Power up the CS208 / CS216 input expander
DIP
switch setting
= ON
= OFF
6.2.2.1 DIP switch 6 (CS216 only)
To disable the second group of 8 zones on the CS216 input expander, turn DIP switch 6 on. This should be done
only if you need an 8-zone expander in a particular location.
For details on how to install the CS208 / CS216 input expander in the various housings, chapter A-4 Installing a
basic system.
B.6.2
Table 6-1: CS208 / CS216 input expander DIP switches
Starting
Module
zone
number
number
9
23
17
16
25
17
33
18
41
19
49
20
57
21
65
96
73
97
81
98
CS875-575-375-275-175 Installers Manual with CS5500 keypad
DIP
Starting
switch setting
number
89
97
105
113
121
129
137
145
153
161
Module
zone
number
99
100
101
102
103
104
105
106
107
108
