Summary of Contents for Avonic AV-CON100
- Page 1 USER MANUAL PTZ Camera Controller AV-CON100 www.avonic.com • © July 2022 • Version 1.3...
-
Page 2: Disclaimer, Contact And Ce Marking
“look and feel” and arrangement of such Content, contained in this Manual is owned, controlled or licensed by or to Avonic, and is protected by trade dress, copyright, patent and trademark laws, and various other intellectual property rights and unfair competition laws. -
Page 3: Eu Declaration Of Conformity
4. The object of the declaration described in point 1 is in conformity with the EMC2014/30/EU EN 55022:2010 5. Standards EN 55024:2010+A1:2015 EN 61000-3-2:2014 EN 61000-3-3: 2013 6. Signed for and on behalf of Avonic: Delfgauw, 25th of April, 2019 Martijn van Bodegom, Product Manager... -
Page 4: Important Information
IMPORTANT INFORMATION Liability Avonic will NOT be held responsible for any damage or injury caused by unqualified persons carrying out these tasks, or by not following the instructions in this Manual. Intended Use and Non-Intended Use Installation The following applies to the installation of the CON100: •... -
Page 5: Symbols Used In This Manual
Symbols Used in This Manual Symbol Meaning Description Not following the instructions associated with this symbol may lead to Danger life-threatening situations and / or serious damage to the Product. Not following the instructions associated with this symbol may lead to Warning personal injury and / or serious damage to the Product. -
Page 6: Table Of Contents
Contents DISCLAIMER, CONTACT AND CE MARKING..................ii EU DECLARATION OF CONFORMITY....................iii IMPORTANT INFORMATION........................iv Liability............................iv Intended Use and Non-Intended Use..................iv Installation......................... iv Operation..........................iv Important Precautions..................... iv Symbols Used in This Manual.....................v Acronyms............................. v INTRODUCTION............................8 Purpose of This Manual......................8 Target Audience.........................8 Document Structure........................ - Page 7 4. Backlight Setting......................21 5. Sleep Setting....................... 21 6. PIN setting (and what to do if the PIN is lost)............22 7. Joystick Calibration....................22 8. Key Custom.........................22 9. Speed Setting......................23 10. Default Setup......................23 11. Information........................ 23 OSD Menu (Camera).......................24 Buttons to control the OSD menu of the camera............
-
Page 8: Introduction
This Manual describes the safety precautions and the instructions for safe unpackaging, installation, operation, maintenance and disposal of the Avonic CON100. In this Manual, the Avonic CON100 is referred to as the 'Product'. Target Audience This Manual is developed for installation technicians who install the Product at client sites, and for IT professionals who are responsible for operating the Product. -
Page 9: Safety Instructions
Product. Keep the Manual in a safe place for future reference or download it from www.avonic.com. Intended Use This Product is intended to control the Avonic PTZ cameras. See also section Intended Use and Non- Intended Use on page iv for details. -
Page 10: Ventilation
• Don’t open this Product and don’t attempt to repair it yourself. Disassembling the Product may damage it or may cause injury to you. • If this Product is damaged, malfunctioning, or if it comes into contact with liquid, contact Avonic or an Avonic Authorized Service Provider. -
Page 11: Product Overview
PRODUCT OVERVIEW Description The Avonic CM-CON100 is a compact PTZ camera controller. With this controller it is possible to control up to 255 camera’s and using up to 255 presets. The controller supports the Visca, Pelco-D and Pelco-P protocol and can be connected with RS232/485. The Avonic CM-CON100 is therefore compatible with the Avonic camera’s as well with other brands that supports these protocols. -
Page 12: Unpacking
1. Package Contents 2. Unpacking the Controller 3. Return Procedure Package Contents The following tables contains an overview of the package contents of the Product. Quantity Description Avonic SKU 1 pc PTZ Camera Controller CM-CON100 1 pc Power Supply CM-CON100-PSU... -
Page 13: Unpacking The Controller
The CON100 should be in its protective foam as follows: Figure 4: Controller in Foam 3. Verify that the plastic bag is sealed. If this is NOT the case, contact Avonic and stop here. 4. Break the seal of the sealed bag. -
Page 14: Installation
INSTALLATION This chapter describes the steps you have to perform to mount and install the Product in a correct and safe manner. The installation of the controller can be done in two ways: 1. Connecting a controller to a Camera 2. -
Page 15: Rs-232 Interface
RS-232 Interface Connect the controller to the back of the camera via RS-232 cables as shown in the figures below: Figure 5: RS-232 Interface (Mini Figure 6: RS-232 Cable and Interface DIN-8) Connection (Mini DIN-8 and Windows DB-9) RS-485 Interface Connect the controller to the + and - at the back of the camera via the RS-485 cables, as shown in the figure below. -
Page 16: Operation
OPERATION This chapter will explain the operation instructions for using the CON100. Connections Before using the CON100 for the first time, the buttons and their functionalities will be explained. See below: Name Functionality OLED Screen Displays status of current operation From top to bottom: CAMERA Switch camera’s... -
Page 17: Start
Start If you have connected the cables to your camera (see previous chapter) the CON100 will start automatically. When the CON100 is for the first time ON, you will see that it will display the User PIN. 1. Press to fill in the pin. The initial pin is “111111”. Pin Error: When “USER PIN: ERROR”... -
Page 18: Ptz Controls
Functionality Buttons Switch between Zoom and Focus Autofocus Manual Focus Iris Open Iris Close PTZ Controls Move the Joystick up, down, left and right (1) to control the camera. Turn the joystick clockwise to zoom in (2) and anti-clockwise to zoom out (3). The button on the joystick is for switching between zoom and focus. See pictures below: Zoom and Focus It is possible to switch to Focus mode in two different ways: Using the Joystick button (see picture 3 above), or using... -
Page 19: Delete Preset Position
Follow the instructions below to Call a Preset: 1. Press number 1 button (or another number button between 0 - 255). 2. Press the to call the preset. The camera moves automatically to the position of that preset number. Note also that it is possible to easily confuse the Preset/ CALL functionality with setting up camera (protocol) Address and ID number! Keep in mind in which feature and menu you are. -
Page 20: Buttons To Control The Camera (Setup Menu)
Buttons to control the camera (setup menu) The following buttons and button combinations can be used to control the camera in Setup Menu: Functionality Button Enter Setup Menu Enter Sub Menu Leave (Setup) Menu Leave/ Delete wrong insert Scroll through Menu or settings Switch between settings Confirm setting Special functions / Enter extra... -
Page 21: Time Setting
Follow the instructions below: 1. Move the joystick to the right to enter the Camera Setting menu. The camera ID screen appears. This will set the Camera ID. Press 1 - 255 to set the ID and press the Enter to confirm. -
Page 22: Pin Setting (And What To Do If The Pin Is Lost)
6. PIN setting (and what to do if the PIN is lost) This will set the PIN. 1. Move the Joystick up/down to change between the USER or the ADMIN (administrator). 2. Press Enter to save. 3. The controller now asks for the old PIN. Type the old PIN by using the number buttons and press Enter to confirm. -
Page 23: Speed Setting
Follow the instructions below: 1. Move in NON-Setup Menu the joystick to set the camera in the desired position. 2. Move in Setup Menu to Key Custom and open the menu. Screen Menu preset shows up. 3. Press PATTERN, CRUISE or MENU Button (see picture above). The corresponding Menu opens. 4. -
Page 24: Osd Menu (Camera)
You can download the camera manual on the Avonic website to read about the functionality of the OSD menu. If you are using a third party camera, please refer to the manual of that third party camera. -
Page 25: Maintenance
MAINTENANCE Maintenance Take the following actions to maintain the CON100: • If you will not be using the CON100 for a long time, disconnect the AC powercord of the AC adaptor to the outlet. • Use a soft cloth or tissue to clean the camera cover. •... -
Page 26: Transport And Storage
TRANSPORT AND STORAGE The CON100 must be transported in its original packaging box. Inside the box, it is recommended to wrap the CON100 in the original plastic bag and to place it in the protective foam. Specific guidelines apply to the environmental temperature and humidity when operating and storing the CON100. -
Page 27: Disposal And Recycling
In general, the term 'E-Waste' applies to items of all types of electrical and electronic equipment and its parts that have been discarded by the owner as waste without the intention of re-use. Avonic outsources the disposal and recycling of its E-Waste camera materials to the Stichting Open. https://stichting-open.org/... -
Page 28: Troubleshooting
TROUBLESHOOTING General 1. Turn the CON100 off and on again and check if the problem persists. 2. If it does, restore to the factory default. Power Issues No display and no button lights: 1. Check the net power. 2. Check the power supply. Serial functionality issues Cannot control the camera (controller is not responding): •... - Page 29 PTZ Camera Controller AV-CON100 © July 2022 • Version 1.3 Exportweg 11a • 2645 ED Delfgauw • The Netherlands +31(0)15 7112 712 • info@avonic.com • www.avonic.com...
