Technical Data
Nomen- Parameter
clature
Max. short-circuit
current DC (at STC)
Min. on grid power
Efficiency
Max. efficiency
Euro efficiency, V at
dc,r
Other
Dimensions (H, W,
D), inverter / incl.
packaging
Mounting
recommendation
Weight, inverter /
incl. packaging
4
Acoustic noise level
MPP trackers
Operation
temperature range
Nom. temperature
range
Storage temperature
Overload operation
Overvoltage
categories
Table 5.1 Specifications
1)
At rated grid voltage (V ), Cos(phi)=1.
ac,r
2)
To utilise the full range, asymmetrical layouts must be considered
including start-up voltage for at least 1 string. Achieving nominal
power will depend on configuration.
Nomen- Parameter
clature
AC
|S| Rated apparent
power
1)
P
Rated active power
ac,r
Active power at
cos(phi)=0.95
Active power at
cos(phi)=0.90
Reactive power
range
Nominal AC voltage
V
ac,r
(AC voltage range)
Rated current AC
5 6
- 97.8%
- 96.5%
667 x 500 x 233 mm / 774 x 570 x 356 mm
FLX series
10 12.5
10 kVA 12.5 kVA
10 kW 12.5 kW
9.5 kW 11.9 kW
9.0 kW 11.3 kW
0 - 6.0 kVAr 0-7.5 kVAr
3P+N+PE - 230/400 V (+/- 20 %)
3 x 14.5 A 3 x 18.2 A
L00410568-02_02 / Rev. date: 2013-12-10
FLX series
7
13.5 A per PV input
20 W
- 97.9%
- 97.0%
Mounting plate
38 kg / 44 kg
-
2
-25..60 °C
-25..45 °C
-25..60 °C
Change of operating point
Grid: OVC III
PV: OVC II
3)
At symmetric input configuration.
4)
SPL (Sound Pressure Level) at 1 m under normal operating
conditions. Measured at 25 °C.
15
15 kVA 17 kVA
15 kW 17k W
14.3 kW 16.2 kW
13.5 kW 15.3 kW
0-9.0 kVAr 0-10.2 kVAr
3 x 21.7 A 3 x 24.7 A
8 9
-
-
17
35
5 5
