- Page 2 EKX6TQGGDH-92 PRE-ASSEMBLY CHECK LIST ITEM# DESCRIPTION Frame Upper Frame Cover Upright Grab handle cover Rear stabilizer assembly Handle assembly Rocker left Rocker right Left pedal assembly Right pedal assembly Handle assembly left Handle assembly right Computer Frame rear cover Plastic pedal set left Plastic pedal set right Grab handle cover-left front Grab handle cover-left rear...
- Page 4 Assembly Screws ITEM# DESCRIPTION Washer Ø22xØ9x2t Washer Ø25xØ9x2t Wave Washer Ø17.5xØ26x0.3t Truss hex screw M8x20(SAE82046) Arc Washer SCB2085 Truss hex screw M8X20 Cylinder hex screw M8X58 Washer Ø25X Ø 8.5x2t Truss hex screw M8X45 Truss hex screw M8X95 Truss hex scrw M12xP1.75x35 15 Nylon Nut M12xP1.75，19 Round head Philips screw M6X20 Truss Philips screw M4X12...
-
Page 6: Assembly Instructions
ASSEMBLY INSTRUCTIONS 1. Assemble Rear Stabilizer (#70) to Frame (#1) with Screw (#132),Spring washer(#163) Washers (#133) first and then tight the truss hex screw(#135),Spring washer(#163),Arc washer(#157),Nut(#153) on Rear Stabilizer (#70) and Frame (#1) . Control wire ±± ¨ î ½ u ±±... - Page 7 ASSEMBLY INSTRUCTIONS Handle pulse sensor wire ¤â ´ ¤ ¤ ß ¸ õ · P À ³ ½ u ±± ¨ î ½ u ¤ ¤ ¬ q Middle Control wire 3. Connecting the wire that from upright with upper control wire that from(#108), and then tight the fixed the computer(#108) on the upright(#62) with truss Philips screw(#113).
-
Page 8: Grab Handle Cover
ASSEMBLY INSTRUCTIONS 5. Set Grab handle cover (#63) and Wave Washer (#128) on the Upright. Assemble left and right Rocker (#75,76) to Upright with Screw (#151) and Washers (#149, 127). When assembly, pay attention to the “L” and “R” tabs on the Handrails. 6. - Page 9 ASSEMBLY INSTRUCTIONS 5. Set Grab handle cover (#63) and Wave Washer (#128) on the Upright. Assemble left and right Rocker (#75,76) to Upright with Screw (#151) and Washers (#149, 127). When assembly, pay attention to the “L” and “R” tabs on the Handrails.
- Page 10 6. Aim at the “L” and “R” tabs on Handrail and Rocker and then tight the left & right Handrail (102, 103)and left & right rockers (75, 76) with Screw (131), Truss hex screw(134),Washers (163,130) and Nylon Nut (153).. ASSEMBLY INSTRUCTIONS 7.
-
Page 11: Handle Assembly
8. Assemble Pedal(L&R) (#115,116) to left and right Pedal Assembly (#93,94) with Screw (#138). ASSEMBLY INSTRUCTIONS Á ³ ¥ À ½ Õ ¾ ã ¸ } ¹ Ô Adjust foot pad 9. Adjust frame’s level, let middle adjustment foot pad higher to the frame hang in the air. Then adjust rear adjustment foot pad of the frame to let frame be level and adjust middle adjustment foot pad to floor. -
Page 12: Glide Rail Cover
ASSEMBLY INSTRUCTIONS Glide rail 11. Assembly the Joint Pole Cover （ 122,123） on the left and right Rocker with Philips screw(139), Then assembly glide rail cover（121）with truss Philips screw（140） in glide rail, Can be appropriately lay on the Silicon（148）on the glide rail. -
Page 13: Glide Rail Connecting Rod
12. Assembly glide rail connecting rod cover(124,125) on the Rear stabilizer assembly(70) with Philips screw(139), and the tighten the glide rail connecting rod cover(124,125) with Philips screw(141) ASSEMBLY INSTRUCTIONS 13. Insert Adapter (#126) into power plug of Frame (#1). Be sure to check the Adapter’s parameters before plug (such as input and output voltage). - Page 16 Operation Instruction I. Power Mode: 1. Boot mode: after open the power, the buzzer long call and display all screen (Figure 1), and after 2 seconds entering the user settings screen (Figure 2). 2. Dormancy model: When no any operation or no RMP signal input after 4 minutes, The meter will enter the dormancy model, can be sport or press any key to awaken the meter.
- Page 17 III. Program mode setting: Under the sports program mode, press ▲ or ▼ key to cyclic selection the sport mode as below.. MANUAL→PROGRAM→FITNESS→WATT→PERSONAL→H.R.C.→RAND 1. MANUAL Mode If Press ENTER key to confirm select the MANUAL Mode, Enter the resistance LEVEL setting: press ▲ or ▼ key to setting the resistance level Press ENTER key to confirm the resistance level and enter the target TIME setting: press ▲...
- Page 18 5. PERSONAL Mode If press ENTER key to confirm select PERSONAL mode to enter the resistance LEVEL setting: Press ▲ or ▼ key can setting the resistance level of the first line, Press ENTER key to confirm and enter to next resistance level setting. Long press ENTER 3seconds to save the personal figure and enter the target time setting, press ▲...
- Page 19 Display result Status Wonderful Very good Good Normal Poor Very Poor ● Test result V. Key function instruction: 1. START/STOP Key: Under anyone sport mode, press this key can be start the motion directly. Under the motion mode, press this key can stop the motion, press this key again can continue the motion.
- Page 20 DISTANCE 0.0 - 99.99 CALORIES 0 - 999 SPEED 0.0 - 99.9 PULSE 30 - 200 bpm 0 - 250 rpm USER U0-U4 BRAKE RESISTANCE LEVEL L1 - L24 VII. Figure Instruciton: 1. Program mode figure: ● MANUAL ● PROGRAM ●...
- Page 21 ● P4 ● P5 ● P6 ● P7 ● P8 ● P9 ● P10 ● P11 ● P12...
- Page 22 3. H.R.C. (55%, 75%, 90%, Tag) ●HRC(55%) ●HRC(75%) ●HRC(90%) ●HRC(Tag)
