SPECIFICATIONS

Product
Uplink Frequency Range (MHz):
Downlink Frequency Range (MHz):
Input / Output Impedance:
Maximum Gain:
Gain Adjustment:
Supported Standards:
Noise Figure:
VWSR:
Maximum Output Power:
DC Power:
Cable:
RF Connectors:
Power Consumption:
Operation Temperature:
Dimensions:
Weight:
Certification:
Note: The term "IC" before the radio certification number only signifies that Industry Canada technical specifications were met.
FusionTrek (US)
698-716 / 776-787 / 824-849 / 1850-1915 / 1710-1755 (G Block Included)
728-746 / 746-757 / 869-894 / 1930-1995 / 2110-2155 (G Block Included)
50 Ω
23 dB
20 dB (Automatic)
CDMA, WCDMA, GSM, EDGE, HSPA+, EVDO, LTE and all cellular standards
≤ 7 dB
≤ 2.0
1 Watt EIRP
8-15VDC
SC-174, 15 ft
SMA Female
< 12W
14° F – 122º F
7.5 x 3.5 x 1.16 in
.62 lbs (9.92 oz)
FCC ID: RSNF-TREK
SureCall | www.surecall.com | 1-888-365-6283 | support@surecall.com
Specifications
FusionTrek CA (Canada)
IC: 7784A-FTREK
9
