Features

•
Incorporates the ARM7TDMI
– High-performance 32-bit RISC Architecture
– High-density 16-bit Instruction Set
– Leader in MIPS/Watt
™
– EmbeddedICE
(In-circuit Emulation)
•
256K Bytes of On-chip SRAM
– 32-bit Data Bus, Single-clock Cycle Access
•
1024K Words 16-bit Flash Memory (2M bytes)
– Single Voltage Read/Write,
– Sector Erase Architecture
– Erase Suspend Capability
– Low-power Operation
– Data Polling, Toggle Bit and Ready/Busy End of Program Cycle Detection
– Reset Input for Device Initialization
– Sector Program Unlock Command
– 128-bit Protection Register
– Factory-programmed AT91 Flash Memory Uploader Software
•
Fully Programmable External Bus Interface (EBI)
– Up to 8 Chip Selects, Maximum External Address Space of 64M Bytes
– Software Programmable 8/16-bit External Data Bus
•
8-level Priority, Individually Maskable, Vectored Interrupt Controller
– 4 External Interrupts, Including a High-priority Low-latency Interrupt Request
•
32 Programmable I/O Lines
•
3-channel 16-bit Timer/Counter
– 3 External Clock Inputs, 2 Multi-purpose I/O Pins per Channel
•
2 USARTs
– Two Dedicated Peripheral Data Controller (PDC) Channels per USART
•
Programmable Watchdog Timer
•
Advanced Power-saving Features
– CPU and Peripherals Can be De-activated Individually
•
Fully Static Operation:
– 0 Hz to 75 MHz Internal Frequency Range at VDDCORE = 1.8V, 85° C
•
2.7V to 3.6V I/O Operating Range, 1.65V to 1.95V Core Operating Range
•
-40° C to 85° C Temperature Range
•
Available in a 121-ball 10 x 10 x 1.2 mm BGA Package with 0.8 mm Ball Pitch

1. Description

The AT91FR40162S is a member of the Atmel AT91 16/32-bit Microcontroller family,
which is based on the ARM7TDMI processor core. The processor has a high-perfor-
mance 32-bit RISC architecture with a high-density 16-bit instruction set and very low
power consumption.
The AT91FR40162S ARM microcontroller features 2 Mbits of on-chip SRAM and 2
Mbytes of Flash memory in a single compact 121-ball BGA package. Its high level of
integration and very small footprint make the device ideal for space-constrained appli-
cations. The high-speed on-chip SRAM enables a performance of up to 74 MIPs in
typical conditions with significant power reduction and EMC improvement over an
external SRAM implementation.
The Flash memory may be programmed via the JTAG/ICE interface or the factory-
programmed Flash Memory Uploader (FMU) using a single device supply, making the
AT91FR40162S suitable for in-system programmable applications.
®
®
®
ARM
Thumb
Processor Core
AT91
®
ARM
Thumb
Microcontrollers
AT91FR40162S
Preliminary
6174B–ATARM–07-Nov-05
®
