VQ Model VQA09 Building Instructions page 2

P-39 q/n airacobra radio controled almost ready-to-fly engine powered all balsa plane
Table of Contents

Advertisement

OPTIONAL ACCESSORIES / BENOTIGTES ZUBEHOR
Minimum 5 channel radio
for airplane with 5 servos
.Motor control x1
.Aileron x 2
.Elevator x1
.Rudder x1
(Purchase separately)
GLUE
SILICON
Silicon sealer
TOLLS REQUIRED
Hobby knife
Needle nose Pliers
Sander
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
Masking tape - Straight Edged Ruler - Pen or pencil - Rubbing alcohol - Drill and Assorted Drill Bits
If exposed to direct sunlight and/or heat, wrinkels can appear. Storing the
model in a cool place will let the wrinkles disappear. Otherwise, remove
wrinkles in covering film with a hair dryer, starting with
low temperature. You can fix the corners by using a hot iron.
Bei Sonneneinstrahlung und/oder Wärme kann die Folie erschlaffen bzw. Falten
entstehen. Verwenden Sie ein Warumluftgebläse (Haartrockner) um evtl. Falten aus der Folie
zu bekommen. Die Kanten können Sie mit einem Bügeleisen behandeln. Nicht zuviel Hitze anwenden !
Drill holes using the stated
size of drill
1.5mm
(in this case 1.5 mm Ø)
A B
Use epoxy glue
Read through the manual before you begin, so you will have an overall idea of what to do.
CONVERSION TABLE
3.0mm = 1/8"
1.0mm = 3/64"
4.0mm = 5/32"
1.5mm = 1/16"
5.0mm = 13/64"
2.0mm = 5/64"
6.0mm = 15/64"
2.5mm = 3/32"
10.5x6 for .40 - 2 cycle engine
11x6 for .46
11X7 for .52
.40-.45 - 2 cycle
Cyanoacrylate
Glue
Klebstoff
(Purchase separately)
Phillip screw driver
Scissors
!
Take particular care here
Apply cyano glue
CA
10mm = 13/32"
12mm = 15/32"
15mm = 19/32"
20mm = 51/64"
- 2 cycle engine
- 4 cycle engine
.52-.60 - 4 cycle
EPOXY A
CA
EPOXY B
Hatched-in areas:
remove covering
film carefully
Assemble left and right
L/R
sides the same way.
25mm = 1"
30mm = 1-3/16"
45mm = 1-51/64"
Extension for aileron servo
650 Watt
Silicone tube
Brushless motor
Epoxy Glue (5 minute type)
Epoxy-Klebstoff (5min-Typ)
Epoxy Glue (30 minute type)
Epoxy-Klebstoff (30min-Typ)
Hex Wrench
Awl
Wire Cutters
Check during assembly that these
parts move freely, without binding
Not included.
X
These parts must be
purchased separately
Low setting
