ENFORCER E-931CS22RRCQ Installation Manual

Specifications:

Model Number
Type
Retro-Reflective Photoelectric Entry Alert System
Sensing Range
Voltage Supply Sensor: 9-15 VDC, Chime: 9-15 VDC
Total Current Consumption
Stand-by Current
Light Source
Ambient Temperature
Speaker Response Time
~1 sec. for Chime, 30 sec. for Alarm
Speaker Volume
Adjustable from 0 ~ 90 dB at 1m (max.)
Alarm Time Range
Speaker Output Chime / Off /Alarm (Select by switch)
Mounting Brackets

Troubleshooting:

Trouble Possible Origin(s)
Sensor does not detect the object. Sensor not aligned properly.
1) Reflector and/or sensor is misaligned.
Red LED does not turn on.
2) No power.
Dimensions:
1 3 / " (30mm)
16
2 / " (60mm)
3
8
NOTICE:
The information and specifications printed in this manual are current at the time of publication. However,
the SECO-LARM policy is one of continual development and improvement. For this reason, SECO-LARM reserves the right
to change specifications without notice. SECO-LARM is also not responsible for misprints or typographical errors.
Copyright © 2014 SECO-LARM U.S.A., Inc. All rights reserved. This material may not be reproduced or copied, in whole
or in part, without the written permission of SECO-LARM.
WARRANTY:
ENFORCER Photobeam Sensors are warranted against defects in material and workmanship while
used in normal service for a period of one (1) year from the date of sale to the original customer. Our obligation is
limited to the repair or replacement of any defective part if the unit is returned, transportation pre-paid, to SECO-LARM.
SECO-LARM U.S.A., Inc.,
®
16842 Millikan Avenue, Irvine, CA 92606 Tel: 800-662-0800 / 949-261-2999
Fax: 949-261-7326 Website: www.seco-larm.com E-mail: sales@seco-larm.com
E-931CS22RRCQ
22' (7 m)
100mA Max.
30mA
IR LED
-4 F (-20 C) ~ 122 F (50 C)
0 0 0 0
Adjustable 3~30sec. for alarm
All Included
Remedy(s)
Change the angle of the sensor or reflector.
1) Adjust the reflector and/or sensor for
proper alignment
2) Check power adapter and cable.
(35mm)
2 7 / " (62mm)
16
5 / " (8.2mm)
2 1 / " (51.3mm)
16
64
MiE931CS22RRCQ_1409.pmd
ENFORCER
Retro-Reflective Photoelectric
Sensor Entry Alert System
E-931CS22RRCQ
Range: 22ft. (7m)
Features:
1 / "
3
8
• • • • • Retro-reflective photoelectric sensor.
• • • • • Range: Up to 22 feet (7m).
• • • • • Perfect for monitoring an entrance, or for counting
foot traffic with optional counter.
• • • • • Will make "ding-dong" sound or alarm sound
when the beam is interrupted.
• • • • • Speaker volume can be adjusted or turned off.
• • • • • When in alarm mode, sounding time is adjustable
from 3 to 30 seconds.
Caution:
• This sensor was not designed to prevent bodily injury or loss of life.
• Use of this sensor in certain security applications may be regulated by local laws or codes.
SECO-LARM is not responsible for compliance with such laws or codes.
Included:
E-931CS22SQ
Transmitter/Receiver
PITSW3
®
By A. Aaron at 3:29 pm, Sep 30, 2014
®
By P. Lin at 3:33 pm, Sep 30, 2014
Sensor
By J. Delfino at 3:38 pm, Sep 30, 2014

INSTALLATION MANUAL

• • • • • All components plug into each other.
No hard wiring required.
• • • • • Optional counter available (E-931ACC-CQ).
• • • • • Optional second speaker available (E-931ACC-SQ).
• • • • • Includes the following:
— Retro-reflective photoelectric sensor.
— Reflector.
— Speaker/electronic chime.
— Power adapter.
E-931ACC-R2Q
E-931ACC-SQ E-931ACC-BLS4Q
Reflector Speaker/Electronic Chime Sensor Bracket
E-931ACC-BLR2Q Power
Reflector bracket Adapter
