Instructions
WVR6UP, WVR70UP, and WVR7UP Upgrades
WVR6100, WVR7000, and WVR7100 Series
Waveform Rasterizers
075-0887-03
Warning
The servicing instructions are for use by qualified
personnel only. To avoid personal injury, do not
perform any servicing unless you are qualified to
do so. Refer to all safety summaries prior to
performing service.
www.tektronix.com
*P075088703*
075088703
Advertisement
Table of Contents
Related Manuals for Tektronix WVR6UP
Summary of Contents for Tektronix WVR6UP
- Page 1 Instructions WVR6UP, WVR70UP, and WVR7UP Upgrades WVR6100, WVR7000, and WVR7100 Series Waveform Rasterizers 075-0887-03 Warning The servicing instructions are for use by qualified personnel only. To avoid personal injury, do not perform any servicing unless you are qualified to do so. Refer to all safety summaries prior to performing service.
- Page 2 Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or suppliers, and are protected by national copyright laws and international treaty provisions. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supercedes that in all previously published material.
-
Page 3: Service Safety Summary
Use Care When Servicing With Power On. Dangerous voltages or currents may exist in this product. Disconnect power, remove battery (if applicable), and disconnect test leads before removing protective panels, soldering, or replacing components. To avoid electric shock, do not touch exposed connections. WVR6UP, WVR70UP, and WVR7UP Upgrades... - Page 4 Service Safety Summary WVR6UP, WVR70UP, and WVR7UP Upgrades...
-
Page 5: Kit Description
CAUTION. To prevent monitoring problems, after installing any audio option in this kit, do not use the optional accessory, Analog/Audio Breakout Cable Assembly, Tektronix part number 012-1658-01. This optional accessory is for rasterizers that shipped with early versions of audio option hardware and will not work properly with your new audio option. -
Page 6: Minimum Tool And Equipment List
A standard PC running Windows 98, Windows NT 4.0, Windows ME, Windows 2000, or Windows XP. Used for installing all options. Winsock 2.0, an Ethernet interface, and 10 MB of free disk space must be present on the PC system. Used for installing all options. WVR6UP, WVR70UP, and WVR7UP Upgrades... -
Page 7: Kit Parts Lists
Screw; 6- - 32 X 0.250, panhead T- - 15 TORX drive 2 each 214-3903-XX Screw; 4- - 40 X 0.312 long, 0.188 H hex head stand off 8 each 220-0497-XX Nut; hex; 0.5- - 28 X 0.562 1 each 671-9938-XX Circuit-board assembly; Digital Analog Audio WVR6UP, WVR70UP, and WVR7UP Upgrades... - Page 8 Screw; 6- - 32 X 0.250, panhead T- - 15 TORX drive 2 each 214-3903-XX Screw; 4- - 40 X 0.312 long, 0.188 H hex head stand off 8 each 220-0497-XX Nut; hex; 0.5- - 28 X 0.562 1 each 671-9938-XX Circuit-board assembly; Digital Analog Audio WVR6UP, WVR70UP, and WVR7UP Upgrades...
- Page 9 1 each 174-5224-XX Cable assembly, Power Supply to Main and Eye boards 2 each 174-5301-00 Coaxial cable, SMA 1 each 679-9935-XX Circuit board subassembly; Loop-through board 1 each 671-9936-XX Circuit board subassembly; HD/SD, Eye board WVR6UP, WVR70UP, and WVR7UP Upgrades...
- Page 10 Kit Description WVR6UP, WVR70UP, and WVR7UP Upgrades...
-
Page 11: Installation Instructions
If you need further details for disassembling or reassem- bling the product, refer to the appropriate product manual. Contact your nearest Tektronix Service Center or Tektronix Factory Service for installation assistance. CAUTION. To prevent static discharge damage, service the product only in a static-free environment. -
Page 12: System Upgrade
System Upgrade All kits require that you upgrade the system software. You can locate the latest available upgrade at the Tektronix Web site (www.tektronix.com). At the Web site, click on Software and Drivers and type WVR in the Find by model number or keyword entry box. - Page 13 A flat-blade screwdriver may help pry out the plug. b. Remove the three Main board mounting screws as shown below. c. Continue with Install Upgrade Audio Board on page 13. Remove these screws WVR6UP, WVR70UP, and WVR7UP Upgrades...
- Page 14 3. Remove the nut and washers that secure the eight audio BNC connectors to the rear panel. 4. If an analog audio connector is present, use a 3/16 in. nut driver to remove the two retainer posts that secure it to the rear panel. WVR6UP, WVR70UP, and WVR7UP Upgrades...
- Page 15 Perform the following steps to install the new Audio board and to put it into Audio Board service. If installing option WVR6UP-DS, WVR70UP-DS, or WVR7UP-DS, start with step 2; otherwise, start with step 1: 1. If a panel covers the analog audio input/connector hole at the rear panel, remove the two screws that secure the panel Remove the panel by pulling it away from the inside.
- Page 16 4. Install the three mounting posts from the kit in the locations from which you removed the mounting screws or the mounting posts earlier. The figure associated with step 6 on page 13 indicates the post locations. Tighten firmly, but not excessively. WVR6UP, WVR70UP, and WVR7UP Upgrades...
- Page 17 7. From the kit, install a washer, and then a nut, to each of the BNC connectors of the new board. 8. Plug the cable from the new Audio board into J750 on the Main board. Plug audio cable into J750 WVR6UP, WVR70UP, and WVR7UP Upgrades...
- Page 18 Installation Instructions 9. For all Audio boards except options WVR6UP-DS, WVR70UP-DS, and WVR7UP-DS, install the two standoff retainers that secure the audio analog connector to the rear panel. These screws install from the outside of the rear panel. Tighten firmly, but not excessively.
-
Page 19: Eye Board Installation (Eye And Phy Options Only)
3. Use the illustration below to inspect the instrument for the presence of an existing Audio board. 4. If an Audio board is installed, perform the Remove Old Audio Board procedure starting on page 12. Audio board Eye board WVR6UP, WVR70UP, and WVR7UP Upgrades... - Page 20 NOTE. You can save the old Option Eye board for use in another instrument. c. Proceed to step 13 on page 22. Disconnect the coaxial cable from J8 on Main board Remove Eye board retaining screws WVR6UP, WVR70UP, and WVR7UP Upgrades...
- Page 21 NOTE. You can save the old Option Eye board for use in another instrument. c. Proceed to step 13 on page 22. Disconnect the two coaxial cables connected to J2 and J3 on the Loop-through board Remove Eye board retaining screws WVR6UP, WVR70UP, and WVR7UP Upgrades...
- Page 22 Remove the four nuts and washers that secure the four Loop-through BNC connectors to the rear panel. d. Back out the old Loop-through board until the connectors clear the rear panel and lift the board out of the chassis. WVR6UP, WVR70UP, and WVR7UP Upgrades...
- Page 23 Loop- -through board. e. Plug the ribbon cable from the old Loop-through board into the cable connector pins on the new Loop-through board and to the adjacent cable connector pins on the Main board. WVR6UP, WVR70UP, and WVR7UP Upgrades...
- Page 24 11. Remove the five Main board 4-40 mounting screws in the locations shown below. 12. Install the five spacer posts (Tektronix part number 129-1604-XX) from the kit in the locations from which you removed the mounting screws. Tighten firmly, but not excessively.
- Page 25 16. To remove the old Power Supply cable, disconnect the old cable from the Power Supply by firmly, but carefully, pulling the cable from the Power Supply pins on the Power Supply, and from the Power Supply pins on the Main board. WVR6UP, WVR70UP, and WVR7UP Upgrades...
- Page 26 17. Perform the following steps to install the new Power Supply cable: a. Lift the fan bracket (loosened in step 15) and route the new Power Supply cable (Tektronix part number 174-5224-XX) under the bracket and position the cable in the rectangular cut-out in the fan bracket. Make...
- Page 27 J1 connection of the Eye board. 19. Connect the remaining coaxial cable from the J2 connection of the Loop- through board to the J2 connection of the Eye board. 20. Verify that the installed Eye board appears as shown below. WVR6UP, WVR70UP, and WVR7UP Upgrades...
- Page 28 Ribbon cable Loop- - through board Connect the coaxial cable between J2 on Eye board and J2 on Loop-through board. Connect the coaxial cable between J1 on Eye board and J3 on Loop-through board. Eye board WVR6UP, WVR70UP, and WVR7UP Upgrades...
- Page 29 21. Connect the coaxial cable from the J1 connector on the Eye board to the J8 connector on the Main board. 22. Verify that the installed Eye board appears as shown below. Connect the coaxial cable between J1 on Eye board and J8 on Main board. WVR6UP, WVR70UP, and WVR7UP Upgrades...
- Page 30 26. Replace the top cover. WVR6100 and WVR7100 27. After installing the Eye board, go to to page 29 and perform the steps in the Option PHY Only Option Activation section. WVR6UP, WVR70UP, and WVR7UP Upgrades...
-
Page 31: Option Activation
NOTE. This kit provides an option key based on the instrument serial number that you provided to Tektronix when you ordered this kit. The kit option key enables your new option(s) only on the rasterizer having the serial number that you provided. - Page 32 Documents Browser on the CD or you can navigate to the PDFs and print them. H The latest versions of both the product software and the documentation are available at www.tektronix.com. g End of document g WVR6UP, WVR70UP, and WVR7UP Upgrades...
