  • Page 1 AWS-8248V Industrial Workstation with 15" LCD Display User’s Manual...
  • Page 2 Acknowledgements AWS-8248VT, AWS-8248VTP, AWS-8248VT-T, and AWS-8248VTP-T are all trademarks of Advantech Co., Ltd. IBM and PC are trademarks of International Business Machines Corporation. MS-DOS is a trademark of Microsoft Corporation. All other brand and product names mentioned herein are trademarks or registered trademarks of their respective owners.
  • Page 3 FCC Class A This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interfer- ence when the equipment is operated in a commercial environment.
  • Page 4 If any of these items is missing or damaged, contact your distributor or sales representative immediately. Additional Information and Assistance 1.Visit the Advantech web site at www.advantech.com where you can find the latest information about the product. 2.Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance.
  • Page 5 Safety Instructions 1. Read these safety instructions carefully. 2. Keep this User's Manual for later reference. 3. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for cleaning. 4. For plug-in equipment, the power outlet socket must be located near the equipment and must be easily accessible.
  • Page 6 - Wenn das Gerät deutliche Anzeichen eines Defektes aufweist. Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70dB(A) oder weiger. DISCLAIMER: This set of instructions is given according to IEC704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. AWS-8248V User’s Manual...

  • Page 7: Table Of Contents

    Contents Chapter 1 Introduction ............2 Introduction ............... 2 1.1.1 Features:................3 Specifications ..............3 Front and rear panel layout..........5 Dimensions................ 6 Chapter 2 System Setup.............8 General ................8 Rack mounting ..............9 Figure 2.1:Rack mounting the AWS-8248 ..... 9 Panel mounting..............
  • Page 8 AWS-8248V User’s Manual viii...

  • Page 9: Chapter 1 Introduction

    Introduction • Introduction • Specifications • Front and rear panel layout • Dimensions...

  • Page 10: Introduction

    Chapter 1 Introduction 1.1 Introduction The AWS-8248V is a 14-slot, 15” TFT LCD workstation. It is a great update to the AWS-8248 product line by offering more expansion capa- bility, a larger LCD screen, and increased usability, all at an even more competitive price.

  • Page 11: Features

    1.1.1 Features: • Low cost 15", 14-slot TFT LCD workstation, and 1024 x 768 resolution • Three card-cage design: Easy to maintain add-on cards, CPU card and power supply. • Two 3.5î HDDs with mobile rack drive & CD-ROM drive in back of chassis •...
  • Page 12 - Backlight lifetime: 50,000 hours - Interface: Direct VGA - LCD defect specification: refer to Advantech web site Front Panel • Keypads: One with 39 operating keys, one with 10 function keys and 10 programmable macro function keys • Keyboard connector: Pre-wired 5-pin DIN connector with dust- protection cover on front and rear panel •...

  • Page 13: Front And Rear Panel Layout

    24 V input 250 W (optional) • Input voltage: 19 ~ 32 V • Output voltage: +5 V @ 25 A; +12 V @ 10 A; -5 V @ 1.0 A; -12 V @ 1.0 A • MTBF: 100,000 hours Environmental specifications •...

  • Page 14: Dimensions

    Figure 1.2: Rear panel layout 1.4 Dimensions Figure 1.3: AWS-8248 dimensions AWS-8248V User’s Manual...
  • Page 15 System Setup • General • Rack Mounting • Panel mounting...

  • Page 16: Chapter 2 System Setup

    Chapter 2 System Setup 2.1 General When you receive your workstation you will find a backplane, power supply, and floppy disk drive already installed. Further setup of the AWS-8248V is easy. All you have to do is slide out its work drawer mod- ule, install a CPU card, optional hard disk drive and whatever additional I/O cards your application requires.

  • Page 17: Rack Mounting

    2.2 Rack mounting The AWS-8248 can be mounted in a 19" rack. Ensure that all addi-tional equipment has been installed correctly and that the cabling has been reat- tached. (See Fig. 2-7) Remove the screw covers on the front panel. Attach the case to the rack using screws on both sides.

  • Page 18: Panel Mounting

    2.3 Panel mounting Panel mounting the AWS-8248 is easy. Just line up the holes in the panel aperture and the holes on the panel, and then secure the AWS-8248 to the panel with the mounting bolts. Figure 2.2: Panel mounting the AWS-8248 AWS-8248V User’s Manual...
  • Page 19 Programming KBT-2002 Macro Keys • Introduction • Macro Keys • Using Main.exe to edit Macro Key • Examples...

  • Page 20: Chapter 3 Programming Kbt-2002 Macro Keys

    Chapter 3 Programming KBT-2002 Macro Keys 3.1 Introduction The KBT-2002 is equipped with programmable function keys (macro keys) that greatly enhances the operating interface. Macros, which are far more powerful than batch files; automate the most commonly used input sequences. They extend their functional reach within application pro- grams.

  • Page 21: Examples

    There ís an example within the subdirectory of the utility disk. Go into this subdirectory and look for a .txt file that corresponds to your worksta- tion, for example, AWS8420.txt. You can use this file under the macro key edit program to practice. Note 1: The keyboard translator utility main.exe pro- gram can be run under DOS mode only.
  • Page 22 Choose Load in the function and press the enter key. Key in the file name that you edited in this program before. To practice, you can choose, for example, the AWS8420.txt in the example in the utility disk. After read- ing the file, press Esc key to leave this mode.
  • Page 23 n this sub screen, you can key in any character string that you want to see when pressing this macro key, or any signs. You can also key in the names of the function keys of the keyboard; but please add a [ ] sigh. The number characters you key in should be under 78.
  • Page 24 Choose Run in the main menu, and press Enter to go into the Run (pro- gramming) mode. You will see a sub-screen for upper key setting OFF= Press both character and upper key in the same time ON= Press upper key.
  • Page 25 After the beep sound setting, press Enter and you will be asked to key in a .pad file name. Please refer to chapter 1.3. Do not use any other file names other than that of this workstation, or character definition errors might arise! After keying the file name, press Enter, The system will start to read the data in the file together with the data in the .txt file that you just edited...
  • Page 26 After the system finished the programming, you will see a sub-screen that tells you to repeat the process again or press Esc to leave the Run mode. Note: There might be transition error when the con- nection cable between the CPU card and the keyboard translator is too long.
  • Page 27 Display Timing Mode & • Supported input timing modes • OSD operation keypad • OSD function and operation...

  • Page 28: Appendix A Display Timing Mode And Osd

    Appendix A Display Timing Mode and OSD A.1 Supported Input Timing Modes The following nineteen kinds of timings have already been programmed in this module. The input synchronous signals are automatically recog- nized. Table A.1: Display Modes Table Chroma Resolution HSYNC / VSYNC / PIXEL...
  • Page 29 Table A.1: Display Modes Table Chroma Resolution HSYNC / VSYNC / PIXEL REMARK 2325 KHz (+/-) Hz (+/-) RATE / Timing No. #008 31.469 (+) 70.087 (-) 25.175 640 * 350 #041 VESA 60.023 (+) 75.029 (+) 78.750 1024-75 #042 VESA 68.677(+) 84.996(+)

  • Page 30: Osd Operation Keypad

    Note 2: This module recognizes the synchronous sig- nals with near preset timing of the frequency of the HS and Vsync, even in the case that the signals other than the preset timing that were entered. Note 3: Because adjustments may not fit, such as dif- fering magnifying ratios or, in the case that you use it except for the display timing that was pre- set.

  • Page 31: Osd Function And Operation

    A.3 OSD function and operation Auto-adjustment process or to adjust manually: Press [Sel] button to display the OSD Menu shown below. Press button to scroll to the desired menu option. Press [Sel] button to select the menu option. Press button to adjust the setting. Press [Exit] button or wait until time out to save changes and exit the menu or sub-menu.
  • Page 32 Table A-3 is the OSD menu hierarchy and function description. Table A.3: OSD Functionality Main Menu Sub Menu Sub Menu Functionality Brightness Reset Adjust display Brightness brightness Contrast Contrast Reset Contrast Adjust RGB contrast simulta- neously R Sub Contrast Reset R Contrast Adjust R contrast G Sub Contrast Reset G Contrast...
  • Page 33 Power Supply Specifi- cation • 250 watt power supply • -48 VDC power supply • 24 VDC power supply...

  • Page 34: Appendix B Power Supply Specifications

    Appendix B Power Supply Specifications B.1 Supported Input Timing Modes The AWS-8248 off-line switching power supply is ideal for use in work- stations. It has been designed to meet UL, CSA and TUV safety stan- dards. It has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 35: 48 V Dc Power Supply

    B.2 -48 V power supply The following specifications describe the physical and electrical charac- teristics of a 310 W, four output, DC to DC switching power supply housed in a standard size PS/2 casing. B.2.1 Specifications Input voltage: 36~72V (continuous operation) -48 VDC (normal operation) Input current: 10 A max.
  • Page 36 Overshoot (resistive load): Any output overshoot when the power is turned on does not exceed 10% of the nominal output voltage. Output power: Maximum continuous: 310 W Power good and power fail signals (optional): When the power is turned on, the power good signal will activate 100 to 500 ms after all output DC voltages are operating within their respective regulation limits.
  • Page 37 Reset time: When the power supply has automatically shut down, and the short cir- cuit, over-current and/or over-voltage conditions have ceased to exist, power will be automatically recycled to restart the power supply within 3 seconds of such return to normal conditions. No load start: When the power supply is switched on but with no load connected, the power supply does not get damaged, and it is still completely safe for...
  • Page 38 DC Output wire list All DC output cables use UL 1007 type wires. Wire Length Connector Output Color Housing Terminal #AWG (mm) P8-1 Orange P8-2 +5 V BURNDY BURNDY P8-3 +12 V Yellow GTC 6P-1 DCK 18-2TR9 +30/-10 P8-4 -12 V Blue or equivalent equivalent...

  • Page 39: 24 Vdc Power Supply

    B.3 24 V power supply This is a DC to DC switching mode power supply with a 24 V input. Input voltage:+19 ~ +32 V (normal operation) Input current:16 A max. @ +24 V input Inrush current:10 A max. @ +24 V input Output load range: Output...

  • Page 40: General Features

    Line regulation: The output line regulation for each output is less than ±1%, when mea- sured at each output’s respective rated load and under ±10% changing input voltage conditions. Load regulation: The values for each of the following output numbers were obtained by changing each output load ±40% from the 60% rated load, whilst simulta- neously keeping all other outputs at 60% of their respective rated loads.
  • Page 41 Touchscreen (optional) • Installation of touchscreen driver...

  • Page 42: Appendix C Optional Touchscreen

    Appendix C Optional Touchscreen C.1 Specifications Electrical Operating Voltage: 3.3 to 5 VDC typical 220 ± 30% W/square Sheet Resistance: Linearity: +/- 1.5% full scale linearity error in either direction. > 20 ΜΩ @ 25 VDC. Insulation Resistance: Optical Total light Transmission: 68% typical (> 66% @ 550 nm test) Environmental Operating Temperature Range: -20°C to +50°C, ambient humidity...

  • Page 43: Installation Of Touchscreen Driver

    Durability Point Activation Life: 1 Million activations on a single point with a 5/8” diameter silicone finger with a 350g load at 2 Hz Character Activation Life: >100,000 characters written within a 20mm x 20mm C.2 Installation of Touchscreen Driver The touchscreen for the AWS-8248 Series provides drivers for use with MS-DOS,Windows 3.1, 95, 98, NT, 2000, XP.
  • Page 44 AWS-8248V User’s Manual...
