Proline Promag 53 MODBUS RS485
Endress+Hauser
2.1.3

Nameplate for connections

See operating manual
Betriebsanleitung beachten
Observer manuel d'instruction
XXXXXXXXXXX
1
Ser.No.:
Supply /
Versorgung /
4
Tension d'alimentation
26 = B (RxD/TxD-P)
27 = A (RxD/TxD-N)
3...30VDC, Ri = 3 kOhm
5
max. 60VDC/0.1A
max. 30VAC/0.5A
max. 60VDC/0.1A
max. 30VAC/0.5A
Ex works / ab Werk / réglages usine
6
Device SW:
7
Communication:
8
Drivers:
9
Date: 01. MAI 2009
Fig. 3:
Nameplate specifications for Proline transmitter connections (example)
1
Serial number
2
Possible configuration of current output
3
Possible configuration of relay contacts
4
Terminal assignment, cable for power supply:
Terminal No. 1: L1 for AC, L+ for DC
Terminal No. 2: N for AC, L– for DC
Pending signals at the inputs and outputs, possible configurations and terminal assignment → Page 47 ff.
5
6
Version of device software currently installed
7
Installed communication type
8
Information on communication driver
9
Date of installation
10
Language group
11
Current updates to data specified in 6 to 9
A:
P:
NO:
NC:
L1/L+
N/L-
PE
MODBUS RS485
STATUS-IN
RELAY
RELAY
Update 1
XX.XX.XX
(WEA)
XXXXXXXXXXXXXXXX
319475-00XX
active
passive
normally open contact
normally closed contact
1
2
X
NO
NC
Update 2
10
Identification
2
3
X
a0004362
9
