Kitting Information

ANTENNA KITTING INFORMATION

Component Prod No. Description
FusionTrek Kit
Outdoor Antenna WPANT10104-S3A
(SC325W-WP)
Indoor Antenna SC128W
Indoor Cable SC-174-15FT (15 Feet)
*All equivalent antennas and cables are suitable for use with the FusionTrek
As above information. Remark: Lower gain antenna can also be used.
* Warning: Unauthorized antennas, cables, and/or coupling devices are prohibited by FCC new rules. Changes or modifications not
expressly approved by SureCall could void the user's authority to operate the equipment.
* FCC 27.50(d)(4) Statement: Fixed, mobile and portable (hand-held) stations operating in the 1720-1755 MHz band are limited 1 Watt
EIRP. Fixed sta tions operating in this band are limited to a maximum antenna height of 10 meters above ground. Mobile and portable
stations operating in this band must employ a means for limiting power to the minimum necessary for successful communications.
10
Gain/Loss
LTE-A
0.5dBi
-0.1dBi
3.4dB
SureCall | www.surecall.com | 1-888-365-6283 | support@surecall.com
1900
LTE-V 800 MHz MHz
0.5dBi 2dBi 2dBi
-0.1dBi -0.3dBi 3dBi
3.4dB 3.7dB 6dB
Notes
1700 MHz /
2100 MHz
3dBi\3dBi Integrated
antenna
2.5dBi\3.2dBi
5.5dB \6.2dB
