- Page 1 Avonic CM-CON100 PTZ Camera Keyboard Controller User Manual Version 2.0 Update notes: Join Avonic linkedin.com/company/avonic twitter.com/avonic1 facebook.com/avonic www.avonic.eu...
-
Page 2: Table Of Contents
Product Overview ................4 Features ............................... 4 Product Description ..........................4 Installation ..................6 Connection Diagram ..........................6 Operation Instructions ..............6 Menu ..............................6 Maintenance .................. 9 Troubleshooting ................9 Contact ..................9 Appendix ..................10 Technical Data ........................... 10 www.avonic.eu... -
Page 3: Introduction
Before cleaning, unplug the power cable. Use a soft, damp cloth to clean the device, do not use strong or abrasive detergent to clean that will damage the device. • If you wish to dispose this product, please contact Avonic to obtain info about the take-back procedure. Compliance Statements and Certifications •... -
Page 4: Package Contents And Accessories
CM-CON100-PSU Product Overview The Avonic CM-CON100 is a mini keyboard controller is a full-function system keyboard. With features of ergonomic design, multi-function, high reliability and easy operation, it is a perfect controller for PTZ cameras, video conference cameras, surveillance cameras and so on. - Page 5 Operation: Press this key, the crisscross of indicator lighter near the joystick will go out, twist the joystick to zoom in / out; press this key again, the crisscross of indicator lighter will be lightened, twist the joystick will adjust focus value. www.avonic.eu...
-
Page 6: Installation
If still no operations, the controller will enter sleeping mode Enter menu The initial ADMIN pin ADMIN PIN: is “111111“ See “PIN SETTING” to Press SETUP key set pin. Menu List www.avonic.eu... - Page 7 Volume Setting OFF (switch off sound) VOLUME SETTING 1~6 (6 levels from low to high) Backlight Setting AUTO/ON/OFF BACKLIGHT MODE SLEEP SETTING Sleep Setting OFF/ 30S/ 1M/ 5M/10M / 30M/60M PIN SETTING PIN setting USER/ADMIN www.avonic.eu...
- Page 8 It is used to custom keys to realize special functions requested. Speed setting SPEED SETTING Set control speed of the joystick HIGH MIDDLE Default Setting DEFAULT Restore the keyboard setting to factory SETTING default INFORMATION Information Display It displays firmware version number www.avonic.eu...
-
Page 9: Maintenance
Troubleshooting Contact For any questions or suggestions, contact the reseller or the local Avonic distributor. Find the local distributor on the Avonic website. For support qustions mail to support@avonic.eu For the recent manual or datasheet, look at the Avonic website. -
Page 10: Appendix
Baud Rate 2400bps, 4800bps, 9600bps, 19200bps, 38400bps Address 0~255 Joystick 4-axis (Left/Right, Up/Down, Zoom In/Out, Focus Near/Far) Display OLED Power DC12V Power Consumption <2W Working Temperature 0℃~40℃ Storage Temperature -20℃~+50℃ Relative Humidity ≤90% (non-condensation) Dimensions 200mm(L)*120mm(W)*103mm(H) Net Weight 0.5kg www.avonic.eu...
