- Page 1 AWS-8124 Mini-Workstation with 12.1" LCD and 4 Slot Backplane...
- Page 2 Acknowledgments AWS-8124T, AWS-8124T-T, AWS-8124TP and AWS-8124TP-T series are all trademarks of Advantech Co., Ltd. IBM and PC are trademarks of International Business Machines Corporation. MS-DOS is a trademark of Microsoft Corporation. All other brand and product names mentioned herein are trademarks or registered trademarks of their respective owners.
- Page 3 FCC Class A This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commer- cial environment.
- Page 4 If anything is missing or damaged, contact your dealer immediately. • AWS-8124 with 12.1" TFT LCD display • Utility CD-ROM • AWS-8124 User's Manual • TSCB-9516 driver installation guide (Only for AWS-8124T-T and AWS-8124TP-T) • Accessories for AWS-8124: - HDD flat cable - Power cord...
- Page 5 The sound pressure level at the operator's position according to IEC 704-1:1982 is equal to or less than 70 dB(A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
- Page 6 - Wenn das Gerät deutliche Anzeichen eines Defektes aufweist. Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70dB(A) oder weiger. DISCLAIMER: This set of instructions is given according to IEC704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
-
Page 7: Table Of Contents
Contents Chapter 1 Introduction ............1 Description ............2 Specifications ............. 4 LCD specifications ..........6 Dimensions ............7 Panel mounting ..........8 Chapter 2 System Setup ............9 General ............. 10 Removing top cover and rear panel ....11 Adding cards ............ 12 Removing the protective cover ....... - Page 8 Appendix A Power Supply Specifications ..... 25 Power Supply: SNP-8086 (AC 100~230V/60Hz Input) SPECIFICATION ........26 A.1.1 INTRODUCTIONS ..........26 A.1.2 INPUT SPECIFICATIONS ......... 26 A.1.3 OUTPUT SPECIFICATIONS ......26 A.1.4 GENERAL FEATURES ........27 A.1.5 ENVIRONMENT SPECIFICATIONS ....28 A.1.6 INTERNATIONAL STANDARDS ......
- Page 9 Figures Figure 1-1: Dimensions ................7 Figure 1-2: Panel mounting ............... 8 Figure 2-1: Removing the top cover and rear panel ........11 Figure 2-2: Installing add-on cards ............12 Figure 2-3: Slide out the main chassis ............ 13 Figure 2-4: Installing an optional drive ............14 Figure 3-1: Detaching the passive backplane ...........
-
Page 11: Chapter 1 Introduction
Introduction • Description • Specifications • LCD Specifications • Dimensions • Panel Mounting Chapter 1 Introduction... -
Page 12: Description
CPU cards. The user interface of the AWS-8124 can be customized with additional components. Advantech is the leader in half-size tech- nology. When we designed the AWS-8124 series we took advan- tages of the half-size form factor to give you the tightest package possible. - Page 13 Features • Compact mini workstation / industrial man-machine interface • 4-slot passive backplane • NEMA 4/IP 65 front panel protection • 12.1" color TFT LCD display, with 800 x 600 resolution • Full-line of half-size plug-in cards available • 80-watt power supply •...
-
Page 14: Specifications
1.2 Specifications General • Construction: Heavy-duty steel chassis, hardened aluminum alloy front panel • Disk drive housing: Accommodates one 3½" FDD and one 3½" HDD (HDD optional) • LCD interface: 3.3V TTL • Compatiable CPU cards: PCA-6751/6752/6770 (for 8124T), PCI-6771 (for 8124TP) •... - Page 15 • Safety standards: UL/CSA/CE approved • EMI: Meets FCC class B (II) DC input: 12 V/ 24 V/ 48 V (optional by customer request) Environmental Specifications • Operating temperature: 32° to 122°F (O° to 50° C) • Relative humidity: 10% to 90% @ 40° C, non-condensing •...
-
Page 16: Lcd Specifications
1.3 LCD specifications Display type TFT Color LCD Size(diagonal) 12.1" Max. resolution 800 x 600 Max. colors or gray scales 256K colors Dot size (mm x mm) 0.3075 x 0.3075 Luminance (cd/m Viewing angel 90 (H) 40 (V) Temperature 0 ~ 50 C Brightness adjustment Contrast adjustment VR controls... -
Page 17: Dimensions
1.4 Dimensions Units = mm Figure 1-1: Dimensions Chapter 1 Introduction... -
Page 18: Panel Mounting
1.5 Panel mounting The AWS-8124 will stand on a shelf or a table, or you can mount it in a panel. Included with your AWS-8124, you’ll find three panel- mount brackets. The brackets have two screws that stick out and fit in the keyhole slots on the workstation chassis. -
Page 19: Chapter 2 System Setup
System Setup • General • Removing top cover and rear panel • Adding Cards • Protective cover • Installing optional drives Chapter 2 System Setup... -
Page 20: General
2.1 General When you receive your mini-workstation, you should be able to plug-and-play since we have already installed and tested the workstation’s components in the factory. However, if you need to customize the AWS-8124 yourself, you will see that it is a simple job. -
Page 21: Removing Top Cover And Rear Panel
2.2 Removing top cover and rear panel To access the backplane, remove the top cover and rear panel. First remove the five screws that secure the top cover, then remove the top cover (see Figure 2-1). After you remove the top cover, unscrew the six screws on the rear panel and remove the rear panel. -
Page 22: Adding Cards
2.3 Adding cards The 4-slot passive backplane accepts half-size CPU and I/O cards. Slot number S4 has a little bit more space than the other slots. This slot lets you insert a CPU card with an on-board piggyback/PC-104 module. We strongly recommend these all-in-one cards, for they are durable and save valuable slot space by bundling a CPU with hard disk and floppy disk controllers, as well as serial and parallel ports. -
Page 23: Removing The Protective Cover
2.4 Removing the protective cover To reach the disk drives, power supply and monitor you must slide the main chassis out of its protective cover. First remove the top cover and rear panel as described in section 2.2. Remove the three screws on the side panel just above the card brackets. -
Page 24: Installing Optional Drives
2.5 Installing optional drives The AWS-8124 offers space for two disk drives. When you receive the station, a 3½” floppy drive is already installed. Only the upper drive bay offers access through the floppy disk door. The lower position should therefore be reserved for an optional HDD. To install the optional drive first remove the protective cover completely (see section 2.4). -
Page 25: Chapter 3 Maintenance
Maintenance • Passive backplane • Power Supply and cooling fan • Flat panel Display • LCD backlight Chapter 3 Maintenance... -
Page 26: The Passive Backplane
3.1 The passive backplane Four screws secure the 4-slot passive backplane to the inside of the AWS-8124 chassis. To service or replace the backplane, remove the top cover. There is no need to slide the main chassis out. Remove the four screws that secure the backplane to the chassis. -
Page 27: Power Supply And Cooling Fan
3.2 Power supply and cooling fan To service or replace the power supply and cooling fan, first remove the protective cover. (See section 2.4) To reach the power supply you must first remove the cooling fan. Four screws connect the fan to the chassis. Unscrew the fan and disconnect its power cable. -
Page 28: The Flat Panel Display
(See Figure 3-3). Note: We recommend that you leave display service and repair to your supplier Contact Advantech’s Cus- tomer Service Department for additional informa- tion on the displays. Figure 3-3: Disconnecting the display... -
Page 29: Lcd Backlight Replacement
3.4 LCD backlight replacement In the normal working life of the AWS-8124 you will seldom need to replace the LCD backlight. If it's necessary to maintain the LCD backlight, plaese contact your distributor, sales representative, or Advantech's customer service center. Chapter 3 Maintenance... - Page 30 AWS-8124 User's Manual...
-
Page 31: Appendix A Power Supply Specifications
Power Supply Specifications • SNP-8086 (AC 100~230 V/60 MHz Input) • D12-4081 (DC 12 V Input) • SNP-4081 (DC 24/48 V Input) Appendix A Power Supply Specifications... -
Page 32: Power Supply: Snp-8086 (Ac 100~230V/60Hz Input) Specification
A.1 Power Supply: SNP-8086 (AC 100~230V/ 60Hz Input) SPECIFICATION A.1.1 INTRODUCTIONS The SNP-8086 is a 72-watt (convection cooling) / 100-watt (forced air cooling) dual-output switching power supply. It is especially designed for use with Network and Telecommunications Equip- ment. A.1.2 INPUT SPECIFICATIONS Universal AC Input Voltage The range of input voltage is from 85V to 264V... -
Page 33: General Features
At the factory, the +5 V output is set between 5.OOV to 5. 10 V at 60% rated load, and the + 12 V Output is checked to be within the accuracy range. The adjustable range for the +5 V output is ± 5 %. Note: +12 V output voltage will track the adjustment. -
Page 34: Environment Specifications
The built-in crowbar circuit will shut down the outputs to avoid damaging the external circuits. The trip point of over voltage protection is around 6.4 V to 7.4 V. To recover from over voltage protection, cycle the AC line OFF and ON to make it restart. Short circuit protection The power supply will generate a hiccup mode to protect itself against short circuit or over load conditions, and will return to... -
Page 35: Power Supply: D12-4081 (Dc 12V Input) Specification
A.2 Power Supply: D12-4081 (DC 12V Input) SPECIFICATION A.2.1 INTRODUCTIONS The D12-4081 is a 74 watts DC to DC switching power supply with a nominal input of 9 or 18 V DC, it is designed for general purpose. A.2.2 INPUT SPECIFICATIONS DC Input Voltage to 18 V Input Current... -
Page 36: General Features
Line regulation The line regulation is less than ±1% at rated load with ±10% change in input voltage. Load regulation The load regulation for +5 V is less than ±1 %, for +12 V outputs is less than ±5 %, for -12 V outputs is less than ±10 %, while the measuring is done by changing the measured output loading ±40 % from 60 % rated load, and keep other output is at 60 % rated load. -
Page 37: International Standards
Altitude: will operate properly at any altitude between 0 to 10000 ft. Humidity: 10 % to 90 % (Non-condensing). B.2.6 INTERNATIONAL STANDARDS Safety standards UL 1950 CSA 22.2 NO. 234 VDE EN 60 950 EMI standards Designed to meet the following radiation limits: FCC docket 20780 curve “B”... -
Page 38: Power Supply: Snp-4081
A.3 Power Supply: SNP-4081 (DC 24/48V Input) SPECIFICATION A.3.1 INTRODUCTION The SNP-4081 is a 74 watts DC-to-DC switching power supply with a nominal input of 24 or 56 VDC. It is designed for general purpose. A.3.2 INPUT SPECIFICATIONS DC Input Voltage 18 V to 56 V Input Current... -
Page 39: Environment Specifications
Line regulation The line regulation is less than ±1 % at rated load with ±10 % change in input voltage. Load regulation The load regulation for +5 V is less than ±1 %, for + 12 V outputs is less than ±5 %, for -12 V outputs is less than ±10 %,while the measuring is done by changing the measured output loading ±40 % from 60 % rated load, and keep other output is at 60 % rated load. -
Page 40: International Standards
Altitude: will operate properly at any altitude between 0 to 10000 ft. Humidity: 10 % to 90 % (Non-condensing). A.3.6 INTERNATIONAL STANDARDS Safety standards UL 1950 CSA 22.2 NO. 234 VDE EN 60 950 EMI standards FCC docket 20780 curve “B” EN55022 “B”...
