FastTrak TX4650, TX2650 User Manual
Creating Your Logical Drive
You will now use the onboard FastBuild BIOS utility to create a logical drive with
the attached drives.
For an explanation of the logical drive concepts, see Chapter 6
1. Boot your system. If this is the first time you have booted with the FastTrak
card and drives installed, the Promise onboard BIOS will display the
following screen (below).
2. Press the Ctrl-F keys to display the FastBuild Utility Main Menu (below).
3. Press 2 on the Main Menu screen to display the Define LD Menu (below).
You can omit this step, proceed with the WebPAM installation on
page 16, then create your logical drive using WebPAM. See
"Creating a Logical Drive" on page 80.
Note
12
