How to Monitor Dolby-Based Surround Sound
14. Option DDE only: Select Dolby
Downmix Mode. Each downmix mode
combines multiple separate audio
channels into a mix that provides
compatibility for users with only mono
or stereo systems, or with older analog
surround sound systems.
15. Choose one of the following modes to
display as two bars in the Audio Display
(Option DD is always in Lt/Rt mode.):
Select None to get no downmix.
Select Mono to get the downmix shown
right.
Select Lo/Ro (Left-only/Right only) to
get a standard stereo downmix.
Select Lt/Rt (Left-total/Right-total) to get
a Dolby Pro-Logic compatible stereo mix.
16. Press the CONFIG button to dismiss the
CONFIG menu.
100 WVR6100, WVR7000, and WVR7100 Waveform Rasterizers Quick Start User Manual
