2.4

Connectors

Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table of connectors on the hardware.
Connector
CN1
CN2
CN3
CN4
CN5
CN6
CN9
CN11
CN12
CN13
CN14
FAN1
COM1
SATA1
USB1
VGA1
ATX1
LAN1~2
SCN1
SCN2
SCN3
SDIMM1
Board and Pin Assignments
Description
USB 2.0 Wafer Port 3 and 4
Front Panel Connector
Inverter Connector
I2C Connector
LVDS Connector
SMBus Connector
SATA Power Connector
Digital I/O Connector
COM2 Wafer Connector
Audio Connector
Audio Jack
Fan Connector
COM1 Connector
SATA Connector
USB 3.0 Port 1 and 2
VGA Connector
ATX Power Connector
Ethernet Port 1 and 2
Full-size PCI-Express Mini Card and mSATA Connector
Full-size PCI-Express Mini Card Connector
SIM Card Slot
DDR3L SO-DIMM Connector
CAPA318 3.5" Board
]
11
