Replaceable Parts
Cables
Table 2-4
(Continued)
Reference Designator
W95
(Options 550 & 567)
W96
(Options 550 & 567)
W97
(E8267D)
W98
(E8267D)
W99
(E8267D)
(Options 532 & 544)
W100
(E8267D)
(Options 532, 540, & 544)
W101
(E8267D)
(Options 532 & 544)
W102
(E8267D)
(Options 532 & 544)
W103
(E8267D)
(Options 532 & 544)
W104
(E8267D)
W105
(E8267D)
W106
(Options 550 & 567)
W107
(Options 550 & 567)
W108
(Options 550 & 567)
W109
(Options 550 & 567)
W110
(Options 532 & 544)
E8257D/67D, E8663D PSG Signal Generators Service Guide
Input
A10J202
A11J206
A35J8
A30J1
A37J7 (backside)
A27J2 (RF out)
A28
A37J4 (RF out)
A30J2
A27J1
A35J4
A36J1
A36J2
A36J4
A10J201
A10J202
Output
A36J6
A36J5
A37J8
A37J2
A26J34
A37J5 (LO in)
A39 Directional Sweep Coupler (input) E8251-20331
Semi-Rigid Cable,
A24 50 GHz Highband Coupler (input)
A37J3
A35J3
A29J3
A30J4
A30J2
A30J6
A36J3
A37J6
Part Number
8120-6990
8121-6990
8121-0627
E8251-20218
8121-1241
E8251-20216
E8251-20310
E8251-20219
E8251-20215
E8251-20077
E8251-20313
E8251-20314
8120-6990
8120-6990
8121-6990
