1.8 Overview of Installation Area
1
1
PELV (Safe to touch)
1
RS-485 interface
2
Option slot A (can be used for GSM option, optional sensor interface, or PLA option)
3
Ethernet interface
4
Option slot A (can be used for GSM option, optional sensor interface, or PLA option)
Live Part
5
PV connection area
6
Communication board
7
AC terminal
Other
8
Security screw position
9
PV load switch
10
Security screw position
Illustration 1.3 Overview of Installation Area
6
