6 Specifications

Inputs
Port Quantity
6G-SDI 1
HDMI 1
DVI 1
Outputs
Port Quantity
RJ45 8
OPT 2
Control Interface
Port
ETHERNET
USB (flat mouth)
USB (square mouth)
GenLock
Port Quantity
IN
1
LOOP 1
Overall Specifications
Input power
Overall power consumption
Operating temperature
Dimension
Weight
M C T R L R 5 Use r M a ua l
Specifications
Subject to 6G-SDI standard, support resolution up to
3840×2160@30Hz, and be downward compatible.
Subject to HDMI 1.4 standard, support resolution up to
3840×1080@60Hz, and be downward compatible.
Subject to VESA standard, support resolution up to
3840×1080@60Hz, and be downward compatible.
Specifications
Neutrik Gigabit Ethernet port
Fiber interface, single-mode dual-fiber, LC connector,
1310nm
OPT1 transmits data from Port 1 to Port 8.
OPT2 is the standby channel of OPT1.
Quantity Specifications
1 Control interface
1 Control interface of upper computer
1 Cascading interface
Specifications
Genlock type: Blackburst
Genlock synchronization signal guarantees
synchronization between large-screen display image and
external Genlock source.
Loop out port of Genlock
AC 100~240V, 50/60Hz
25W
-20~60℃
482.6×330×45 (mm)
4.0kg
