PICO-ITX SBC with AMD® G-Series SoC Processor,
Quick Installation Guide
Package List
HYPER-KBN package includes the following items:
1 x HYPER-KBN Single Board Computer
1 x Specific Heatsink
1 x Audio Cable (P/N: 32000-072100-RS)
1 x SATA with 5V Output Cable Kit (P/N: 32801-000201-100-RS)
1 x RS-232 cable (P/N: 32200-000049-RS)
1 x Utility CD
1 x QIG (Quick Installation Guide)
DDR3, DVI-I/LVDS, GbE, USB 3.0,
SATA 6Gb/s, Audio and RoHS
HYPER-KBN
Version 1.0
Sep 10, 2013.
©2006 Copyright by IEI Technology corp.
All rights reserved.
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for IEI Technology HYPER-KBN
Summary of Contents for IEI Technology HYPER-KBN
- Page 1 SATA 6Gb/s, Audio and RoHS HYPER-KBN Quick Installation Guide Version 1.0 Sep 10, 2013. Package List HYPER-KBN package includes the following items: 1 x HYPER-KBN Single Board Computer 1 x Specific Heatsink 1 x Audio Cable (P/N: 32000-072100-RS) ...
- Page 2 Specifications SoC: AMD® G-Series SoC processor Memory: One 204-pin 1600/1333 single-channel DDR3 SO-DIMM supported (system max. 8GB) BIOS: UEFI BIOS Ethernet: 1 x PCIe GbE by Realtek RTL8111E with ASF 2.0 support Graphics: GPU frequency 300MHz (Radeon™ HD 8310E), DirectX ®...
-
Page 3: Ordering Information
Operation Humidity: 5% ~ 95%, non-condensing Dimensions: 100mm x 72mm Weight GW/NW: 600g / 250g Ordering Information HYPER-KBN-4201-R10: ® PICO-ITX SBC with AMD G-Series GX-420CA SoC processor, DDR3, DVI-I/LVDS, GbE, USB 3.0, SATA 6GB/s, Audio and RoHS ... -
Page 4: Jumpers Setting And Connectors
Jumpers setting and connectors LABEL FUNCTION J_ATX_AT1 AT/ATX mode select switch AUDIO1 Audio connector BAT1 Battery connector Buzzer connector J_CMOS1 Clear CMOS button DIMM1 DDR3 SO-DIMM slot Front panel connector LAN LED connector LVDS1 LVDS LCD connector INV1 LVDS backlight inverter connector PWR_BTN1 Power button connector RST_BTN1... - Page 5 AUDIO1: Audio connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION LINEOUT1R LINE1R GND_AUDIO GND_AUDIO LINEOUT1L LINE1L GND_AUDIO GND_AUDIO FMIC1R FMIC1L BAT1: Battery Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +VBAT CN3: Buzzer Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION SPKR+ SPKR- J_CMOS1: Clear CMOS button PIN NO.
- Page 6 INV1: LVDS Backlight Inverter connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION BRIGHTNESS BKL_PWR ENABKL LVDS1: LVDS LCD connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION DP0_TX0P DP0_TX0N DP0_TX1P DP0_TX1N DP0_TX2P DP0_TX2N DP0_TX3P DP0_TX3N DP0_AUXN DP0_AUXP VCC_LCD VCC_LCD VCC_LCD VCC_LCD PWR_BTN1: Power button connector PIN NO.
- Page 7 COM1: RS-232 serial port connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION NDCD1 NDSR1 NRX1 NRTS1 NTX1 NCTS1 NDTR1 NRI1 SATA_PWR1: SATA power connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION SPI1: SPI Programming connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION SPI_POWER SPI_CS# SPI_DATAIN SPI_CLK...
- Page 8 DVI_1: DVI connector DESCRIPTION DESCRIPTION DDI2_LANE_N0 +5V_DVI DDI2_LANE_P0 CON_DP1_HPD DDI2_LANE_N2 DDI2_LANE_P2 CON_DP1_AUXP CON_DP1_AUXN VGA_VSYNC DDI2_LANE_N1 DDI2_LANE_P1 DDI2_LANE_P3 DDI2_LANE_N3 GND_DVI-I GND_DVI-I GREEN BLUE VGA_HSYNC GND_VGA LAN1: LAN connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION MDIA3- MDIA1+ MDIA3+ MDIA2+ MDIA2- MDIA0- MDIA1- MDIA0+ PWR_CON1: Power connector PIN NO.
- Page 9 USB1: USB connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB_3P0_VCC1 USB_3P0_VCC2 USB2P8_DM0_L USB2P9_DM1_L USB2P8_DP0_L USB2P9_DP1_L USB3P0_RXDN0_C USB3P0_RXDN1_C USB3P0_RXDP0_C USB3P0_RXDP1_C USB3P0_TXDN0_C USB3P0_TXDN1_C USB3P0_TXDP0_C USB3P0_TXDP1_C...
-
Page 10: Board Layout: Jumper And Connector Locations
Board Layout: Jumper and Connector Locations... - Page 11 （Unit: mm）...
