to alter level.
3 Monitor Control buttons – these buttons switch monitor cut, dim, and mono, as well as switching to the alternate
speaker output (ALT L/S). Click on switches to toggle.
4 Headphone Source Buttons – these buttons switch the headphone output source between Mix A, Mix B, and the
external input. Click on switches to toggle between sources.
5 Headphone level – adjusts headphone level. Click and drag mouse to alter level.
6 Level Indicator – indicates the dB value of headphone and monitor levels.
workstation Setup
Follow the steps outlined in the Example setups for Sigma and your chosen DAW
1.
2. Once the plugin has been installed, insert the -Monitoring plugin into any track in your DAW
3. The plugin will connect to Sigma automatically.
Page 63
4
5
6
