Summary of Contents for VADDIO IntelliSHOT 999-21100-000
- Page 1 Complete Manual for the IntelliSHOT Auto-Tracking Camera Document 411-0053-30 Rev A May 2021...
-
Page 2: Table Of Contents
About Inverted Installation Initial Device Set-Up Browser Support Initial Device Set-up Process Overview Initial Device Set-Up Using the Vaddio Device Controller Initial Device Set-Up Using the Vaddio Deployment Tool Manual Access and Initial Device Set-Up Initial Access to the Web Interface... - Page 3 Complete Manual for the IntelliSHOT Auto-Tracking Camera Managing Audio Other Audio Settings and Adjustments About Echo Cancellation Configuring Streaming Behavior Viewing the USB Stream Configuring USB Streaming Enabling or Disabling IP Streaming Viewing the IP Stream (RTSP) RTSP Streaming Protocol and URL Setting up IP Streaming in Easy Mode Customizing IP Streaming Settings Configuring RTMP Streaming...
- Page 4 Complete Manual for the IntelliSHOT Auto-Tracking Camera Contacting Vaddio Technical Support and Viewing Diagnostic Logs Telnet Serial Command API Requirements Usage Notes Getting More Information Typographical Conventions Autoframer Commands autoframer enabled autoframer paused camera optical-zoom autoframer buffer-zone autoframer shot-margin autoframer sensitivity...
- Page 5 Complete Manual for the IntelliSHOT Auto-Tracking Camera streaming ip enable streaming settings get Maintenance and Troubleshooting Commands version network ping system reboot system factory-reset Telnet Information and Session Management Commands history help exit Troubleshooting and Care Power and Control Video and Streaming Audio Status Lights Restoring Default Camera Settings...
-
Page 6: Overview
Overview This guide covers: ® IntelliSHOT auto-tracking camera: North America – 999-21100-000 (black); 999-21100-000W (white) Europe and UK – 999-21100-001 (black); 999-21100-001W (white) Australia and New Zealand – 999-21100-009 (black); 999-21100-009W (white) What's in this Guide This guide covers Physical features Installation Initial set-up and system administration Performance/behavior configuration... -
Page 7: A Quick Look At The Camera
Complete Manual for the IntelliSHOT Auto-Tracking Camera A Quick Look at the Camera This section covers the physical features of the camera. Front of the Camera The camera is available in black or white. Camera and zoom lens – Up to 30x zoom. Integrated microphone –... -
Page 8: Connector Panel
Complete Manual for the IntelliSHOT Auto-Tracking Camera Connector Panel The connectors are on the underside of the camera. PoE+ – RJ-45 connector. Connect to the network and to power via the Power and Data Out port of the mid-span PoE+ power injector. Provides power and network access for IP streaming and camera control via web interface or Telnet. -
Page 9: Installation
Do not allow it to come into contact with any liquid. Do not install or operate this product if it has been dropped, damaged, or exposed to liquids. If any of these things happen, return it to Vaddio for safety and functional testing. Before You Install the Camera... -
Page 10: Pre-Installation Functional Check
If the camera turns on and sends video, continue with the installation. Getting the Camera's IP Address You will need the camera's IP address if you do not use the Vaddio Device Controller or Vaddio Deployment Tool to access its web interface. -
Page 11: If The Camera Is At 169.254.1.1
Complete Manual for the IntelliSHOT Auto-Tracking Camera If the Camera Is At 169.254.1.1 This is the camera's default IP address. This means one of these things: The camera's PoE+ power injector is not connected to the network, The network does not automatically assign IP addresses. If the camera does not receive an IP address when connected to the network, you will need to configure the camera for the network after you have done the initial device set-up. -
Page 12: Basic Connections
Complete Manual for the IntelliSHOT Auto-Tracking Camera Basic Connections Here is an example of how the camera might be set up in a medium-size conference room. In this setup, a PC uses a unified communications conferencing application to manage the camera and connected microphones and speaker. -
Page 13: Initial Device Set-Up
Then you will be able to access to the system administration tasks to define how the device behaves as an element of your network. This is also true after restoring factory defaults. Because this process is the same for all Vaddio cameras, screen shots in this section may show different products. -
Page 14: Initial Device Set-Up Using The Vaddio Deployment Tool
Note Be sure you have the current version of the Vaddio Deployment Tool. If it notifies you that an update is available, install the update. This ensures that you have access to the full capabilities of the tool. Old versions may not recognize the newest products. -
Page 15: Manual Access And Initial Device Set-Up
Manual Access and Initial Device Set-Up If you do not use a Vaddio Device Controller or the Vaddio Deployment Tool, you will need to complete the initial device set-up manually, by browsing to the device's web interface using its IP address. See Getting the Camera's IP Address. -
Page 16: System Administration
Complete Manual for the IntelliSHOT Auto-Tracking Camera System Administration This chapter covers settings for managing the camera as an element of your network. Security – Passwords, guest access, other IT security-related settings Network configuration Time settings Configuring Camera Behavior for information on image adjustments, streaming configuration, and other items related to camera behavior. -
Page 17: Configuring The Camera For Your Network
Complete Manual for the IntelliSHOT Auto-Tracking Camera Configuring the Camera for Your Network By default, the camera is set to DHCP, and will receive an IP address automatically if your network assigns IP addresses. Work with your network specialist to ensure that the camera is configured to comply with the organization's network policies. -
Page 18: Changing The Camera's Hostname
Complete Manual for the IntelliSHOT Auto-Tracking Camera Changing the Camera's Hostname ETWORKING PAGE If your network supports hostname resolution, you can browse to the camera using its hostname. Giving it a simple, easy-to-remember hostname means you don't need to know its IP address. Work with your IT department to ensure that the new hostname conforms to the organization's naming conventions. -
Page 19: Configuring Camera Behavior
Complete Manual for the IntelliSHOT Auto-Tracking Camera Configuring Camera Behavior This chapter covers settings for defining how the camera performs in your environment: Autoframing adjustments Streaming Manual-mode settings and adjustments – presets, color and lighting, speed, focus Audio adjustments Other camera settings Fine-Tuning Autoframing Behavior The Autoframing feature can be tuned to your specific installation. -
Page 20: How It Works: Autoframing
Complete Manual for the IntelliSHOT Auto-Tracking Camera How It Works: Autoframing Autoframing is based on motion detection. It won't mistake pictures for people, it still works if you turn away from the camera, and you don't have to wear a special device. Because there's no special device, though, Autoframing does not necessarily keep the shot on its original subject. -
Page 21: Basic Autoframing Adjustments
Complete Manual for the IntelliSHOT Auto-Tracking Camera Basic Autoframing Adjustments UTOFRAMING PAGE When making adjustments, compare the Visualizer's image to the video output. Optical Zoom – Sets the area in which motion can be tracked. Adjust this first. Autoframing Presets – Factory configurations. "Conservative" settings are less sensitive and track at lower speeds than "responsive"... -
Page 22: Advanced Autoframing Adjustments
Complete Manual for the IntelliSHOT Auto-Tracking Camera Persistence – How long the camera remembers motion and stays on its source after other trackable motion starts. Typically 25% to 100% for conferencing, below 15% for lecture capture. Shot Margin – Controls how tight or wide the shot will be around the people in the cameras view. A high value will result in a wider shot and a low value results in a tighter shot around the person or group of people.Default value is 7% for conferencing and 13% for lecture capture. -
Page 23: Autoframing Adjustment Quick Reference
Complete Manual for the IntelliSHOT Auto-Tracking Camera Autoframing Adjustment Quick Reference Set Optical Zoom and select the Autoframing preset that is most similar to the room's requirements. Then adjust Autoframing to meet the unique demands of your space. These tables may help. Not Tracking Enough To correct this Do this... -
Page 24: Managing Audio
Complete Manual for the IntelliSHOT Auto-Tracking Camera Managing Audio UDIO PAGE Controls for individual inputs (audio from your site) and outputs (audio from the far end of the conference) are on separate tabs. To mute all audio inputs together: To stop sending audio, use the audio mute button at the top of any page of the web interface. To mute or control volume for individual audio inputs or outputs: Use the button to mute the desired audio input or output. -
Page 25: About Echo Cancellation
Complete Manual for the IntelliSHOT Auto-Tracking Camera To sync the sound with the video in the IP stream: On the Outputs tab, check the Delay box and enter a delay value in milliseconds. About Echo Cancellation When a microphone picks up the audio from a speaker (far-end audio) during a conference, it sends the far-end audio back to the participants at the far end, creating an echo. -
Page 26: Configuring Streaming Behavior
Notes The screen shots in this section are representative, and may differ from what you see. Some may refer to other Vaddio products. You may be prompted to reboot the camera when you save changes to the streaming settings. Viewing the USB Stream Do one of these things: Start or join a conference. -
Page 27: Enabling Or Disabling Ip Streaming
Complete Manual for the IntelliSHOT Auto-Tracking Camera Enabling or Disabling IP Streaming TREAMING PAGE IP streaming is disabled by default. Two IP streaming protocols are available: RTSP streaming delivers an IP stream that people can access from your network using a media player. -
Page 28: Rtsp Streaming Protocol And Url
When IP streaming is enabled and RTSP is selected, the RTSP stream is automatically available. Consult your IT department before changing these settings. RTSP port: Vaddio strongly recommends using the default RTSP port number. Path: The portion of the streaming URL that appears after the IP address. You may wish to change this to help identify the stream source –... -
Page 29: Setting Up Ip Streaming In Easy Mode
Complete Manual for the IntelliSHOT Auto-Tracking Camera Setting up IP Streaming in Easy Mode TREAMING PAGE Note Consult your network specialist when setting up IP streaming, to be sure that you select settings that are appropriate for the network. If you are not sure about these settings, start with the defaults. 1. -
Page 30: Configuring Rtmp Streaming
Complete Manual for the IntelliSHOT Auto-Tracking Camera Configuring RTMP Streaming TREAMING PAGE To use RTMP streaming, you must have an account with a streaming service. To configure an RTMP streaming service: 1. Select RTMP streaming, then select Settings. 2. Expand the information box for the service. 3. -
Page 31: Configuring Manual Mode Behaviors
Complete Manual for the IntelliSHOT Auto-Tracking Camera Configuring Manual Mode Behaviors Although Autoframing mode is normally used with this camera, there are times when you need conventional PTZ behaviors. This section covers: Preset shots Speed controls Direction controls These settings are on the Camera page of the web interface. Setting the Home Position and Other Preset Shots AMERA PAGE Although the camera's Autoframing feature is the simplest way to keep the focus on the presenter, there... -
Page 32: Renaming Presets And Custom Ccu Scenes
Complete Manual for the IntelliSHOT Auto-Tracking Camera Renaming Presets and Custom CCU Scenes AMERA PAGE You can rename presets and custom scenes to identify them. This also helps you identify and avoid overwriting them when you store new ones. The process is the same for both. Right-click the button for the preset or custom scene, and edit the label. -
Page 33: Adjusting Color, Lighting, And Image Quality Settings
Adjusting Color, Lighting, and Image Quality Settings AMERA PAGE No two rooms are exactly alike – but a lot of rooms are a lot alike. The technical folks at Vaddio (Scott, to be specific) have already set up adjustments for common lighting scenarios (CCU scenes) –... -
Page 34: Lighting And Image Quality Quick Reference
Complete Manual for the IntelliSHOT Auto-Tracking Camera Lighting and Image Quality Quick Reference Here are some tips for using the CCU settings for lighting and image quality. What do you need to correct? Make this adjustment: The image is too dark Increase Iris (lower F-stop value) Increase Iris Gain The image looks washed out or faded... -
Page 35: Color Adjustment Quick Reference
Complete Manual for the IntelliSHOT Auto-Tracking Camera Color Adjustment Quick Reference Here are some tips for using the color-related CCU settings. What do you need to correct? Make this adjustment: Colors look less vivid than they should Increase Chroma Colors look too vivid Decrease Chroma Colors look wrong;... -
Page 36: Adjusting The Focus
Complete Manual for the IntelliSHOT Auto-Tracking Camera Adjusting the Focus AMERA PAGE Open the Focus control to select Auto-focus, or set manual focus with the + (near) and – (far) buttons. The + and – buttons only work when Auto Focus is not selected. Focus control is available to non-administrative users via the RF remote. -
Page 37: Additional Camera Settings
ENERAL TAB Additional settings are available on the General tab on the System page. LED On – In most cases, Vaddio recommends leaving the status lights on, to let people in the room know whether the camera is currently sending video. -
Page 38: Operating The Camera
When you need to control the camera in manual mode rather than using Autoframing, you can use The RF remote The web interface (accessible from your computer's browser or using a Vaddio Device Controller) A third-party control device When you use the manual controls, Autoframing pauses. It's similar to cruise control in a car: Using a preset or directional control is like tapping the brake pedal. -
Page 39: Muting Audio And Video
Complete Manual for the IntelliSHOT Auto-Tracking Camera Muting Audio and Video Use the audio mute button to stop sending audio. Use the video mute button to temporarily stop sending video from the camera without placing it in standby. Use the RF remote to control volume. Managing the Camera Ready State Use the Standby button to switch between low-power (standby) and ready states. -
Page 40: Operating The Camera With The Rf Remote
Vaddio Technical Support. Note Any time a pairing error occurs (status light blinking blue), Vaddio recommends rebooting the camera as soon as feasible. If pairing was successful, the remote remains paired through the reboot process. If you have access to the administrative web interface: 1. -
Page 41: Rf Remote Quick Reference
Complete Manual for the IntelliSHOT Auto-Tracking Camera RF Remote Quick Reference Indicator and Power button – Set the camera to standby mode, or return to full-power mode. Function buttons – Reserved for future use. Arrow buttons – Pan and tilt. Autoframing pauses if you use these buttons. -
Page 42: Unpairing The Remote
Complete Manual for the IntelliSHOT Auto-Tracking Camera Unpairing the Remote AIRING PAGE If you need to unpair the remote from the camera that currently recognizes it, you will need admin access to the camera's web interface. On the Pairing page, select Forget Remote. -
Page 43: System Maintenance
Complete Manual for the IntelliSHOT Auto-Tracking Camera System Maintenance This chapter covers tasks for keeping your system up-to-date and operating properly: Rebooting Backing up and restoring the camera configuration Installing firmware updates Getting help Saving (Exporting) or Restoring (Importing) a Configuration YSTEM PAGE IRMWARE TAB If you need to restore a camera's factory default settings, you can export the configuration beforehand to... -
Page 44: Installing A Firmware Update
Complete Manual for the IntelliSHOT Auto-Tracking Camera Installing a Firmware Update YSTEM PAGE IRMWARE TAB Caution Be sure the camera stays connected to power and to the network during the update. Interrupting the update could make it unusable. 1. Read the release notes and download the firmware update file from the product's web page at www.legrandav.com. -
Page 45: Contacting Vaddio Technical Support And Viewing Diagnostic Logs
You’ll find information for contacting Vaddio Technical Support on the Help screen. Note The Help page links to our standard privacy notice. This product does not record or save video files, or store any identifying information except what you enter on the Room Labels page. -
Page 46: Telnet Serial Command Api
Complete Manual for the IntelliSHOT Auto-Tracking Camera Telnet Serial Command API The Vaddio Telnet command API allows an external device such as an AMX or Crestron presentation system to control the camera. It is also used for writing macros. Requirements Telnet must be enabled on the Security page of the device's web interface. -
Page 47: Autoframer Commands
Complete Manual for the IntelliSHOT Auto-Tracking Camera Autoframer Commands Commands to manage and adjust Autoframing fall roughly into three categories. Status commands: autoframer enabled autoframer paused Shot definition commands: camera optical-zoom autoframer shot-margin autoframer max-electronic-zoom autoframer buffer-zone Autoframing behavior adjustment commands: autoframer sensitivity autoframer responsiveness autoframer initial-persistence... -
Page 48: Autoframer Paused
Complete Manual for the IntelliSHOT Auto-Tracking Camera autoframer paused Pause or resume Autoframing. Autoframing pauses automatically when the camera receives a pan, tilt, zoom, or preset recall command from any source. Synopsis autoframer paused { get | off | on | toggle } Options Returns the pause state for Autoframing Turns off the pause state (restarts... -
Page 49: Autoframer Buffer-Zone
Complete Manual for the IntelliSHOT Auto-Tracking Camera autoframer buffer-zone Get or set the size of the Autoframing buffer zone. Synopsis autoframer buffer-zone { get | set <value> } Options Returns the current value for the Autoframing buffer zone set <value> Sets the Autoframing buffer zone >autoframer buffer-zone set 10 Examples >... -
Page 50: Autoframer Sensitivity
Complete Manual for the IntelliSHOT Auto-Tracking Camera autoframer sensitivity Get or set Autoframing sensitivity. Synopsis autoframer sensitivity { get | set <value> } Options Returns the current value for sensitivity set <value> Sets Autoframing sensitivity >autoframer sensitivity set 95 Examples > Sets the sensitivity to 95. -
Page 51: Autoframer Initial-Persistence
Complete Manual for the IntelliSHOT Auto-Tracking Camera autoframer initial-persistence Get or set the initial persistence value. Synopsis autoframer initial-persistence { get | set <value> } Options Returns the current value for initial persistence set <value> Sets initial persistence >autoframer initial-persistence set 15 Examples >... -
Page 52: Autoframer Max-Electronic-Zoom
Complete Manual for the IntelliSHOT Auto-Tracking Camera autoframer max-electronic-zoom Get or set the value for the Autoframing maximum electronic zoom. This limits how far the camera zooms in for Autoframing. Synopsis autoframer max-electronic-zoom { get | set <value> } Options Returns the current value for the maximum electronic zoom set <value>... -
Page 53: Autoframer Noise-Threshold
Complete Manual for the IntelliSHOT Auto-Tracking Camera autoframer noise-threshold Get or set the value for the Autoframing noise threshold. This helps the camera to identify motion. Synopsis autoframer noise-threshold { get | set <value> } Options Returns the current value for the noise threshold set <value>... -
Page 54: Autoframer Forced-Wait-Time
Complete Manual for the IntelliSHOT Auto-Tracking Camera autoframer forced-wait-time Get or set the value for the Autoframing forced wait time. This sets a minimum time to hold the shot before responding to new motion. Increasing persistence and reducing responsiveness may produce more satisfactory results. -
Page 55: Camera And Video Management Commands
Complete Manual for the IntelliSHOT Auto-Tracking Camera Camera and Video Management Commands The following camera and video management commands are available: camera home camera pan camera tilt camera zoom camera ptz-position camera focus camera preset camera ccu get camera ccu set camera led camera icr video mute... -
Page 56: Camera Pan
Complete Manual for the IntelliSHOT Auto-Tracking Camera camera pan Moves the camera horizontally. Autoframing pauses when the camera receives this command. The amount of pan available depends on the zoom level. A tight shot can move more than a wide one. (See How It Works: Digital Pan/Tilt/Zoom.) If the camera is fully zoomed out, pan commands do not... -
Page 57: Camera Tilt
Complete Manual for the IntelliSHOT Auto-Tracking Camera camera tilt Moves the shot vertically. Autoframing pauses when the camera receives this command. The amount of tilt available depends on the zoom level. A tight shot can move more than a wide one. (See How It Works: Digital Pan/Tilt/Zoom.) If the camera is fully zoomed out, tilt commands do not result... -
Page 58: Camera Zoom
Complete Manual for the IntelliSHOT Auto-Tracking Camera camera zoom Moves the camera in toward the subject or out away from the subject. Autoframing pauses when the camera receives this command. Synopsis camera zoom { in [<speed>] | out [<speed>] | stop | get | set <position> [<speed>] [no_wait] } Options Zooms the camera in... -
Page 59: Camera Ptz-Position
Complete Manual for the IntelliSHOT Auto-Tracking Camera camera ptz-position Specifies a shot by zoom and center coordinates. Autoframing pauses when the camera receives this command. The amount of pan and tilt available depend on the zoom level. A tight shot can move more than a wide one. -
Page 60: Camera Preset
Complete Manual for the IntelliSHOT Auto-Tracking Camera camera preset Moves the camera to the specified preset, or stores the current camera position and type of motion to use, optionally including color and lighting information. Synopsis camera preset { recall | store} <1 - 16> [tri-sync <1 - 24>] [save-ccu] Options recall <1 - 16>] Moves the camera to the specified preset... -
Page 61: Camera Focus
Complete Manual for the IntelliSHOT Auto-Tracking Camera camera focus Changes the camera focus. Synopsis camera focus { near [<speed>] | far [<speed> | stop | mode {get | auto | manual} } Options near Brings the focus nearer to the camera; manual mode only Moves the focus farther from the camera;... -
Page 62: Camera Ccu Get
Complete Manual for the IntelliSHOT Auto-Tracking Camera camera ccu get Returns CCU (lighting and color) information. Entering the command without specifying a parameter returns all current CCU settings. Synopsis camera ccu get <param> auto_white_balance Options Current auto white balance setting (on or off) red_gain Red gain value (integer) blue_gain... -
Page 63: Camera Ccu Set
Complete Manual for the IntelliSHOT Auto-Tracking Camera camera ccu set Sets the specified CCU (lighting) information. Synopsis camera ccu set <param> <value> auto_white_balance Options Sets auto white balance on or off red_gain Sets the red gain value (integer) blue_gain Sets the blue gain value (integer) backlight_compensation Sets backlight compensation on or off auto_iris... -
Page 64: Video Mute
Complete Manual for the IntelliSHOT Auto-Tracking Camera video mute Gets or sets the camera's video mute status. When video is muted, the camera sends blue or black video with an on-screen message stating that video mute is on. This can be desirable when preparing the room, or when privacy is needed. -
Page 65: Audio Commands
Complete Manual for the IntelliSHOT Auto-Tracking Camera Audio Commands The following audio commands are available: audio volume audio mute audio volume Gets or sets the volume of the specified audio channel. Synopsis audio < channel > volume { get | up | down } internal_mic Channels The built-in microphone... -
Page 66: Audio Mute
Complete Manual for the IntelliSHOT Auto-Tracking Camera audio mute Gets or sets the mute status of the specified audio channel. Synopsis audio < channel > mute { get | on | off | toggle } master Channels Applies the command to all audio channels internal_mic The built-in microphone line_in... -
Page 67: Audio Echo-Cancel
Complete Manual for the IntelliSHOT Auto-Tracking Camera audio echo-cancel Gets or sets the echo cancellation status of the specified audio channel. On the IntelliSHOT camera, echo cancellation is available for the internal microphone only. Synopsis audio < channel > echo-cancel { get | on | off | toggle } internal_mic Channels The built-in microphone... -
Page 68: Network And Communication Commands
Complete Manual for the IntelliSHOT Auto-Tracking Camera Network and Communication Commands The following communication-related commands are available: network settings get streaming ip enable streaming settings get network settings get Returns the camera's current network settings and MAC address. Synopsis network settings get network settings get Example Name... -
Page 69: Streaming Settings Get
720p IP Custom_Resolution 1080p/25 IP Bit Rate Mode Variable IP Max Bandwidth 2048 bps IP Compression IP Protocol RTSP IP RTSP Port IT RTMP Port 1935 IP RTSP URL vaddio-huddleshot-stream IP RTSP MTU 1400 IP RTMP Service Service 1 >... -
Page 70: Maintenance And Troubleshooting Commands
Complete Manual for the IntelliSHOT Auto-Tracking Camera Maintenance and Troubleshooting Commands The following commands are available for maintenance and troubleshooting: camera recalibrate network ping system reboot system factory-reset version version Returns the current firmware version. "System version" may show a product family name or more than one product name, as multiple products sometimes use the same firmware. -
Page 71: System Reboot
Complete Manual for the IntelliSHOT Auto-Tracking Camera system reboot Reboots the system either immediately or after the specified delay. Note that a reboot is required when resetting the system to factory defaults (system factory-reset). Synopsis system reboot [<seconds>] Options <seconds> The number of seconds to delay the reboot. -
Page 72: Telnet Information And Session Management Commands
Complete Manual for the IntelliSHOT Auto-Tracking Camera Telnet Information and Session Management Commands The following commands are available for Telnet help and session management: history help exit history Returns the most recently issued commands from the current Telnet session. Since many of the programs read user input a line at a time, the command history is used to keep track of these lines and recall historic information. -
Page 73: Troubleshooting And Care
When the camera doesn't behave as you expect, check the status lights on the front before you do anything else. See Status Lights. Use this table to determine whether it's time to call Vaddio Technical Support. Power and Control What is it doing? Possible causes Check and correct Nothing. -
Page 74: Video And Streaming
Echo cancellation is not Enable echo cancellation (Audio page, enabled. Inputs tab) and select the appropriate master output/AEC reference. Need help? Call Vaddio Technical Support at (+1) 763-971-4400 or 800-572-2011. -
Page 75: Status Lights
Complete Manual for the IntelliSHOT Auto-Tracking Camera Status Lights The lights in the camera's head indicate its current state. Purple – Initializing White – Active Red – Audio is muted Blinking red – Video is muted Yellow – Firmware update is in progress Blinking cyan –... -
Page 76: Operation, Storage, And Care
Complete Manual for the IntelliSHOT Auto-Tracking Camera Operation, Storage, and Care For smears or smudges on the product, wipe with a clean, soft cloth. Use a lens cleaner on the lens. Do not use any abrasive chemicals. Keep this device away from food and liquids. Do not operate or store the device under any of the following conditions: Temperatures above 104°... -
Page 77: Glossary
Field of View (FOV) How wide the video image is. Vaddio measures horizontal field of view. Some manufacturers use diagonal field of view, which yields a bigger number for the same actual image area. Tilt your head to one side and... - Page 78 Complete Manual for the IntelliSHOT Auto-Tracking Camera flombodulator A technically complex item the name of which you can't recall at the moment. frame rate The number of output video frames per second. Different outputs (such as the IP stream and the USB stream) may use different frame rates.
- Page 79 1. The image size. For Vaddio cameras, resolution is expressed in terms of digital TV standards, with 1080p being the default in most cases. Resolution and frame rate are set together on Vaddio cameras. 2. The thing that usually flies out the window by January 10th.
- Page 80 UVC drivers (Universal Video Class) Standard USB video drivers used by Vaddio cameras. They're the reason your computer doesn't have to stop and download a driver when you connect your new Vaddio USB camera to UVC extensions Controls in UVC drivers to allow participants at the far end of a conference to control your camera, if it...
-
Page 81: Photo Credits
Complete Manual for the IntelliSHOT Auto-Tracking Camera Photo Credits This guide may include some of these photos. European Space Agency (ESA) astronaut Samantha Cristoforetti, a Flight Engineer with Expedition 42, photographs the Earth through a window in the Cupola on the International Space Station By NASA - https://blogs.nasa.gov/ISS_Science_Blog/2015/03/06/women-in-space-part-two-whats- gender-got-to-do-with-it/, Public Domain, https://commons.wikimedia.org/w/index.php?curid=38834990 Carl Sagan, Bruce Murray, Louis Friedman (founders) and Harry Ashmore (advisor), on the occasion of... -
Page 82: Index
camera placement 4 camera standby position 34 Index capabilities 1 CCU scenes 27, 30, 56 custom 27, 30, 56 recalling 56 admin password 10-11 CCU settings 26, 28-30, 55, 57-58 changing 11 adjusting 29-30 initial 10 in the web interface 28 AEC 7, 19-20 storing with a preset 26, 55 anatomy of the camera 2... - Page 83 19, 61 information, conference room 13 microphones 61 initial device set-up 8-10 speakers 61 using the Vaddio Device Controller 8, 10 video 34, 59 using the web interface 10 using Vaddio Deployment Tool 9 Initial Persistence (setting) 46...
- Page 84 Complete Manual for the IntelliSHOT Auto-Tracking Camera requirements 4 installation 4 mounting 4 page 11, 13, 19, 21-25, 33, 40 reset See also rebooting; restoring default Audio 19 settings Controls 33 Resolution (IP streaming setting) 24 Diagnostics 40 Responsiveness (setting) 45 Help 40 restoring a configuration 38 Networking 13...
- Page 85 Complete Manual for the IntelliSHOT Auto-Tracking Camera storing a configuration 38 stream viewer 21 streaming 21-25, 63-64 Vaddio Deployment Tool 8-9 configuring 21 check for the latest version 9 enabling/disabling 22 initial device set-up 9 IP 21-22, 24 Vaddio Device Controller 8...
- Page 86 Fax +1.763.971.4464 · Email av.vaddio.support@legrand.com Vaddio is a registered trademark of Legrand AV Inc. All other brand names or marks are used for identification purposes and are trademarks of their respective owners. All patents are protected under existing designations. Other patents pending.
