Replace a Storage Array I/O Module (CRU)
Replace a Storage Array I/O Module (CRU)
Storage array SAS I/O modules are fully redundant and can be replaced while the appliance is
running.
1.
Disconnect the cables from the I/O module.
Be sure to mark the cables so you can return them to their proper connectors.
Callout
1
2
3
Remove the I/O module.
2.
28
Oracle MiniCluster S7-2 Service Manual • March 2017
Description
I/O module locking levers
I/O module 1 (top)
I/O module 0 (bottom)
