Terminal Identification - Altronix ReServ1 Installation Manual

ReServ Board
LED LED State
ON
Output
LEDs
------
ON
Low Battery
------
ON
Shutdown
------
ReServ Unit
Audio Signal
Single Periodic Beep
Double Periodic Beep Low Battery or No Battery.
Power Supply Board
Terminal
Function/Description
Legend
L, G, N Connect 115VAC 60Hz to these terminals: L to hot, N to neutral.
-- DC + 24VDC non power-limited output.
Form "C" dry contacts used to instantaneously signal the loss AC to local annunciation devices, with
AC FAIL
AC present terminals marked NO and C are open, NC and C are closed. When loss of AC occurs ter-
NO, C, NC
minals marked NO and C are closed, NC and C are open.
Form "C" dry contacts used to signal low battery voltage or loss of battery voltage. Under normal con-
BAT FAIL
ditions terminals marked NO and C are open, NC and C are closed. During a trouble condition termi-
NO, C, NC
nals marked NO and C are closed, and NC and C are open.
-- BAT + Stand-by battery connections. Maximum charge current 0.7A.
ReServ Board
Terminal
Function/Description
Legend
Input
24VDC input from power supply board.
--- 24VDC +
N, P 1-16 24VAC and/or 12VDC outputs.
The lightning flash with arrow head symbol within an equilateral triangle is intended to alert the user to the
presence of an insulated DANGEROUS VOLTAGE within the product's enclosure that may be of sufficient
magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- 4 -
LED Diagnostics (cont'd):
Unit Status
------ Normal operating condition.
OFF Loss of 24VAC and/or 12VDC output power.
------ Stand-by batteries are low.
OFF Normal operating condition.
------ Loss of 24VAC and/or 12VDC output power. Discharged stand-by battery.
OFF Normal operating condition.
Audio Signal Diagnostics:
Unit Status
AC Fail.

Terminal Identification:

CAUTION: To reduce the risk of electric shock do not open enclosure.
There are no user serviceable parts inside. Refer servicing to qualified
service personnel.
ReServ
