Features
The TPM kit is a custom board containing an I
SAM4S ARM board. Interface signals on the board are:
• Power
• Ground
• PIRQ
• Chip Select (CS)
• MISO
• SDA
The following functional sections are provided on the Embedded TPM kit:
• AT97SC3205 I
• TPM Reset Switch
• RC Reset Delay
• Decoupling Capacitors
• Pull-Up and Pull-Down Resistors
• Test Points
USB Drive
The included USB drive includes the following:
• User Guide
• Source Code of the Demo
• Hex Images for Reloading the Demo (If Necessary)
• Kit Schematics
Figure 1. Atmel I
AT97SC3205T/3205P-SDK2 TPM I
2
Atmel-8528D-TPM-I2C-SPI-Development-Kit-UserGuide_052014
• SCL
• SCLK
• MOSI
• RST
• GND
• V
CC
2
C or SPI Atmel TPM
2
C/SPI Demonstration Kit
Mini JTAG Connector
2
C/SPI Development Kiti [USER GUIDE]
2
C TPM or SPI TPM and related circuitry connected to the
SAMS4 ARM Reset Button
Detachable Segments
TPM JTAG Connector
