Oracle MiniCluster S7-2 Service Manual page 26

Replace a Storage Array Power Supply (CRU)
Callout
1
2
3
4
5
6
7
If any of the indicators are amber, or if the power supply status indicator does not light, replace
the power supply.
1. Ensure the power supply on/off switch is in the "O" off position.
2. Disconnect the power cord tie strap from the power cord, and unplug the power
cord from the power supply.
3. Remove the power supply unit.
26 Oracle MiniCluster S7-2 Service Manual • March 2017
Description
AC power fail indicator
Fan fail indicator
Power supply status indicator
DC power fail indicator
Release lever
AC connector
On/Off switch
