Storage Array Hot-Swappable Components

"Servicing Fan Modules" in SPARC S7-2 Server Service Manual
■
"Servicing Power Supplies" in SPARC S7-2 Server Service Manual
■
Storage Array Hot-Swappable Components
This section describes replacing hot-swappable components for the storage array.
Hot-swappable components are those that can be removed and installed while the system and
the compute nodes are running without requiring any administrative tasks. These are designated
as Customer Replaceable Units (CRUs).
Caution -
storage expansion shelf (if equipped) while the database is running. If you must power off the
storage array or expansion storage array, stop the database first.
Note -
or SAS cable), you should wait before performing the next action to allow the system software
to fully process the event. This could take up to 3 minutes to complete.

Replacement Procedures

These storage array components can be replaced while the storage array is powered-on and
running:
"Replace a Storage Array HDD or SSD (CRU) " on page 18
■
"Replace a Storage Array Power Supply (CRU)" on page 24
■
"Replace a Storage Array I/O Module (CRU)" on page 28
■
Replace a Storage Array HDD or SSD (CRU)
Use these procedures to replace a storage array HDD or SSD.
"Remove a Storage Array HDD or SSD (CRU)" on page 19
■
"Install a Storage Array HDD or SSD (CRU)" on page 22
■
18 Oracle MiniCluster S7-2 Service Manual • March 2017
Data loss. Do not remove power from both power supplies of the storage array or
After a physical insertion or removal action of a storage array component (such as a disk
