Extron electronics PC 101 Setup Manual page 2

Installation Steps
1. (Optional) Mount the PC 101 to a rack shelf or furniture using mounting hardware such as an Extron under-desk mount kit.
2. Connect the male IEC connector on the 6-inch input cable (see
source, using a standard IEC power cord.
3. Connect the female IEC connector on the 24-inch output cable (
output cable can be plugged directly into the device being controlled. Alternatively, you can use the provided IEC adapter.
4. Connect a push button or control processor to the Contact In port (
power on and off by contact closure. You can optionally monitor the status by connecting an LED from the +V (+5 volts) pin
to pin 1 of the Tally port (
CAUTION:
• When using the NEMA 5-15R receptacle adapter, connect the equipment only to a nominal 120 VAC source of supply.
• Replacement of fuses should be by service personnel only.
ATTENTION:
• Lorsque vous utilisez la prise de courant NEMA 5-15R, veillez à ne connecter le dispositif qu'à une source d'alimentation
nominale de 120 Vca.
• Le remplacement des fusibles doit être effectué uniquement par un technicien qualifié.
Front Panel Features
CONTACT
A A B B
Figure 2. PC 101 Front Panel
Input Power LED — Lights when the unit is powered
A
on.
Contact LED — Lights when the Contact input port is
B
active.
C Power LED — Lights when AC power is being
supplied to the rear panel Output connector (same
function as the Cable Receptacle Power LED on the
rear panel).
D Test button — This button tests the power connection
to the output. Use a small screwdriver to press this
recessed button to enable AC power to pass to the
output. Power is off by default when AC power is first
applied to the PC 101. Subsequent presses of the
button toggle power to the output on and off.
Power test LED — This LED is off by default when
E
AC power is applied to the unit. Thereafter, the LED
toggles on and off with each press of the Test button.
Extron Headquarters
+800.633.9876 Inside USA/Canada Only
Extron USA - West Extron USA - East
+1.714.491.1500 +1.919.850.1000
+1.714.491.1517 FAX +1.919.850.1001 FAX
©
2017 Extron Electronics All rights reserved. All trademarks mentioned are the property of their respective owners.
E
).
OUTPUT POWER
POWER
TEST
C C D D E E
Extron Europe Extron Asia
+800.3987.6673 +65.6383.4400
Inside Europe Only +65.6383.4664 FAX
+31.33.453.4040
+31.33.453.4050 FAX
figure 1, B
, on the previous page) to a 100-240 VAC power
C
) to the device to be controlled. In many instances the
F ) to enable the PC 101 to turn the Output connector
Application Diagram
GlobalViewer
AV Resource
Management and
Remote Control
Application
PC 101
1 0
Extron R
K E
E A
B R
PC 101
Power Controller
Figure 3. PC 101 Application Using an IPL 250
NOTE:
Use the provided IEC adapter if the PC 101
output cable cannot plug directly into the device to
be controlled.
Extron Japan Extron China
+81.3.3511.7655 +86.21.3760.1568
+81.3.3511.7656 FAX +86.21.3760.1566 FAX
Extron
TLP 710TV
7" TouchLink
Touchpanel
Ethernet
TCP/IP
Network
CO
Rx
Tx
INP
N 2
LA 1
R
PO WE
12V
500 mA
MA X
Ethernet
Relay
C T
N TA
C O
IN
LL Y
M AX TA +V
1
8A
G
1
z
-6 0H
0 ~ 50
0- 24
10
-6 0H z
50
0 ~
0- 24
10
To Display
Adapter
Flat Panel Display
Extron Middle East Extron Australia
+971.4.299.1800 +61.8.8113.6800
+61.8.8351.2511 FAX
+971.4.299.1880 FAX
www.extron.com
Extron
IPL 250
IP Link Control
Processor
LA Y
RE 2
1
IR 2
1
2
M
CO Rx S G LA 4 Y
Tx G RE
M1 CT S S 3
RTS
IR 4
3
3
CO M
Rx S G
Tx G
UT S
3 4
Extron India
1800.3070.3777
(Inside India Only)
+91.80.3055.3777
+91.80.3055.3737 FAX
68-2263-50 Rev. B
07 17
