IEI Technology HYPER-KBN User Manual

Pico-itx sbc with amd g-series soc processor, ddr3, dvi-i/lvds, gbe, usb 3.0, sata 6gb/s, audio and rohs
Hide thumbs Also See for HYPER-KBN:
Table of Contents

Advertisement

Quick Links

Download this manual
HYPER-KBN
HYPER-KBN CPU Card
MODEL:
HYP ER-KBN
P ICO-ITX S BC with AMD® G-S e rie s S o C P ro c e s s o r,
DDR3, DVI-I/LVDS , Gb E, US B 3.0,
S ATA 6Gb /s , Au d io a n d Ro HS
Us e r Ma n u a l
Page I
Re v. 1.02 - 27 De c e m b e r, 2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HYPER-KBN and is the answer not in the manual?

Questions and answers

Related Manuals for IEI Technology HYPER-KBN

Summary of Contents for IEI Technology HYPER-KBN

  • Page 1 HYPER-KBN HYPER-KBN CPU Card MODEL: HYP ER-KBN P ICO-ITX S BC with AMD® G-S e rie s S o C P ro c e s s o r, DDR3, DVI-I/LVDS , Gb E, US B 3.0, S ATA 6Gb /s , Au d io a n d Ro HS...
  • Page 2 HYPER-KBN Re vis io n Date Version Changes 27 December, 2013 1.02 Update Appendix D: Example program for WDT 27 November, 2013 1.01 Update Section 2.3: Packing List 21 October, 2013 1.00 Initial release Page II...
  • Page 3 HYPER-KBN Co p yrig h t COP YRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer.

  • Page 4: Table Of Contents

    PTIONAL TEMS 3 CONNECTORS ......................13 3.1 P ............... 14 ERIPHERAL NTERFACE ONNECTORS 3.1.1 HYPER-KBN Layout ..................14 3.1.2 Peripheral Interface Connectors ..............15 3.1.3 External Interface Panel Connectors ............... 16 3.2 I ................. 16 NTERNAL ERIPHERAL ONNECTORS 3.2.1 AT/ATX Mode Select Switch ................16 3.2.2 Audio Connector ....................
  • Page 5 HYPER-KBN 3.2.11 Power Button Connector ................25 3.2.12 Reset Button Connector ................. 26 3.2.13 RS-232 Serial Port Connector ............... 26 3.2.14 SATA 6Gb/s Drive Connector ................ 27 3.2.15 SATA Power Connector .................. 28 3.2.16 SPI Flash Connector ..................29 3.2.17 System Fan Connector ................... 29 3.2.18 USB Connector ....................
  • Page 6 HYPER-KBN 5.2 M ........................50 5.3 A ........................ 51 DVANCED 5.3.1 ACPI Settings ....................52 5.3.2 RTC Wake Settings ................... 52 5.3.3 CPU Configuration ..................54 5.3.4 IDE Configuration ................... 55 5.3.5 USB Configuration ................... 56 5.3.6 F81216 Super IO Configuration ..............57 5.3.6.1 Serial Port 1 Configuration ..............
  • Page 7 HYPER-KBN B.5.2 Backup System ....................102 B.5.3 Restore Your Last Backup ................103 B.5.4 Manual ......................104 B.6 R LAN ........105 ESTORE YSTEMS FROM A INUX ERVER THROUGH B.6.1 Configure DHCP Server Settings ..............106 B.6.2 Configure TFTP Settings ................107 B.6.3 Configure One Key Recovery Server Settings ..........
  • Page 8 HYPER-KBN Lis t o f Fig u re s Figure 1-1: HYPER-KBN ......................... 2 Figure 1-2: Connectors ........................4 Figure 1-3: Dimensions (mm) ......................5 Figure 1-4: Data Flow Diagram ...................... 6 Figure 3-1: Connector and Jumper Locations (Front) ..............14 Figure 3-2: Connector and Jumper Locations (Rear) ...............15...
  • Page 9 HYPER-KBN Figure 4-6: LAN Connection ......................44 Figure 4-7: USB Connector ......................45 Figure 4-8: Heat Sink Retention Screws ..................46 Figure B-1: IEI One Key Recovery Tool Menu ................76 Figure B-2: Launching the Recovery Tool .................81 Figure B-3: Recovery Tool Setup Menu ..................81 Figure B-4: Command Prompt ....................82...
  • Page 10 HYPER-KBN Figure B-33: Recovery Tool Main Menu ...................100 Figure B-34: Restore Factory Default ..................101 Figure B-35: Recovery Complete Window ................102 Figure B-36: Backup System .....................102 Figure B-37: System Backup Complete Window ..............103 Figure B-38: Restore Backup ....................103 Figure B-39: Restore System Backup Complete Window ............104 Figure B-40: Symantec Ghost Window ..................104...
  • Page 11 HYPER-KBN Lis t o f Ta b le s Table 1-1: HYPER-KBN Model Variations ..................2 Table 1-2: Technical Specifications ....................8 Table 3-1: Peripheral Interface Connectors ................16 Table 3-2: Rear Panel Connectors ....................16 Table 3-3: AT/ATX Mode Select Switch Settings ...............17 Table 3-4: Audio Connector Pinouts ..................18...
  • Page 12 HYPER-KBN Lis t o f BIOS Me n u s BIOS Menu 1: Main ........................50 BIOS Menu 2: Advanced ......................51 BIOS Menu 3: ACPI Configuration ....................52 BIOS Menu 4: RTC Wake Settings ....................53 BIOS Menu 5: CPU Configuration ....................54 BIOS Menu 6: IDE Configuration ....................55 BIOS Menu 7: USB Configuration ....................56...

  • Page 13: Introduction

    HYPER-KBN Chapter In tro d u c tio n P a g e 1...

  • Page 14: Introduction

    It supports one 1600/1333 MHz DDR3 SO-DIMM up to 8.0 GB. The HYPER-KBN includes a LVDS connector and a DVI-I connector. Expansion and I/O include two USB 3.0 connectors on the rear panel, two USB 2.0 connectors by pin header and one SATA 6Gb/s connector.

  • Page 15: Features

    HYPER-KBN 1.3 Fe a tu re s Some of the HYPER-KBN motherboard features are listed below:  PICO-ITX form factor with AMD® G-Series SoC processor supports DDR3 1600/1333 MHz memory  12V only single voltage design for AT/ATX power by DC power jack ...

  • Page 16: Connectors

    HYPER-KBN 1.4 Co n n e c to rs The connectors on the HYPER-KBN are shown in the figure below. Figure 1-2: Connectors P a g e 4...

  • Page 17: Dimensions

    HYPER-KBN 1.5 Dim e n s io n s The dimensions of the board are listed below: Figure 1-3: Dimensions (mm) P a g e 5...

  • Page 18: Data Flow

    HYPER-KBN 1.6 Da ta Flow Figure 1-4 shows the data flow between the system chipset, the CPU and other components installed on the motherboard. Figure 1-4: Data Flow Diagram P a g e 6...

  • Page 19: Technical Specifications

    HYPER-KBN 1.7 Te c h n ic a l Sp e c ific a tio n s HYPER-KBN technical specifications are listed below. S p e c ific a tio n HYP ER-KBN S o C AMD® G-Series SoC processor...

  • Page 20: Table 1-2: Technical Specifications

    HYPER-KBN S p e c ific a tio n HYP ER-KBN S e ria l ATA 1 x SATA 6Gb/s with 5V SATA power connector (NO RAID) En viro n m e n ta l a n d P o we r S p e c ific a tio n s...

  • Page 21: Unpacking

    HYPER-KBN Chapter Un p a c kin g P a g e 9...

  • Page 22: Anti Static Precautions

    Only handle the edges of the PCB: Don't touch the surface of the motherboard. Hold the motherboard by the edges when handling. 2.2 Un pa c kin g P re c a u tio n s When the HYPER-KBN is unpacked, please do the following:  Follow the antistatic guidelines above.

  • Page 23: Packing List

    If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the HYPER-KBN was purchased from or contact an IEI sales representative directly by sending an email to sales@iei.com.tw.

  • Page 24: Optional Items

    HYPER-KBN SATA with 5V output cable kit (P/N: 32801-000201-100-RS) RS-232 cable (P/N: 32200-000049-RS) Utility CD One Key Recovery CD Quick Installation Guide 2.4 Op tio n a l Ite m s The following are optional components which may be separately purchased:...

  • Page 25: Connectors

    HYPER-KBN Chapter Co n n e c to rs P a g e 13...

  • Page 26: Peripheral Interface Connectors

    HYPER-KBN 3.1 P e rip h e ra l In te rfa c e Co n n e c to rs This chapter details all the jumpers and connectors. 3.1.1 HYP ER-KBN La yo u t The figures below show all the connectors and jumpers.

  • Page 27: Peripheral Interface Connectors

    HYPER-KBN Figure 3-2: Connector and Jumper Locations (Rear) 3.1.2 P e rip h e ra l In te rfa c e Co n n e c to rs The table below lists all the connectors on the board. Co n n e c to r...

  • Page 28: External Interface Panel Connectors

    3.2 In te rn a l P e rip h e ra l Co n n e c to rs The section describes all of the connectors on the HYPER-KBN. 3.2.1 AT/ATX Mo d e S e le c t S witc h...

  • Page 29: Audio Connector

    HYPER-KBN CN Typ e : switch CN Lo c a tio n : See Figure 3-3 CN S e ttin g s : See Table 3-3 The AT/ATX mode select switch specifies the systems power mode as AT or ATX.

  • Page 30: Battery Connector

    HYPER-KBN The audio connector is connected to external audio devices including speakers and microphones for the input and output of audio signals to and from the system. Figure 3-4: Audio Connector Location P IN NO. DES CRIP TION P IN NO.

  • Page 31: Buzzer Connector

    HYPER-KBN Figure 3-5: Battery Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION +VBAT Table 3-5: Battery Connector Pinouts 3.2.4 Bu zze r Co n n e c to r CN La b e l: CN Typ e : 2-pin wafer...

  • Page 32: Clear Cmos Button

    See Table 3-7 CN S e ttin g s : If the HYPER-KBN fails to boot due to improper BIOS settings, use the button to clear the CMOS data and reset the system BIOS information. The clear CMOS button settings are shown in Table 3-7.

  • Page 33: Ddr3 So-Dimm Slot

    HYPER-KBN 3.2.6 DDR3 S O-DIMM S lo t CN La b e l: DIMM1 DDR3 SO-DIMM slot CN Typ e : CN Lo c a tio n : See Figure 3-8 The DDR3 SO-DIMM slot is for DDR3 SO-DIMM memory module.

  • Page 34: Lan Led Connector

    HYPER-KBN Figure 3-9: Front Panel Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION PWR LED+ PWR LED- HDD LED+ HDD LED- Table 3-8: Front Panel Connector Pinouts 3.2.8 LAN LED Co n n e c to r CN La b e l:...

  • Page 35: Lvds Lcd Connector

    HYPER-KBN Figure 3-10: LAN LED Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION LAN1_AVDD33 LAN1_LED0_LINK_ACT# Table 3-9: LAN LED Connector Pinouts 3.2.9 LVDS LCD Co n n e c to r CN La b e l: LVDS 1 20-pin crimp...

  • Page 36: Lvds Backlight Inverter Connector

    HYPER-KBN Description Description DP0_TX0P DP0_TX0N DP0_TX1P DP0_TX1N DP0_TX2P DP0_TX2N DP0_TX3P DP0_TX3N DP0_AUXN DP0_AUXP VCC_LCD VCC_LCD VCC_LCD VCC_LCD Table 3-10: LVDS Connector Pinouts 3.2.10 LVDS Ba c klig h t In ve rte r Co n n e c to r...

  • Page 37: Power Button Connector

    HYPER-KBN Description BRIGHTNESS BKL_PWR ENABKL Table 3-11: Backlight Inverter Connector Pinouts 3.2.11 P owe r Bu tto n Co n n e c to r CN La b e l: P WR_BTN1 2-pin wafer CN Typ e : See Figure 3-13...

  • Page 38: Reset Button Connector

    HYPER-KBN 3.2.12 Re s e t Bu tto n Co n n e c to r CN La b e l: RS T_BTN1 2-pin wafer CN Typ e : CN Lo c a tio n : See Figure 3-14 See Table 3-13...

  • Page 39: Sata 6Gb/S Drive Connector

    HYPER-KBN The serial connector provides RS-232 connection. Figure 3-15: RS-232 Serial Port Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION NDCD1 NDSR1 NRX1 NRTS1 NTX1 NCTS1 NDTR1 NRI1 Table 3-14: RS-232 Serial Port Connector Pinouts 3.2.14 S ATA 6Gb /s Drive Co n n e c to r...

  • Page 40: Sata Power Connector

    HYPER-KBN Figure 3-16: SATA 6Gb/s Drive Connector Location 3.2.15 S ATA P o we r Co n n e c to r CN La b e l: SATA_PWR1 2-pin wafer CN Typ e : CN Lo c a tio n :...

  • Page 41: Spi Flash Connector

    HYPER-KBN 3.2.16 S P I Fla s h Co n n e c to r CN La b e l: S P I1 6-pin wafer CN Typ e : CN Lo c a tio n : See Figure 3-18 See Table 3-16 CN P in o u ts : The SPI Flash connector is used to flash the BIOS.

  • Page 42: Usb Connector

    HYPER-KBN See Figure 3-19 CN Lo c a tio n : See Table 3-17 CN P in o u ts : The fan connector attaches to a system cooling fan. Figure 3-19: System Fan Connector Locations PIN NO. DESCRIPTION PIN NO.

  • Page 43: External Peripheral Interface Connector Panel

    3.3 Exte rn a l P e rip h e ra l In te rfa c e Co n n e c to r P a n e l Figure 3-21 shows the HYPER-KBN external peripheral interface connector (EPIC) panel.

  • Page 44: Dvi Connector

    HYPER-KBN 3.3.1 DVI Co n n e c to r CN La b e l: DVI_1 24-pin female CN Typ e : CN Lo c a tio n : See Figure 3-21 See Table 3-19 CN P in o u ts : The DVI (Digital Visual Interface) port connects to a monitor that supports DVI video input.

  • Page 45: Power Connectors

    HYPER-KBN See Figure 3-22 and Table 3-20 CN P in o u ts : The LAN connector connects to a local network. Figure 3-22: LAN Connector Description Description MDIA3- MDIA1+ MDIA3+ MDIA2+ MDIA2- MDIA0- MDIA1- MDIA0+ Table 3-20: LAN Pinouts...

  • Page 46: Usb Connectors

    CN P in o u ts : See Table 3-22 The HYPER-KBN has two external USB 3.0 ports. The USB 3.0 ports are for attaching USB 3.0 peripheral devices to the system. The pinouts of USB 3.0 connectors are shown below.

  • Page 47: Installation

    HYPER-KBN Chapter In s ta lla tio n P a g e 35...

  • Page 48: Anti - Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the HYPER-KBN. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the HYPER-KBN or any other electrical component is handled, the following anti-static precautions are strictly adhered to.
  • Page 49  Turn all power to the HYPER-KBN off: When working with the HYPER-KBN, make sure that it is disconnected from all power supplies and that no electricity is being fed into the system. Before and during the installation of the HYPER-KBN DO NOT: ...

  • Page 50: So-Dimm Installation

    HYPER-KBN. Please make sure the purchased SO-DIMM complies with the memory specifications of the HYPER-KBN. SO-DIMM specifications compliant with the HYPER-KBN are listed in the specification table of Chapter 1. To install an SO-DIMM, please follow the steps below and refer to Figure 4-1.

  • Page 51: Internal Peripheral Device Connections

    4.4.1 Au d io Kit In s ta lla tio n The Audio Kit that came with the HYPER-KBN connects to the audio connector on the HYPER-KBN. The audio kit consists of three audio jacks. Mic-in connects to a microphone.

  • Page 52: Sata Drive Connection

    0: 4.4.2 S ATA Drive Co n n e c tio n The HYPER-KBN is shipped with a SATA drive cable. To connect the SATA drive to the connector, please follow the steps below. S te p 1: Locate the SATA connector and the SATA power connector.

  • Page 53: Single Rs-232 Cable

    HYPER-KBN S te p 4: To remove the SATA cable from the SATA connector, press the clip on the connector at the end of the cable. S te p 0: 4.4.3 S in g le RS -232 Ca ble The single RS-232 cable consists of one serial port connector attached to a serial communications cable that is then attached to a D-sub 9 male connector.

  • Page 54: External Peripheral Interface Connection

    4.5.1 DVI Dis p la y De vic e Co n n e c tio n The HYPER-KBN has a single female DVI connector on the external peripheral interface panel. The DVI connector is connected to a digital display device. To connect a digital display device to the HYPER-KBN, please follow the instructions below.

  • Page 55: Lan Connection

    Locate the RJ-45 connector. The location of the LAN connector is shown in Chapter 3. S te p 2: Align the connector. Align the RJ-45 connector on the LAN cable with the RJ-45 connectors on the HYPER-KBN. See Figure 4-6. P a g e 43...

  • Page 56: Usb Connection

    HYPER-KBN Figure 4-6: LAN Connection Insert the LAN cable RJ-45 connector. Once aligned, gently insert the LAN S te p 3: cable RJ-45 connector into the on-board RJ-45 connector. 4.5.3 US B Co n n e c tio n The external USB Series "A" receptacle connectors provide easier and quicker access to external USB devices.

  • Page 57: Heat Sink Enclosure

    The heat sink ensures the system remains cool and does not need addition heat sinks to cool the system. The HYPER-KBN is shipped with a specific heat sink module and four retention screws, four hex head studs and four intermediate poles. To install the heat sink module, see Figure 4-8 below.

  • Page 58: Figure 4-8: Heat Sink Retention Screws

    HYPER-KBN Figure 4-8: Heat Sink Retention Screws P a g e 46...

  • Page 59: Bios

    HYPER-KBN Chapter BIOS P a g e 47...

  • Page 60: Introduction

    HYPER-KBN 5.1 In tro d u c tio n The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. NOTE: Some of the BIOS options may vary throughout the life cycle of the product and are subject to change without prior notice.

  • Page 61: Getting Help

    HYPER-KBN Ke y Fu n c tio n Decrease the numeric value or make changes Page up Move to the next page Page down Move to the previous page Main Menu – Quit and do not save changes into CMOS...

  • Page 62: Main

    HYPER-KBN The following sections completely describe the configuration options found in the menu items at the top of the BIOS screen and listed above. 5.2 Ma in The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered.

  • Page 63: Advanced

    HYPER-KBN  S ys te m Da te [xx/xx/xx] Use the System Date option to set the system date. Manually enter the day, month and year.  S ys te m Tim e [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds.

  • Page 64: Acpi Settings

    HYPER-KBN 5.3.1 ACP I S e ttin g s The ACPI Settings menu (BIOS Menu 3) configures the Advanced Configuration and Power Interface (ACPI) options. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Advanced ACPI Settings ACPI Sleep State [S3 only(Suspend to…]...

  • Page 65: Bios Menu 4: Rtc Wake Settings

    HYPER-KBN Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Advanced RTC Wake Settings Enable or disable System wake on alarm event. When Wake system with Fixed Time [Disabled] enabled, System will wake on the date::hr::min::sec specified ---------------------- : Select Screen ↑...

  • Page 66: Cpu Configuration

    HYPER-KBN 5.3.3 CP U Co n fig u ra tio n Use the CPU Configuration menu (BIOS Menu 5) to view detailed CPU specifications and configure the CPU. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Advanced CPU Configuration...

  • Page 67: Ide Configuration

    HYPER-KBN  Active three of the processor cores Three cores per processor  cores Active two of the processor cores processor  core Active one of the processor cores processor 5.3.4 IDE Co n fig u ra tio n Use the IDE Configuration menu (BIOS Menu 6) to change and/or set the configuration of the SATA devices installed in the system.

  • Page 68: Usb Configuration

    HYPER-KBN  Configures SATA devices as normal IDE device. EFAULT  AHCI Configures SATA devices as AHCI device. 5.3.5 US B Co n fig u ra tio n Use the USB Configuration menu (BIOS Menu 7) to read USB configuration information and configure the USB settings.

  • Page 69: F81216 Super Io Configuration

    HYPER-KBN keyboard can control the system even when there is no USB driver loaded onto the system.  Enabled Legacy USB support enabled EFAULT  Disabled Legacy USB support disabled  Auto Legacy USB support disabled if no USB devices are connected 5.3.6 F81216 S u pe r IO Co nfig u ra tio n...

  • Page 70: Serial Port 1 Configuration

    HYPER-KBN 5.3.6.1 S e ria l P o rt 1 Co n fig u ra tio n Use the Serial Port 1 Configuration menu (BIOS Menu 13) to configure the serial port 1. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.

  • Page 71: Serial Port Console Redirection

    HYPER-KBN  Serial Port I/O port address is 2F8h and the IO=2F8h; IRQ=3, 4,5,6,7,10,11,12 interrupt address is IRQ3,4,5,6,7,10,11,12  IO=3E8h; IRQ=3, Serial Port I/O port address is 3E8h and the interrupt address is IRQ3,4,5,6,7,10,11,12 4,5,6,7,10,11,12  IO=2E8h; IRQ=3, Serial Port I/O port address is 2E8h and the...

  • Page 72: Console Redirection Settings

    HYPER-KBN 5.3.7.1 Co n s o le Re d ire c tio n S e ttin g s The Console Redirection Settings menu (BIOS Menu 11) allows the console redirection options to be configured. The option is active when Console Redirection option is enabled.
  • Page 73 HYPER-KBN  Bits p e r s e c o n d [115200] Use the Bits per second option to specify the serial port transmission speed. The speed must match the other side. Long or noisy lines may require lower speeds.

  • Page 74: Chipset

    HYPER-KBN  Sto p Bits [1] Use the Stop Bits option to specify the number of stop bits used to indicate the end of a serial data packet. Communication with slow devices may require more than 1 stop bit. ...

  • Page 75: Gfx Configuration

    HYPER-KBN 5.4.1 GFX Co n fig u ra tio n Use the GFX Configuration menu (BIOS Menu 13) to configure the video device connected to the system. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Advanced GFX Configuration...

  • Page 76: Bios Menu 14: South Bridge Configuration

    HYPER-KBN Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Chipset Auto Power Button Function [Disabled(ATX)] Restore AC Power Loss [Last State] HD Audio Azalia Device [Enabled] --------------------- : Select Screen Azalia Front Panel [Auto] ↑ ↓: Select Item Enter Select +/-: Change Opt.

  • Page 77: North Bridge Configuration

    HYPER-KBN  Aza lia Fro n t P a n e l [En a b le d ] Use the Azalia Front Panel option to enable or disable the front panel audio controller.  The front panel audio controller will be enabled if Auto present, disabled otherwise.

  • Page 78: Vuma Int15 Config Select

    HYPER-KBN  1333MHZ  1600MHZ  1866MHZ 5.4.4 VUMA INT15 Co n fig S e le c t Use the VUMA INT15 Config Select menu (BIOS Menu 16) to configure the video device connected to the system. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
  • Page 79 HYPER-KBN  LVDS P a n e l Co n fig S e le c t [LVDS Op tio n 1 800x600] Use the LVDS Panel Config Select BIOS option to select the type of flat panel connected to the system. Configuration options are listed below.

  • Page 80: Boot

    HYPER-KBN 5.5 Bo o t Use the Boot menu (BIOS Menu 17) to configure system boot options. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Boot Configuration Select the keyboard...
  • Page 81 HYPER-KBN  Qu ie t Bo o t [En a b le d ] Use the Quiet Boot BIOS option to select the screen display when the system boots.  Normal POST messages displayed Disabled  Enabled OEM Logo displayed instead of POST messages EFAULT ...

  • Page 82: Security

    HYPER-KBN  Bo o t Op tio n P rio rity Use the Boot Option Priority function to set the system boot sequence from the available devices. The drive sequence also depends on the boot sequence in the individual device section.

  • Page 83: Bios Menu 19:Exit

    HYPER-KBN Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Save Changes and Reset Reset the system after Discard Changes and Reset saving the changes. Restore Defaults Save as User Defaults...

  • Page 84: A Bios Menu Options

    HYPER-KBN Ap p e n d ix BIOS Me n u Op tio n s P a g e 72...
  • Page 85 HYPER-KBN  BIOS Information .........................50  System Date [xx/xx/xx] ......................51  System Time [xx:xx:xx] .......................51  ACPI Sleep State [S3 only (Suspend to RAM)] ..............52  Wake system with Fixed Time [Disabled] ................53  SVM Mode [Enabled] ......................54  Core Leveling Mode [Automatic mode] ................54 ...
  • Page 86 HYPER-KBN  Administrator Password .....................70  User Password ........................70  Save Changes and Reset ....................71  Discard Changes and Reset ....................71  Restore Defaults ........................71  Save as User Defaults ......................71  Restore User Defaults ......................71 P a g e 74...

  • Page 87: B One Key Recovery

    HYPER-KBN Ap p e n d ix On e Ke y Re c o ve ry P a g e 75...

  • Page 88: One Key Recovery Introduction

    HYPER-KBN B.1 On e Ke y Re c o ve ry In tro d u c tio n The IEI one key recovery is an easy-to-use front end for the Norton Ghost system backup and recovery tool. This tool provides quick and easy shortcuts for creating a backup and reverting to that backup or reverting to the factory default settings.

  • Page 89: System Requirement

    HYPER-KBN After completing the five initial setup procedures as described above, users can access the recovery tool by pressing <F3> while booting up the system. The detailed information of each function is described in Section B.5. NOTE: The initial setup procedures for Linux system are described in Section B.3.

  • Page 90: Supported Operating System

    HYPER-KBN partitions. Please take the following table as a reference when calculating the size of the partition. OS Image after Ghost Compression Ratio Windows® 7 7 GB 5 GB Windows® XPE 776 MB 560 MB Windows® CE 6.0 36 MB...

  • Page 91: Setup Procedure For Windows

    HYPER-KBN Ubuntu 8.10 (Intrepid) Ubuntu 7.10 (Gutsy) Ubuntu 6.10 (Edgy) Debian 5.0 (Lenny) Debian 4.0 (Etch) SuSe 11.2 SuSe 10.3 NOTE: Installing unsupported OS versions may cause the recovery tool to fail. B.2 S e tu p P ro c e d u re fo r Win d ows Prior to using the recovery tool to backup or restore, a few setup procedures are required.

  • Page 92: Hardware And Bios Setup

    HYPER-KBN B.2.1 Ha rdwa re a n d BIOS S e tu p Make sure the system is powered off and unplugged. S te p 1: Install a hard drive or SSD in the system. An unformatted and unpartitioned disk S te p 2: is recommended.

  • Page 93: Figure B-2: Launching The Recovery Tool

    HYPER-KBN Figure B-2: Launching the Recovery Tool S te p 3: The recovery tool setup menu is shown as below. Figure B-3: Recovery Tool Setup Menu S te p 4: Press <6> then <Enter>. P a g e 81...

  • Page 94: Figure B-4: Command Prompt

    HYPER-KBN Figure B-4: Command Prompt S te p 5: The command prompt window appears. Type the following commands (marked in red) to create two partitions. One is for the OS installation; the other is for saving recovery files and images which will be an invisible partition.

  • Page 95: Figure B-5: Partition Creation Commands

    HYPER-KBN Figure B-5: Partition Creation Commands P a g e 83...

  • Page 96: Install Operating System, Drivers And Applications

    HYPER-KBN NOTE: Use the following commands to check if the partitions were created successfully. S te p 6: Press any key to exit the recovery tool and automatically reboot the system. Please continue to the following procedure: Build the Recovery Partition.S t e p 0 :...

  • Page 97: Building The Recovery Partition

    HYPER-KBN B.2.4 Bu ild in g th e Re c o ve ry P a rtitio n Put the recover CD in the optical drive. S te p 1: Start the system. S te p 2: S te p 3: Boot the system from the recovery CD.

  • Page 98: Figure B-8: Building The Recovery Partition

    HYPER-KBN S te p 5: The Symantec Ghost window appears and starts configuring the system to build a recovery partition. In this process the partition created for recovery files in Section B.2.2 is hidden and the recovery tool is saved in this partition.

  • Page 99: Create Factory Default Image

    HYPER-KBN B.2.5 Cre a te Fa c to ry De fa u lt Im a g e NOTE: Before creating the factory default image, please configure the system to a factory default environment, including driver and application installations. To create a factory default image, please follow the steps below.

  • Page 100: Figure B-12: About Symantec Ghost Window

    HYPER-KBN Figure B-12: About Symantec Ghost Window Use mouse to navigate to the option shown below (Figure B-13). S te p 4: Figure B-13: Symantec Ghost Path S te p 5: Select the local source drive (Drive 1) as shown in Figure B-14. Then click OK.

  • Page 101: Figure B-14: Select A Local Source Drive

    HYPER-KBN Figure B-14: Select a Local Source Drive S te p 6: Select a source partition (Part 1) from basic drive as shown in Figure B-15. Then click OK. Figure B-15: Select a Source Partition from Basic Drive Select 1.2: [Recovery] NTFS drive and enter a file name called S te p 7: (Figure B-16).

  • Page 102: Figure B-16: File Name To Copy Image To

    HYPER-KBN Figure B-16: File Name to Copy Image to When the Compress Image screen in Figure B-17 prompts, click High to make S te p 8: the image file smaller. Figure B-17: Compress Image P a g e 90...

  • Page 103: Figure B-18: Image Creation Confirmation

    HYPER-KBN The Proceed with partition image creation window appears, click Yes to S te p 9: continue. Figure B-18: Image Creation Confirmation The Symantec Ghost starts to create the factory default image (Figure B-19). S te p 10: Figure B-19: Image Creation Complete When the image creation completes, a screen prompts as shown in Figure B-20.

  • Page 104: Auto Recovery Setup Procedure

    HYPER-KBN S te p 12: The recovery tool main menu window is shown as below. Press any key to reboot the system. S t e p 0 : Figure B-21: Press Any Key to Continue B.3 Au to Re c o ve ry S e tu p P ro c e d u re...

  • Page 105: Figure B-22: Auto Recovery Utility

    HYPER-KBN Figure B-22: Auto Recovery Utility Reboot the system from the recovery CD. When prompted, press any key to S te p 3: boot from the recovery CD. It will take a while to launch the recovery tool. Please be patient!

  • Page 106: Figure B-25: Building The Auto Recovery Partition

    HYPER-KBN S te p 5: The Symantec Ghost window appears and starts configuring the system to build an auto recovery partition. In this process the partition created for recovery files in Section B.2.2 is hidden and the auto recovery tool is saved in this partition.

  • Page 107: Figure B-27: Image Creation Complete

    HYPER-KBN The Symantec Ghost starts to create the factory default image (Figure B-27). S te p 7: Figure B-27: Image Creation Complete S te p 8: After completing the system configuration, press any key in the following window to restart the system.

  • Page 108: Setup Procedure For Linux

    HYPER-KBN BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit iEi Feature  Auto Recovery Function [Enabled] Recover from PXE [Disabled]  Select Screen ↑ ↓ Select Item Enter Go to SubScreen General Help Save and Exit Exit v02.61 ©Copyright 1985-2006, American Megatrends, Inc.

  • Page 109: Figure B-29: Partitions For Linux

    HYPER-KBN Install Linux operating system. Make sure to install GRUB (v0.97 or earlier) S te p 2: MBR type and Ext3 partition type. Leave enough space on the hard drive to create the recover partition later. NOTE: If the Linux OS is not installed with GRUB (v0.97 or earlier) and Ext3, the Symantec Ghost may not function properly.

  • Page 110: Figure B-30: Manual Recovery Environment For Linux

    HYPER-KBN DISKPART>create part pri size= DISKPART>assign letter=N DISKPART>exit system32>format N: /fs:ntfs /q /v:Recovery /y system32>exit Build the recovery partition. Press any key to boot from the recovery CD. It will S te p 4: take a while to launch the recovery tool. Please be patient. When the recovery tool setup menu appears, type <3>...

  • Page 111: Figure B-31: Access Menu.lst In Linux (Text Mode)

    HYPER-KBN Figure B-31: Access menu.lst in Linux (Text Mode) Modify the menu.lst as shown below. S te p 6: The recovery tool menu appears. (Figure B-32) S te p 7: Figure B-32: Recovery Tool Menu Create a factory default image. Follow...

  • Page 112: Recovery Tool Functions

    HYPER-KBN B.5 Re c o ve ry To o l Fu n c tio n s After completing the initial setup procedures as described above, users can access the recovery tool by pressing <F3> while booting up the system. However, if the setup procedure in Section B.3 has been completed and the auto recovery function is enabled,...

  • Page 113: Factory Restore

    HYPER-KBN WARNING: All data in the system will be deleted during the system recovery. Please backup the system files before restoring the system (either Factory Restore or Restore Backup). B.5.1 Fa c to ry Re s to re To restore the factory default image, please follow the steps below.

  • Page 114: Backup System

    HYPER-KBN Figure B-35: Recovery Complete Window B.5.2 Ba c ku p S ys te m To backup the system, please follow the steps below. Type <2> and press <Enter> in the main menu. S te p 1: The Symantec Ghost window appears and starts to backup the system. A S te p 2: backup image called iei_user.GHO is created in the hidden Recovery partition.

  • Page 115: Restore Your Last Backup

    HYPER-KBN Figure B-37: System Backup Complete Window B.5.3 Re s to re Yo u r La s t Ba c ku p To restore the last system backup, please follow the steps below. Type <3> and press <Enter> in the main menu.

  • Page 116: Manual

    HYPER-KBN Figure B-39: Restore System Backup Complete Window B.5.4 Ma n u a l To restore the last system backup, please follow the steps below. Type <4> and press <Enter> in the main menu. S te p 4: The Symantec Ghost window appears. Use the Ghost program to backup or S te p 5: recover the system manually.

  • Page 117: Restore Systems From A Linux Server Through Lan

    HYPER-KBN B.6 Re s to re S ys te m s fro m a Lin u x S e rve r thro u g h LAN The One Key Recovery allows a client system to automatically restore to a factory default image saved in a Linux system (the server) through LAN connectivity after encountering a Blue Screen of Death (BSoD) or a hang for around 10 minutes.

  • Page 118: Configure Dhcp Server Settings

    HYPER-KBN B.6.1 Co n fig u re DHCP S e rve r S e ttin g s Install the DHCP S te p 1: #yum install dhcp (CentOS, commands marked in red) #apt-get install dhcp3-server (Debian, commands marked in blue) Confirm the operating system default settings: dhcpd.conf.

  • Page 119: Configure Tftp Settings

    HYPER-KBN filename “pxelinux.0”; B.6.2 Co n fig u re TFTP S e ttin g s S te p 1: Install the tftp, httpd and syslinux. #yum install tftp-server httpd syslinux (CentOS) #apt-get install tftpd-hpa xinetd syslinux (Debian) S te p 2: Enable the TFTP server by editing the “/etc/xinetd.d/tftp”...

  • Page 120: Configure One Key Recovery Server Settings

    HYPER-KBN Debian Replace the TFTP settings from “inetd” to “xinetd” and annotate the “inetd” by adding “#”. #vi /etc/inetd.conf Modify: #tftp dgram udp wait root /usr/sbin..(as shown below) #vi /etc/xinetd.d/tftp B.6.3 Co n fig u re On e Ke y Re c o ve ry S e rve r S e ttin g s Copy the Utility/RECOVERYR10.TAR.BZ2 package from the One Key...

  • Page 121: Start The Dhcp, Tftp And Http

    HYPER-KBN B.6.4 Sta rt th e DHCP, TFTP a n d HTTP Start the DHCP, TFTP and HTTP. For example: CentOS #service xinetd restart #service httpd restart #service dhcpd restart Debian #/etc/init.d/xinetd reload #/etc/init.d/xinetd restart #/etc/init.d/dhcp3-server restart B.6.5 Cre a te S ha re d Dire c to ry S te p 1: Install the samba.

  • Page 122: Setup A Client System For Auto Recovery

    HYPER-KBN Modify: [image] comment = One Key Recovery path = /share/image browseable = yes writable = yes public = yes create mask = 0644 directory mask = 0755 S te p 4: Edit “/etc/samba/smb.conf” for your environment. For example: Modify the hostname...
  • Page 123 HYPER-KBN Continue to configure the Boot Option Priorities BIOS option of the client S te p 2: system: Boot Option #1  remain the default setting to boot from the original OS. Boot Option #2  select the boot from LAN option.
  • Page 124 HYPER-KBN NOTE: A firewall or a SELinux is not in use in the whole setup process. If there is a firewall or a SELinux protecting the system, modify the configuration information to accommodate them. P a g e 112...

  • Page 125: Other Information

    HYPER-KBN B.7 Oth e r In fo rm a tio n B.7.1 Us in g AHCI Mo d e o r ALi M5283 / VIA VT6421A Co n tro lle r When the system uses AHCI mode or some specific SATA controllers such as ALi M5283 or VIA VT6421A, the SATA RAID/AHCI driver must be installed before using one key recovery.
  • Page 126 HYPER-KBN When the following window appears, press <S> to select “Specify Additional S te p 5: Device”. In the following window, select a SATA controller mode used in the system. Then S te p 6: press <Enter>. The user can now start using the SATA HDD.

  • Page 127: System Memory Requirement

    HYPER-KBN S te p 7: After pressing <Enter>, the system will get into the recovery tool setup menu. Continue to follow the setup procedure from Step 4 in Section B.2.2 Create Partitions to finish the whole setup process. S t e p 0 : B.7.2 S ys te m Me m o ry Re q u ire m e n t...

  • Page 128: C Terminology

    HYPER-KBN Ap p e n d ix Te rm in o lo g y P a g e 116...
  • Page 129 HYPER-KBN AC ’97 Audio Codec 97 (AC’97) refers to a codec standard developed by Intel® in 1997. ACPI Advanced Configuration and Power Interface (ACPI) is an OS-directed configuration, power management, and thermal management interface. AHCI Advanced Host Controller Interface (AHCI) is a SATA Host controller register-level interface.
  • Page 130 HYPER-KBN computer is usually a male DE-9 connector. The Digital-to-Analog Converter (DAC) converts digital signals to analog signals. Double Data Rate refers to a data bus transferring data on both the rising and falling edges of the clock signal. Direct Memory Access (DMA) enables some peripheral devices to bypass the system processor and communicate directly with the system memory.
  • Page 131 HYPER-KBN PCIe PCI Express (PCIe) is a communications bus that uses dual data lines for full-duplex (two-way) serial (point-to-point) communications between the SBC components and/or expansion cards and the SBC chipsets. Each line has a 2.5 Gbps data transmission rate and a 250 MBps sustained data transfer rate.
  • Page 132 HYPER-KBN USB 2.0 supports 480Mbps data transfer rates. The Video Graphics Array (VGA) is a graphics display system developed by IBM. P a g e 120...

  • Page 133: D Watchdog Timer

    HYPER-KBN Ap p e n d ix Wa tc h d o g Tim e r P a g e 121...
  • Page 134 HYPER-KBN NOTE: The following discussion applies to DOS environment. IEI support is contacted or the IEI website visited for specific drivers for more sophisticated operating systems, e.g., Windows and Linux. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash.
  • Page 135 HYPER-KBN //Key Time mov edi,0xFED80B04h mov ebx,0x00h // 0x0000~0xFFFF mov es:dword ptr [edi],ebx //Start WDT mov edi,0xFED80B00h mov ebx,0x81h mov es:dword ptr [edi],ebx P a g e 123...

  • Page 136: E Hazardous Materials Disclosure

    HYPER-KBN Ap p e n d ix Ha za rd o u s Ma te ria ls Dis c lo s u re P a g e 124...

  • Page 137: Hazardous Material Disclosure Table For Ipb Products Certified As R Ohs

    HYPER-KBN E.1 Ha za rd o u s Ma te ria l Dis c lo s ure Ta b le fo r IP B P ro d u c ts Ce rtifie d a s Ro HS Co m p lia n t Un d e r 2002/95/EC With o u t...
  • Page 138 HYPER-KBN Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated (Pb) (Hg) (Cd) Chromium Biphenyls Diphenyl Ethers (CR(VI)) (PBB) (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply Assemblies Battery...
  • Page 139 HYPER-KBN 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11363-2006 标准规定的限量要求。...
