VADDIO 999-9200-050 Installation And User Manual

Camera and Electronic Products for Integrators
D V I E
D V I E
O M E
O M E
Integrated Outdoor Environmental Pendant Mount
Dome Systems and Outdoor Pendant Mount Dome
Enclosures for Sony® and Canon® PTZ Cameras
OVERVIEW:
The Vaddio™ DomeVIEW Outdoor, Environmental Pendant Mount
Domes (Figure 1) are integrated camera mounting systems that are
attractive and easy to install.
applications, and including an internal heater/blower, the 8.2"
(20.8cm) Outdoor Pendant mount dome enclosure is outfitted with
the internal brackets to support the option of using the Sony EVI-
D70 or the Canon VC-C50iR robotic PTZ cameras.
The DomeVIEW Outdoor Pendant Mount Dome Package is sold complete with the Camera. The DomeVIEW
system for the Sony EVI-D70 and VC-C50iR features the standard Vaddio EZCamera Cabling System. The
EZCamera cabling solution provides for fast and efficient installations using Cat. 5 cabling for video, power
and control. The enclosures are also sold without the camera to accommodate an existing camera to be
used with the Outdoor Pendant Mount Dome enclosure without the EZCamera cabling system.
The outdoor domes are formed from optical grade polycarbonate and are available in smoked tint (clear is
optional). The DomeVIEW Outdoor Pendant Mount Domes are excellent values that are high quality,
attractive and durable solutions for outdoor security applications.
This Manual covers the following Vaddio DomeVIEW Outdoor Pendant Mount Dome Systems:
999-9200-050 DomeVIEW 50iR Outdoor Pendant Dome with Canon VC-C50iR, EZCamera Cabling
System and Internal Mounting Bracket
999-9200-070 DomeVIEW 70 Outdoor Pendant Dome with Sony EVI-D70, EZCamera Cabling System
and Internal Mounting Bracket
This Manual covers the following Outdoor Pendant Mount Dome Enclosures:
998-9200-050 Outdoor Pendant with Internal Mounting Bracket for VC-C50iR (Camera Not Included)
998-9200-070 Outdoor Pendant with Internal Mounting Bracket for EVI-D70 (Camera Not Included)
Note: The Outdoor Pendant Mount Domes mount to a 1-1/2" NPT Pipe, which are not part of the DomeVIEW packages or the
Outdoor Pendant Mount Dome enclosures.

INTENDED USE:

Before operating the DomeVIEW system, please read the entire manual thoroughly. The DomeVIEW Outdoor Pendant Mount systems
were designed, built and tested for use Outdoors (or indoors) and with the provided power supply. The use of a power supply other than
the one provided or has not been tested and could damage the electronics and/or create a potentially unsafe operating condition.
SAVE THESE INSTRUCTIONS:
The information contained in this manual will help you install and operate your Vaddio DomeVIEW. If these instructions are misplaced,
Vaddio keeps copies of Specifications, Installation and User Guides and most pertinent product drawings for the Vaddio product line on
the website. These documents can be downloaded from

IMPORTANT SAFEGUARDS:

Read and understand all instructions before using. Do not operate the system if it has been dropped or damaged. In this case, a Vaddio
technician must examine the product before operating. To reduce the risk of electric shock, do not immerse in water or other liquids and
avoid extremely humid conditions.
ⓒ2009 Vaddio - DomeVIEW Systems - All Rights Reserved. Reproduction in whole or in part without written permission is prohibited. Specifications and
pricing are subject to change without notice. Vaddio, DomeVIEW, EZCamera, Quick-Connect, WallVIEW, CeilingVIEW, EZCable and PowerRite are
trademarks of Vaddio, Inc. All other trademarks are property of their respective owners. Document 341-445 Rev C.
W ™
W ™
Designed for outdoor security
www.vaddio.com
Installation and User Guide
Figure 1:
Outdoor Pendant Mount Dome shown
with Smoke Tinted Dome standard
(Clear is an option)
.
