CHANNeLS

Solo Cut
Button Button
The CHANNeLS page controls functions such as mix bus routing or mono/stereo selection for each channel.
As with the mASTer page, many of these functions are reflected on the Sigma front panel.
Each channel on the Sigma front panel displays the input signal level (pre-fader) with a six segment LED
display.
Sigma has 16 input channels that are individually switchable via the moNo button in the web browser. When
operating in mono, a pan control will appear.
Just above the mix bus buttons, you'll see a value in dBs for each channel. This is the analogue "fader" gain
readout for each channel and is useful for checking that the DAW's faders are controlling the analogue gains
of Sigma.
Sigma has 2 mix busses: A and b. Each channel can be routed to either or both busses using the mIX A and mIX b buttons.
Each channel can be renamed simply by clicking in and typing in the relevant box.
The SoLo button performs a solo-in-place, cutting all other channels. CUT mutes the channel's output.
The SOLO function can be changed from solo-in-place to an AFL style solo, using Mix Bus B as an AFL bus. Please see
the SETTINGS section for more information.
Channel Mix Bus
Name Assignments
Analogue Gain Pan
Readout Position
Page 29
Mono
Button
Sigma
Front Panel
Channel
