2.2. Printer View

External Views:
Front cover A
(left)
Exit cover
Rear side 2 cover
Stacker
________________________________________________________________________________________________
MICROPLEX
Top cover A (left)
Fig. 2.2.a Main view of the SOLID 166E
Operator's Manual SOLID 166E
Top cover B (right)
Stand cover
Skirt
Touch panel
Main
Frontend
switch
Front cover B
(right)
Paper input (tractor)
Edition 1.1
