STEP 1: MOUNT BOOSTER ON/NEAR REAR WINDOW

a. Installation Using Adjustable Window Suction Mount
1. Remove the back part of the window suction mount bracket by
pressing on the release.
2. Identify a high and centered location on the back window and clean
location.
3. Lift the lever on the adjustable window mount, place firmly onto the
window and press down on the lever to lock in place.
4. Press the booster back into the mounted adjustable window mount
bracket.
Adhesive
base
Mount booster in the center of your inside back window using one
of the two options below. We suggest using the adjustable window
mount option for vertical or near-vertical windows and the adhesive
base mount for windows that are more angled, like sedans. For both
installations you need to place the booster as close to the rear window
as possible. For best performance, be sure the booster is mounted
vertically with the SureCall logo facing the front of the vehicle.
Ensure that the antenna has at least a 12-inch radius clear of obstruc-
tions and other radiating elements, such as a radio antenna.
Note: The outside antenna must not be collocated or operating with any other antenna or booster.
b. Installation Using Adhesive Base
1. Find a flat and horizontal surface near the rear window and the use
alcohol pad to clean the mounting location.
2. Remove the backing from the adhesive strip and press the booster
down firmly on to the mounting location.
SureCall | www.surecall.com | 1-888-365-6283 | support@surecall.com
Installation
Release
Ball Joint
Nut
Lever
Connector
