FIGURE 4 – INDICATING LEDS
LED Status
Power On
On
Link/ACT (FP)
Flashing
On
Link/ACT (TP)
Flashing
On
FDX/COL
Off
FX or SD On
On
1000M
Off
FIGURE 5 – DIP SWITCH POSITIONS
Function
Link Fault Pass-through function. DIP Switches 1 and 4 must be set
to opposite positions (default is 1 ON/4 OFF)
Pass-through Mode / Enable Jumbo Frame
Enable Store and Forward Mode (default)
Modified Cut-through mode
TECH SUPPORT: 1.888.678.9427
Meaning
Power is on
Fiber link port is connceted
Packets sending/receiving
TX port is connected
Packets sending/receiving on TX port
TX port full duplex mode active
TX port half duplex mode active
Fiber signal is detected
TX in 1000 Mbps speed
TX in 100 Mbps speed
DIP Switch Position
1 2 3
OFF/
ON
ON ON
OFF OFF
ON OFF
CWGE2SC(M,S)2
4
ON/
OFF
INS_CWGE2SC(M,S)2_REV- 06/22/12 PAGE 3
