Appendices

A A - C
PPeNDIX oNNeCTorS
'CHIP' – Channel Input Connectors †
Connector Type: 25-way D-type Female
Pin Description
1 Channel 4 Right (+ve)
14 Channel 4 Right (–ve)
2 0V
15 Channel 4 Left (+ve)
3 Channel 4 Left (–ve)
16 0V
4 Channel 3 Right (+ve)
17 Channel 3 Right (–ve)
5 0V
18 Channel 3 Left (+ve)
6 Channel 3 Left (–ve)
19 0V
7 Channel 2 Right (+ve)
20 Channel 2 Right (–ve)
8 0V
21 Channel 2 Left (+ve)
9 Channel 2 Left (–ve)
22 0V
10 Channel 1 Right (+ve)
23 Channel 1 Right (–ve)
11 0V
24 Channel 1 Left (+ve)
12 Channel 1 Left (–ve)
25 0V
13 n/c
eXT, rTNS, T/b †
Connector Type: 25-way D-type Female
Pin Description
1 n/c
14 n/c
2 0V
15 Talkback Mic Input (+ve)
3 Talkback Mic Input (–ve)
16 0V
4 Mix B Insert Return Right (+ve)
17 Mix B Insert Return Right (–ve)
5 0V
18 Mix B Insert Return Left (+ve)
6 Mix B Insert Return Left (–ve)
19 0V
7 Mix A Insert Return Right (+ve)
20 Mix A Insert Return Right (–ve)
8 0V
21 Mix A Insert Return Left (+ve)
9 Mix A Insert Return Left (–ve)
22 0V
10 External Input Right (+ve)
23 External Input Right (–ve)
11 0V
24 External Input Left (+ve)
12 External Input Left (–ve)
25 0V
13 n/c
†
: D-type connector wiring follows AES59 ('Tascam') standard and binding posts are 4-40 UNC thread.
& P
INoUTS
'CHoP' – Channel output Connectors †
Connector Type:
Pin Description
1 Channel 4 Right (+ve)
14 Channel 4 Right (–ve)
2 0V
15 Channel 4 Left (+ve)
3 Channel 4 Left (–ve)
16 0V
4 Channel 3 Right (+ve)
17 Channel 3 Right (–ve)
5 0V
18 Channel 3 Left (+ve)
6 Channel 3 Left (–ve)
19 0V
7 Channel 2 Right (+ve)
20 Channel 2 Right (–ve)
8 0V
21 Channel 2 Left (+ve)
9 Channel 2 Left (–ve)
22 0V
10 Channel 1 Right (+ve)
23 Channel 1 Right (–ve)
11 0V
24 Channel 1 Left (+ve)
12 Channel 1 Left (–ve)
25 0V
13 n/c
mIX b, SeNDS, H/P †
D-sub to
Connector Type:
XLR-F
Loom Pin Description
1 Headphone Right (+ve, line level)
XLR-8 14 Headphone Right (–ve, line level)
2 0V
15 Headphone Left (+ve, line level)
XLR-7 3 Headphone Left (–ve, line level)
16 0V
4 Mix B Insert Send Right (+ve)
XLR-6 17 Mix B Insert Send Right (–ve)
5 0V
18 Mix B Insert Send Left (+ve)
XLR-5 6 Mix B Insert Send Left (–ve)
19 0V
7 Mix A Insert Send Right (+ve)
XLR-4 20 Mix A Insert Send Right (–ve)
8 0V
21 Mix A Insert Send Left (+ve)
XLR-3 9 Mix A Insert Send Left (–ve)
22 0V
10 Mix B Output Right (+ve)
XLR-2 23 Mix B Output Right (–ve)
11 0V
24 Mix B Output Left (+ve)
XLR-1 12 Mix B Output Left (–ve)
25 0V
13 n/c
Page 66
25-way D-type Female
D-sub to
25-way D-type Female
XLR-M
Loom
XLR-8
XLR-7
XLR-6
XLR-5
XLR-4
XLR-3
XLR-2
XLR-1
main monitor output
Connector Type: XLR 3-pin Male
Pin Description
1 0V (Chassis)
2 Signal +ve
3 Signal –ve
Alternate monitor output
Connector Type: XLR 3-pin Male
Pin Description
1 0V (Chassis)
2 Signal +ve
3 Signal –ve
mix A output
Connector Type: XLR 3-pin Male
Pin Description
1 0V (Chassis)
2 Signal +ve
3 Signal –ve
Headphones
Connector Type: 0.25" Stereo Jack
Description
Tip Signal Left
Ring Signal Right
Sleeve 0V (Chassis)
iJack Input
Connector Type: 3.5mm Stereo Jack
Description
Tip Signal Left
Ring Signal Right
Sleeve 0V (Chassis)
Foot Switch Input
Connector Type: 0.25" Stereo Jack
Description
Tip Signal
Ring 0V (Chassis)
Sleeve 0V (Chassis)
