Initial Setup and Start
Illustration 3.1 Overview of Display Buttons and Functionality
Key Function
F1 View 1/View 2 - Screen
F2 Status Menu
F3 Production Log Menu
F4 Setup Menu
Return to View Screen
Home
OK Enter/select
Arrow up A step up/increase value
Arrow A step down/decrease
Down value
Arrow Right Moves cursor right
Arrow Left Moves cursor left
Back Return/de-select
On - Green
LED
Alarm - Red
LED
The inverter is
configured as master.
This icon appears in the
top right corner.
The inverter is a
follower, connected to a
master. This icon
appears in the top right
corner.
Table 3.1 Overview of Display Buttons and Functionality
NOTICE
The contrast level of the display can be altered by
pressing the arrow up/down button while holding down
the F1 button.
The menu structure is divided into 4 main sections:
See the following sections for more detailed information.

3.2.1 Initial Setup via Display

The inverter is shipped with a predefined set of settings
for different grids. All grid-specific limits are stored in the
inverter and must be selected at installation. It is always
possible to see the applied grid limits in the display.
After installation, check all cables and then close the
LED
inverter.
Turn on AC at the mains switch.
When keys F1-F4 are
IP address can be found in the display during commis-
selected, the LED above
sioning.
the key will light up
When prompted by the display select language. This
selection has no influence on the operating parameters of
the inverter and is not a grid code selection.
On/flashing = On grid/
Connecting
Flashing = Fail safe
The language is set to English at initial start-up. To change
this setting press the [OK] button. Press [
through the languages. Select language by pressing [OK].
L00410568-02_02 / Rev. date: 2013-12-10
1.
View - presents a short list of information, read
only.
2. Status - shows inverter parameter readings, read
only.
3. Log - shows logged data.
4. Setup - shows configurable parameters, read/
write.
Illustration 3.2 Select Language
3
▼
] to scroll down
