IX 2000 L, IX 2000 H
Colour Camera
Vicon Industries Inc. Does not warrant that the functions contained in this equipment will meet your requirments or
that the operation will be entirely error free or perform precisely as discribed in the documentation. This system
has not been designed to be used in life critical situations and must not be used for this purpose.
Copyright © 2006 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and ist logo are registered trademarks of Vicon Industries Inc.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAGE, NEW YORK 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116
24- Hour Technical Support: 800-34-VICON (800-348-4266)
UK: 44/(0) 1489-566300 WEB: vicon-cctv.com
Advertisement
Table of Contents
Related Manuals for Vicon IX 2000 L
Summary of Contents for Vicon IX 2000 L
- Page 1 IX 2000 L, IX 2000 H Colour Camera Vicon Industries Inc. Does not warrant that the functions contained in this equipment will meet your requirments or that the operation will be entirely error free or perform precisely as discribed in the documentation. This system has not been designed to be used in life critical situations and must not be used for this purpose.
-
Page 2: Table Of Contents
Dear Customer! By selecting this VICON product you have chosen a professional device which guarantees highest possible quality and reliability. We like to thank you very much for your confidence in our products and kindly ask you to read the following instructions carefully before commissioning the product in order to be able to take full advantage of all quality features regarding this product line. -
Page 3: General Information
GENERAL INFORMATION General Information Safety Precautions * Read these instructions carefully before commissioning the camera in order to avoid damages caused by improper installation or use. * Installation may only be carried out by authorised personnel according to the local safety regulations. -
Page 4: Mounting The Camera
MOUNTING THE CAMERA Mounting the Camera Mounting the Camera to a Wall Mount... -
Page 5: Commissioning The Camera
COMMISSIONING THE CAMERA Commissioning the Camera Tips for Camera Location 1.0 To avoid internal overheating: never expose the camera to direct sunlight without additional camera housing keep sufficient distance to direct heat sources. 2.0 Never install the camera at humid, oily or dusty locations without using an additional housing. -
Page 6: Adjustment Of Back Focus
COMMISSIONING THE CAMERA Adjustment of Back Focus This adjustment should only be carried out, if the lens cannot be focused properly using the lens focus ring. For such a case proceed as follows: 1 Loosen the Allan head screw with the attached Allan head key. -
Page 7: Focusing The Camera Lens
COMMISSIONING THE CAMERA Focusing the Camera Lens After you have selected the correct picture detail you have to adjust the lens focus. The focus adjustment needs to be done with the iris fully open, since the camera has the smallest depth of focus in this position. If the focus adjustment was not done with the iris completely open, the picture would be sharp during the day but slowly getting out of focus the more the light disappears. -
Page 8: Circuit Points And Operation
CIRCUIT POINTS AND OPERATION Circuit points and operation ATW // Hold: Rear view ATW: Auto tracking white balance, 12V DC / 24V AC Model adjust automatically Hold: the momentary colour value will be stored BLC : Backlight on / off AGC: AGC on / off AES // AI:... -
Page 9: Lens Mounting And Connection
CIRCUIT POINTS AND OPERATION Lens mounting and connection connection of AI lenses: connection of DC lenses: 1. +8,5 V 1. control – 2. not connected 2. control + 3. control signal 3. drive + 4. GND 4. GND... -
Page 10: Exhibit
TECHNICAL SPECIFICATIONS Exhibit Troubleshooting Error Cause No picture No operating voltage (check red LED) Coaxial connection interrupted (check video cable) The picture is noisy Insufficient light The lens drive of the used lens (DC / AI) is not properly adjusted to the camera (level too low) The picture is too bright The lens drive of the used lens (DC / AI) is not properly adjusted to the camera (level too high) -
Page 11: Technical Specifications
TECHNICAL SPECIFICATIONS Technical Specifications Model IXion 2000L IXion 2000H CCD SENSOR 1/3“ Interline Exview HAD CCD MAX. Pixel 470.000 Effective Pixels 440.000 752(H) x 582(V) Reolution 480 TV-Lines Sensitivity 0,1 Lux / F1.2 Enhancer (H- and V- Aperture) Gamma Correction 0,45 Auto Shutter 1/50 ~ 1/100.000 sek. -
Page 12: Cleaning And Care
CLEANING AND CARE Cleaning and Care Before you start to clean the camera body, disconnect the unit from power supply. For reasons of electrical safety never clean the camera with water or other liquid matters and never put the camera under water. To clean use a soft dry cloth. Cleaning the camera inside is strictly forbidden and may only be done by your authorised dealer. -
Page 13: Notes
NOTES -13-... - Page 14 NOTES -14-...
-
Page 15: Shipping Instructions
Use the following procedure when returning a unit to the factory: 1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the Vicon employee who issued the R.A. Vicon Industries Inc. 89 Arkay Drive Hauppage, NY 11788 Phone: 631-952-CCTV (2288);... - Page 16 Vicon Industries Inc. Corporate Headquarters 89 Arkay Drive Hauppage, New York 11788 631-952-CCTV (2288) 800-645-9116 Fax: 631-951-CCTV (2288) Vicon Europe Headquarters Brunel Way Fareham, PO 15 5TX United Kingdom +44 (0) 1489 566300 Fax: +44 (0) 1489 566322 Brussels Office...
