Parameter Operating Examples

Example (HART): Change the length unit from m to mm.
The example begins at the multi-display (1). Follow the bold arrowed path to complete the
task. Use the arrow buttons shown next to the numbered operation steps.
Function group
1 Auto-Setup
Function group
2 Display
Function group
3 Diagnostics
Function group
4 Device data
Page 22 SITRANS LR 400 (Solids) – INSTRUCTION MANUAL
+12,300 m
+30 dB
4. Device data
1 Units
4. Device data
2. Operating param.
4. Device data
3 Analog output
4.1 Units
1 Length Unit
4.3 Analog output
1 AO select
4.3 Analog output
2 Level param.
4.1.1 Length unit
m
4.1.1 Length unit
mm
4.3.1 AO select
Level
4.3.2 Level param.
1 Level URV
7ML19985JC02
