2. Hardware Installation

I o
NSTALLATIoN vervIew
The diagram below gives you an idea of how Sigma connects to your other studio gear.
Converters
Mix outputs from Sigma,
printing back into DAW
Digital
audio
to and
from
DAW
Analogue Audio
Analogue outboard
(if present)
Analogue Inputs
to Sigma
Main Mon
output
Alt Mon
output
Automation control
data over Ethernet
H/P
output
Ext input
Page 7
Ethernet
router
Ethernet switch
Control
surface
H/P line-level feed
to live room
