Initial Setup and Start
Item Unit
Overall plant status -
Current production kW
Yield today kWh
Total revenue Euro
Total CO saving kg
2
Performance ratio %
Total yield kWh
Power limit adjustment %
Table 3.3 Information Displayed in Plant View, Overview Screen
NOTICE
To calculate performance ratio PR, an irradiation sensor
is required, see [Setup → Calibration].

3.3.6 Autotest Procedure

For certain grid codes, an automatic test of the inverter
can be initialised by activating the inverter autotest
procedure:
•
Via the web interface, go to [Inverter level: Setup
→ Setup details → Autotest] and click on [Start →
Test].
View Description
Plant and Inverter
Group
x Red: Plant PR <50%, or:
Any inverter in the network
- in fail safe mode, or
- missing from the scan list, no contact with the master
Yellow: Any inverter in the network
- with PR <70%, or
- in Connecting or Off grid mode
Green: Plant PR ≥70%, and
- all inverters with PR ≥70%, and
- all inverters in On grid mode
x Red: Inverter PR <50%, or inverter has an error
Yellow: Inverter PR between 51% and 70%, or inverter in Connecting
mode
Green: No errors, and
- inverter PR ≥70%, and
- inverter in On grid mode
x x Real time energy production level
x x Cumulative yield for the day
x x Cumulative revenue earned since initial startup
x x Cumulative CO
x x Real time performance ratio
x x Cumulative yield since initial startup
x Maximum power limit as % of nominal inverter AC output rating
L00410568-02_02 / Rev. date: 2013-12-10
saved since initial startup
