APPENDIX B
USING THE ON-SCREEN DISPLAY MENU

Multi-Window menu options

Option
Multi-Window Mode
Audio Input
Window1
Window2
Window3
Window4

About menu options

Option
Model Number
Serial Number
Scalar firmware version
Touch firmware version
OPS Information
79 smarttech.com/kb/171167
Values Function
Off Sets the number of video inputs
that appear on the display's screen
Dual
to one (Off), two (Dual) or four
Quad
(Quad)
Window1 Sets the audio input source when
multiple video inputs are displayed
Window2
WIndow3
Window4
[Depends on the Select the video input for the first
model] window
[Depends on the Select the video input for the
model] second window
[Depends on the Select the video input for the third
model] window
[Depends on the Select the video input for the fourth
model] window
Values Function
[N/A] Shows the display's model number
[N/A] Shows the display's serial number
[N/A] Shows the display's scalar firmware
version
[N/A] Shows the display's touch firmware
version
[N/A] Indicates whether a module is
installed in the accessory slot
Notes
If you use this feature, be aware
that SMART doesn't support touch
while multiple input sources appear
on the display.
You can modify this option only if
you select Dual or Quad in
Multi-Window Mode.
You can modify this option only if
you select Dual or Quad in
Multi-Window Mode.
You can modify this option only if
you select Dual or Quad in
Multi-Window Mode.
You can modify this option only if
you select Quad in Multi-Window
Mode.
You can modify this option only if
you select Quad in Multi-Window
Mode.
Notes
[N/A]
[N/A]
[N/A]
[N/A]
[N/A]
