Hach LXV321.99.00001 User Manual

Hach LXV321.99.00001 User Manual

Tss portable handheld measurement instrument for turbidity/solids
Hide thumbs
Table of Contents

Advertisement

Quick Links

DOC023.53.90050
TSS Portable handheld
measurement instrument for turbidity/solids
User Manual
01/2018, Edition 6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LXV321.99.00001 and is the answer not in the manual?

Questions and answers

Related Manuals for Hach LXV321.99.00001

Summary of Contents for Hach LXV321.99.00001

  • Page 1 DOC023.53.90050 TSS Portable handheld measurement instrument for turbidity/solids User Manual 01/2018, Edition 6...

  • Page 3: Table Of Contents

    Table of Contents Section 1 Specifications ........................5 Section 2 General Information......................7 2.1 Safety information..........................7 2.1.1 Hazard notices in this manual....................7 2.1.2 Precautionary labels ......................... 7 2.2 Overview of product........................... 8 2.3 Measurement instrument ........................8 2.4 Measuring principle..........................8 2.5 Probe ..............................
  • Page 4 Section 5 Operation ..........................23 5.1 Calibration ............................23 5.1.1 Important notes for calibration....................23 5.1.2 Calibrating ..........................24 5.1.3 Manual calibration value correction..................26 5.1.4 Delete calibration point......................26 5.1.5 Reset to default calibration......................26 5.2 Measure ............................26 5.2.1 Selecting the calibration curve ....................27 5.2.2 Start the measurement......................27 5.2.3 Interrupt and resume the measurement ..................27 5.2.4 Stop measurement ........................27 5.3 Show the data in the display ......................27...

  • Page 5: Section 1 Specifications

    Section 1 Specifications These are subject to change without notice. Performance specifications Wavelength 860 nm Parameter Turbidity Solids (dry matter) Combined multiple-beam alternating light technique with IR diode system and beam focus 2-channel 90° scattered light measurement in accordance with DIN Measurement method Modified absorption measurement EN 27027 / ISO 7027;...
  • Page 6 Specifications...

  • Page 7: Section 2 General Information

    Section 2 General Information Safety information Please read this entire manual carefully before unpacking, setting up, or operating this equipment. Pay attention to all danger and caution notices. Failure to do so could result in serious injury to the operator or damage to the equipment. To prevent damage to or impairment of the device's protection equipment, the device may only be used or installed as described in this manual.

  • Page 8: Overview Of Product

    General Information Overview of product The TSS Portable is a handheld measurement instrument for the analytical determination of turbidity and solids in aqueous media. Measurement instrument The instrument stores the recorded data under the corresponding calibration curve. Four calibration curves for solids (C-DS1, C-DS2, C-DS3, C-DS4) and one calibration curve for turbidity (C-TU) are available for selection.

  • Page 9: Section 3 Installation

    Section 3 Installation WA R N I N G Risk of falling. Measurements are taken directly on site with this instrument. In order to avoid falling into the basin, all local safety regulations with respect to roping up and wearing appropriate protective clothing and shoes must be observed.

  • Page 10: Powered Via Rechargeable Batteries

    Installation Powered via rechargeable batteries WA R N I N G Risk of fire and explosion. Only use rechargeable NiMH batteries and ensure that the rechargeable NiMH batteries are inserted correctly in the battery compartment. Incorrect insertion of the rechargeable NiMH batteries may damage the instrument or lead to fire or explosions. WA R N I N G Risk of fire and explosion.

  • Page 11: Install The Charger

    Installation Figure 2 Inserting the rechargeable batteries Catch Battery holder Battery compartment rechargeable Batteries Battery clip 3.2.2 Install the charger WA R N I N G Risk of fire and explosion. Only use the battery charger to charge the rechargeable NiMH batteries, while batteries inside the instrument.

  • Page 12: Charging The Rechargeable Batteries

    Installation Figure 3 Replacing the adapter Charger Removing the adapter Slide switch The battery charger must agree with local and national safety regulations and may not be part of the shipment. If the charger is not part of the shipment, charge the batteries with a charger available in your country. Make sure that the charger agrees the battery specifications.

  • Page 13: Connecting The Probe

    Installation Figure 4 Charging the rechargeable batteries Charger Charging socket Discharge button (yellow) LED lamp (green => rechargeable batteries fully charged) Charging plug LED lamp (red => rechargeable batteries currently charging) The battery charger must agree with local and national safety regulations and may not be part of the shipment. If the charger is not part of the shipment, charge the batteries with a charger available in your country.

  • Page 14: Switching The Instrument On And Off

    Installation Figure 5 Connecting the probe plug to the instrument Probe plug Probe connection Switching the instrument on and off 1. Fully charge the rechargeable batteries (see section 3.2.3). Note: The rechargeable batteries are fully charged when the LED on the charger is green. 2.

  • Page 15: Section 4 Start Up

    Section 4 Start Up System start overview 1. Switch on the measurement instrument (section 3.4, page 14). 2. Connect the probe to the measurement instrument (section 3.3, page 13). 3. Edit the time/date, display, units, language and integration time (section 4.3, page 17).

  • Page 16: Display

    Start Up 4.2.2 Display In its basic setting, the display shows the main measurement variables and the date/time (Figure 7). It can be set in a user-defined manner, see section 4.5, page Table 1 Navigating in the menu Navigation key Description Navigation key RIGHT/LEFT Navigation occurs with the RIGHT/LEFT navigation keys.

  • Page 17: Querying Internal Information

    Start Up 4.2.2.1 Querying internal information Information about the probe and instrument can be queried directly from the main menu using the navigation keys UP/DOWN The following information is displayed: a. Measurement value (homogeneity in %) b. Battery charge level c.

  • Page 18: Setting The Display

    Start Up Setting the display It is possible to custom-define the first two rows of the display. In the standard setting, the first line shows the main measured variable and the second line shows the date/time. 1. Select , confirm with MENU ENTER/ON 2.

  • Page 19: Calibration

    Start Up Calibration For turbidity measurement, a standard curve C-TU is already stored in the probe. Calibration is not required. However, for solids measurement, calibration is required in order to set the rough measurement signals to a calibrated display (refer to section 5.1, page 23).
  • Page 20 Start Up Calibrate curve C-DS1: 7. Select and confirm with MEMORY ENTER/ON 8. Lower the probe into a container that contains a homogeneous sample. 9. Select and confirm with while stirring the measuring medium with POINT 1 ENTER/ON the probe. The distance between the probe head and the walls and base of the container must always be more than 70 mm (2.76 in.).

  • Page 21: Practical Example For Turbidity Measurement

    Start Up 4.8.2.2 Practical example for turbidity measurement A standard curve C-TU is stored for the turbidity measurement. 1. Connect probe to instrument. 2. To switch the instrument on, press for 2 seconds. ENTER/ON 3. Select and confirm with READ ENTER/ON 4.
  • Page 22 Start Up...

  • Page 23: Section 5 Operation

    Section 5 Operation Calibration Turbidity measurements do not need to be calibrated, as a standardized calibration curve according to ISO 7027 is stored in the instrument. It is possible to create a customer-specific calibration of the turbidity curve. If the standard curve has been altered, a star (*) appears before the measurement point.

  • Page 24: Calibrating

    Operation 5.1.2 Calibrating The instrument can save one turbidity curve and up to four solids calibration curves. This makes measurements in media with different qualities possible. Each measurement point can have one of the saved calibration curves assigned to it individually. 1-point calibration In order to define a calibration curve, it is generally sufficient to use a single calibration point in the probe's measuring range.
  • Page 25 Operation 14. Enter the laboratory values using the navigation keys and confirm with ENTER/ON • Navigation key : Jump to the next/previous decimal place LEFT/RIGHT • Navigation key : Change number UP/DOWN The laboratory value is saved. The main menu is shown. Repeat steps 1 to 14 to record additional calibration points.

  • Page 26: Manual Calibration Value Correction

    Operation 5.1.3 Manual calibration value correction 1. Select , confirm with MENU ENTER/ON 2. Select , confirm with CALIBRATE ENTER/ON The instrument reads the probe data. 3. Select the curve shown and confirm with ENTER/ON 4. Select the desired curve and confirm with ENTER/ON 5.

  • Page 27: Selecting The Calibration Curve

    Operation 5.2.1 Selecting the calibration curve Before starting the measurement, the calibration curve that corresponds to the measurement point must be selected. 1. Select , confirm with MENU ENTER/ON 2. Select , confirm with CALIBRATE ENTER/ON 3. Selectthe curve shown and confirm with ENTER/ON 4.

  • Page 28: Delete Stored Data For All Calibration Curves

    Operation Delete stored data for all calibration curves 1. Select , confirm with MENU ENTER/ON 2. Select , confirm with SYSTEM ENTER/ON 3. Enter the value 379 using the navigation keys and confirm with ENTER/ON...

  • Page 29: Section 6 Maintenance

    Section 6 Maintenance C A U T I O N Potential chemical and biological eye and skin hazards. Only qualified personnel should perform the tasks described in this section of the operating manual. The cleanliness of the measurement windows in the sensor head is critical to the accuracy of the measurement results! Cleaning the instrument Clean the instrument with a damp, lint-free cloth.
  • Page 30 Maintenance...

  • Page 31: Section 7 Troubleshooting

    Section 7 Troubleshooting Error messages Problem/display screen Caused by Action – Plug in the probe The probe is not connected to the Communication with probe – Check the connection to the probe instrument – Correct probe number Switch the instrument off and then back EEPROM error Values cannot be saved on again...
  • Page 32 Troubleshooting...

  • Page 33: Section 8 Replacement Parts And Accessories

    (EU, USA, GB and AUS/China), rechargeable batteries, manual and carry case TSS Portable handheld instrument LXV320.99.00001 TSS probe (10 m (32.8 ft) cable, plug) LXV321.99.00001 6x rechargeable NiMH batteries, type AA HR6, 1800 mAh LZY604 Charger for rechargeable batteries with four adapters LZY607...
  • Page 34 Replacement parts and accessories...
  • Page 36 Fax (970) 669-2932 Fax +49 (0) 2 11 52 88-210 Tel. +41 22 594 6400 orders@hach.com info-de@hach.com Fax +41 22 594 6499 www.hach.com www.de.hach.com © Hach Company/Hach Lange GmbH, 2004–2008, 2012, 2017-2018 All rights reserved. Printed in Germany 01/2018, Edition 6...

This manual is also suitable for:

Lxv320.99.00001Lxv322.99.00001Tss portableTss
