Summary of Contents for Sime Benchmark
- Page 1 Planet Dewy 90 A - 110 A User instructions...
-
Page 2: Very Important
VERY IMPORTANT! PLEASE MAKE SURE YOUR LOG BOOK ENCLOSED IS FILLED IN CORRECTLY. ALL CORGI REGISTERED INSTALLERS CARRY A CORGI ID CARD. BOTH SHOULD BE RECORDED IN YOUR CENTRAL HEATING LOG BOOK. YOU CAN CHECK YOUR INSTALLER IS CORGI REGISTERED BY CALLING ON 01256 372300... -
Page 3: Lighting And Operation
USER INSTRUCTIONS WARNINGS – In case of fault and/or incorrect equipment operation, deactivate it, without making any repairs or taking any direct action. Contact an authorised technical staff. – The installation of the boiler and any servicing or maintenance job must be carried out by qualified personnel. Under no circumstances, the devices sealed by the manufacturer can be tampered with. - Page 4 “OFF” and close the gas-feeding pipe tap if the boiler remains inoperative for a long SPIA ROSSA SPIA GIALLA RED LED YELLOW LED period CLEANING AND MAINTENANCE It is advisable that the boiler is serviced after 12 months of operation. Preventative maintenance checking of the efficient operation of...
-
Page 5: Logica Remote Control
– Safety thermostat trip (fig. 5) If the safety thermostat trips, the red FLASHING RED LED SPIA ROSSA INTERMITTENTE "35°C" led will start flashing. In order to attempt a boiler restar t, rotate the selector knob to position ( ) and release immediately, returning it to the summer ) or winter ( ) position. -
Page 6: Operation
OPERATION During operation, the cover of the controller must be kept closed. – Selection of operating mode The required operating mode is selected by pressing the relative button with the corre- (grey reference buttons) sponding symbol. The selection is displayed with the symbol Automatic operation: the heating functions automatically in line with the set heating programme. - Page 7 – Presence button If the rooms remain unused for long periods of time, you can reduce the temperature with the presence button, thus saving energy. When the rooms are occupied, they can be heated by re-pressing the presence button. The current selection is shown on the display: Heating to the set temperature Heating to the reduced temperature The current selection becomes permanent in manual mode...
- Page 8 Select the day required for the heating phases (1 = Monday... 7 = Sunday/8 = dome- stic hot water programme) Start of phase 1: heating in set mode End of phase 1: heating in reduced mode Start of phase 2: heating inset mode End of phase 2: heating in reduced mode Start of phase 3: heating inset mode End of phase 3: heating in reduced mode...
- Page 9 – Default value To return the settings to their default values, press buttons simul- taneously for at least 3 seconds. A symbol will appear on the display as confirmation. WARNING The values in the following lines previously entered will be lost. •...
- Page 12 Sime Ltd Westbourne House 80 Bagley Lane, Farsley, Leeds, LS28 5LY Tel. 0870 9911114 - Fax 0870 9911115 www.sime.ltd.uk - e-mail: enquiries@sime.ltd.uk...
