Analog Outputs Diagrams - ABB 07CR41 Operating Manual

Current input 0-20 mA:
Current input 4-20 mA:
3.6.4

Analog outputs diagrams

Current 4-20 mA:
Current 0-20 mA:
3
Technical specifications
12
1 LSB = 20 mA/2 = 4.88 µA
Current input in
=
PLC value
20 mA
0 ≤ PLC value ≤ +32.767
Resolution is equal to 0-20 mA
Current input in
=
PLC value
20 mA
0 ≤ PLC value ≤ +32.767
With current input <3.75 mA the PLC value is = –32767
with minimum value (step 8)
mA
×
32767
mA
×
32767
3 – 22
Advant Controller AC 31 / Issued: 01.99
