SHORT LIST OF PARTS

6
12
17
KEY G.C. PART NO
1 309 328
1
2 397 950
2 397 950
3
4
5 a
5 b
6 a
6 b
7
8
8
9
10 397 590
11
11
12
12
13
14 397 585
14
15
16
16
17
18
19
19
20
21
1
2
7
13
18
DESCRIPTION
Main burner POLIDORO ("80 - 80 E")
Main burner POLIDORO ("100 E")
Main injector NP 130 ("80 - 80 E")
Main injector NP 130 ("100 E")
Ignition electrode
Sensing electrode
SIT TANDEM 837 gas valve
SIT SIGMA 845 gas valve
Ignition control box SIT 503 (TANDEM 837)
Ignition control box SIT 537 (SIGMA 845)
Driver PCB
Air pressure switch ("80 - 80 E")
Air pressure switch ("100 E")
Overheat thermostat
Limit thermostat
D.H.W. heat exchanger ("80 - 80 E")
D.H.W. heat exchanger ("100 E")
Heat exchanger ("80 - 80 E")
Heat exchanger ("100 E")
Thermistor
Fan assembly ("80 - 80 E")
Fan assembly ("100 E")
Rotary switch
Circulating pump ("80 - 80 E")
Circulating pump ("100 E")
Divertor valve
Safety valve
C.H. expansion vessel 7 l ("80 - 80 E")
C.H. expansion vessel 10 l ("100 E")
Time clock
Frost stat
3 4
9 - 10 - 21
8
15
14
19
NO OFF
5
11
16
20
Fig. 29
